Assemble WGA as shown, ensuring hose

barb points in the correct direction and the vent

hole on the WGA body faces away from possible

water ingress

Clevis

(RH thread)

Ensure the clevis and turnbuckle have at least 5mm of thread

engaged, but do not tighten any of the locknuts at this stage

Mount the WGA onto the turbo, and adjust the clevis until there is

at least 2mm of pre-load before attaching the clevis to the wastegate arm.

Tighten all locknuts, remembering that the locknut closest to the WGA body is a left hand thread.

Ensure the hose barb is connected to the boost source/boost controller, then perform a boost run to

check the boost level. If boost pressure is too low, increase the pre-load via the turnbuckle (or clevis)

WARNING:

GFB recommends that only qualified motor engineers fit this product. GFB products are engineered for best

performance, however incorrect use or modification may cause damage to or reduce the longevity of the

engine/drive-train components.

GFB LIFETIME WARRANTY:

Our commitment to quality means that when we put our name to something, we are also staking our

reputation on it. That's why we back our products with the best warranty in the business!

You should expect a lifetime of use from a well-engineered product, so if your GFB product fails as a result of

defective materials or faulty workmanship whilst you remain the original owner, we will repair or replace it

(limited only to the repair or replacement of GFB products provided they are used as intended and in

accordance with all appropriate warnings and limitations. No other warranty is expressed or implied).

If a fault occurs as a result of usage outside of the terms of the warranty, or you are not the original owner, fear

not, we can still help you. You should never need to throw a GFB product away, as spare parts are available

and won't cost the earth.

TECH SUPPORT:

We want you to get the best advice, first time. That's why our engineers are available to answer any technical

questions you may have. Head to
