INSTALLATION INSTRUCTIONS
Thank you for purchasing a LOMAX
Folding Hard or Professional Series Cover.
®
Agri-Cover, Inc. proudly manufactured this cover using superior quality materials
and workmanship. With proper care, your cover will provide years of service and
enjoyment.
NOTICE TO INSTALLER: Even if familiar with cover, read instructions prior to
installation as improvements may be made without notice. Always handle cover
and components with care. If you have questions or problems, have serial number
ready and call customer service. When done, these instructions must be given to the
consumer.
NOTICE TO CONSUMER: Before using cover, read operating, maintenance and safety
sections. Save these instructions for future reference.
FOR YOUR RECORDS
DATE PURCHASED:
WHERE PURCHASED:
SERIAL NUMBER:
(Located on decal under rear panel)
Questions? 844-566-2987
agricover.com
Advertisement
Table of Contents
Summary of Contents for ASI LOMAX
- Page 1 INSTALLATION INSTRUCTIONS Thank you for purchasing a LOMAX Folding Hard or Professional Series Cover. ® Agri-Cover, Inc. proudly manufactured this cover using superior quality materials and workmanship. With proper care, your cover will provide years of service and enjoyment. NOTICE TO INSTALLER: Even if familiar with cover, read instructions prior to installation as improvements may be made without notice.
-
Page 2: Parts Diagram
PREPARATION Unpack cover components and clean truck box if dirty. For additional installation assistance, go to lomaxcovers.com for install video. COMPONENTS TOOLS NEEDED • (8) Clamps • 1/2” Wrench • Driver side rail • Torque wrench with 1/2” socket • Passenger side rail •... -
Page 3: Installing Side Rails
1: INSTALLING SIDE RAILS NOTE: Some installs require special Front catch and side rail touching front of instructions. If required, follow special instructions for side rail attachment along with these standard instructions. A. Position side rail with weather strip Side rail guide provides proper side against inside lip of box, front catch toward rail placement front of box and side rail guide set on top of... -
Page 4: Installing Cover
1. INSTALLING SIDE RAILS (Continued) E. With side rail guide set on top of box, install second clamp on side rail 1/3 from front of box. Repeat clamping procedure. F. With side rail guide set on top of box, install third clamp 2/3 from front of box. - Page 5 2. INSTALLING COVER (Continued) C. With cover hooks engaged underneath front catches, lower cover to engage latches in retainment brackets on each side. Latch Retainment bracket D. Attach safety straps to brackets on each side. IMPORTANT: Always ensure safety straps Safety strap carabiner are attached to cover and side rails.
-
Page 6: Troubleshooting
TROUBLESHOOTING PROBLEM SOLUTION Top of tailgate hits cover when attempting Verify side rail guide is set on top of box. to close Side rails are not level or set too low at rear of cover, raise rails at rear of box until cover no longer interferes with tailgate operation (see Step 1). - Page 7 OPENING TRI-FOLD COVER IMPORTANT: To avoid damage or misalignment of hinge points, open cover in a smooth, fluid manner. Avoid dropping or slamming cover. IMPORTANT: Remove debris or snow from hinges before opening cover. A. Open tailgate, pull release latch. B.
- Page 8 CLOSING TRI-FOLD COVER IMPORTANT: To avoid damage or misalignment of hinge points, close cover in a smooth, fluid manner. Avoid dropping or slamming cover. IMPORTANT: Remove debris or snow from hinges before closing cover. A. Open tailgate, unfasten storage clips on both sides.
- Page 9 REMOVING AND REINSTALLING COVER REMOVE COVER A. With cover open and storage clips secured, detach safety straps from safety brackets. Safety strap carabiner attached to bracket B. Pull tab on front panel and lift rear edge of cover 1” above side rails (Figure 1). C.
-
Page 10: Safety Information
SAFETY INFORMATION • Always ensure hooks and latches fully engage catches and side rails. • Ensure safety straps are attached to safety brackets when cover is installed. • Do not tow vehicle backward with cover on your truck. • Do not cover cargo that is higher than the cover. •... -
Page 11: Inspection And Maintenance
TIPS FOR A LONGER LASTING COVER • Keep cover closed when not in use. • Avoid storing cover in its folded position for long periods of time. • Avoid dropping or slamming cover into closed position. • Ensure cover is properly latched while traveling and before entering automatic drive-through car washes. -
Page 12: Manufacturer's Limited Warranty
MANUFACTURER’S LIMITED WARRANTY Agri-Cover, Inc. extends the following three (3) year Limited Warranty for the LOMAX ® Folding Hard Cover or LOMAX Professional Series: ® Agri-Cover, Inc. warrants a period of three (3) years from the date of manufacture that...
