SGS electronic UH1 User Manual

HUMMING PROBE pH strip electrode
UH1 User Manual (V1.3)
1.

Product Introduction

HUMMING PROBE pH test strip electrode UH1 is used together with pH measurement system
￭
UX100/UX200, makes pH measurement simple and accurate. The unique features: calibration-
free and low sample requirement allow multiple applications feasible.
UH1 strip electrode, innovatively integrates the principle of electrode measurement on a single test
￭
strip electrode for pH measuring. It is easy to operate, calibration not needed, easy to use,
convenient to store, carry and use. Measurement can be completed fast and easy.
HUMMING PROBE pH strip electrode UH1 is manufactured by UltraE Co., Ltd., and sold by
￭
authorized dealers. If you have any questions or comments about our products, please call our
company or contact your local distributor. We will assist you as soon as possible.
Product Content:
￭
(1). UH1 : pH test strip Electrode
(2). User Manual
2.

Safety Instructions

Read this user manual before using the Instrument.
￭
When you suspect the instrument is damaged, do not use it and notify us or your distributor
￭
immediately.
Always store the test Strip Electrode in the vial with cap closed when not in use to guarantee the
￭
quality. When using, take the strip electrode out of the vial and close the vial quickly.
If you have any questions about using the system, please contact us or your dealer.
￭
3.

UH1: pH Strip Electrode Product Description

Insert End
4.

Measuring pH Process

Choose Cable Socket Mode
(1) Take the strip electrode out of the vial and close
the vial quickly.
For Cable Socket Mode
connection cable plug to the socket of the meter
and Insert the strip electrode into the adapter of
the cable.
(2) (1) Cable Socket Mode
sampling port end into the test sample up to the
white line of the strip. If you have a CS200 mixer,
you can attach and fix the connection cable to the
bracket.
(2) Strip Port Mode
into the strip sampling port (Fig.A) or immerse the
sampling port end into the test sample for 2
seconds (Fig.B), then insert the Strip Insert End
into the Meter Strip Port. (Fig.C)
(3) Press the Inspect button.
(4) When the pH stable state is displayed, the pH
measuring is accomplished as displayed on the
screen.
or Strip Port Mode
,Connect the
: Immerse the strip
: Drop the test sample
1
Sampling port
Insert into sample up to the white line
as intended before measurement.
(Fig. A) (Fig. B) (Fig. C)
