Page 1 Code: 8TAV00005 INSTALLATION MANUAL 10 DTH V2 Forced circulation systems...
Page 2: Table Of Contents
Contents Safety measures page 3 a. General instructions page 3 b. Installation instructions page 3 Panel description page 5 c. Panel information page 5 d. Description of label page 6 e. Panel overview page 6 f. Panel technical specifications page 7 g.
Page 3: Safety Measures
- Do not carry out repairs on components that have safety functions. These must be periodically checked and, if necessary, replaced. - Components must only be replaced using Thermics Energie original spare parts. Failure to do so will void the warranty.
Page 4 - Installation must only be carried out by qualified personnel according to the national and regional regulations in force. - Only use the fixing systems provided for the Thermics Energie collectors and read the current regulations provided in these instructions in order to install them correctly.
Page 5: Panel Description
The specific design objectives of the Thermics Energie solar collector allows the carrier fluid distribution lines to be simplified and significantly reduced and the available spaces to be optimized.
Page 6: Description Of Label
Panel description d. Description of label The following label on the panel, located at the top right of the frame, is as follows: 1. Manufacturer details 2. Product details 3. Solar Keymark certification label 4. Panel name 5. Technical information e.
Page 7: Panel Technical Specifications
3. Aluminium panel frame 4. Evacuated tube seal 5. Blank end cap 6. End cap with holes 7. Water connections f. Panel technical specifications Model 10 DTH V2 N° Tubes L1 net 1150mm L2 net 1166mm Net area 2.09 sq.m Gross area 2.38 sq.m...
Page 8 Panel description Pressure drop 8/48...
Page 9: Suggestions Regarding Sizing
Panel description g. Suggestions regarding sizing Reference can be made to some general guidelines for the sizing of small Thermics Energie solar systems as a starting point for the detailed executive design that the system, designer or qualified professional technician should carry out according to current technical practices and legislation: - Solar collector orientation;...
Page 10 Thermics Energie technicians. Solar filed reference flow rate The nominal flow rate of Thermics Energie panels is established by considering a value from 0.6 to 0.85 l/min per sq.m. The circulation unit also has to be selected and sized accordingly, considering the area of the solar surface installed, the pressure drops of the solar field and the circuit (local and distributed).
Page 11 Panel description Quick guide to selecting tubing for Thermics Energie solar systems with a maximum delivery and return distance from the boiler of 15 metres Total solar Recommended Flow N° Capacity surface sq.m tubing rate collectors 200L 2.38 sq.m 170 l/h Copper 18 mm 4.76 sq.m...
Page 12: Panel Installation
Panel installation Panel installation h. Notes regarding installation We recommend that you follow the installation and safety instructions indicated below in order to avoid damage to the system, people and property. - The additional weight of the collectors, the people involved in the installation and the load impose by wind and snow on the roof.
Page 13: Transport And Handling
- There should always be a certified safety valve in the solar circuit. All Thermics Energie solar stations and modules are fitted with a certified safety valve. Also install a metal drain at the outlet of the safety valve in a special brass container as per regulations.
Page 14: Choice Of Hydraulic Connection And
Panel installation j. Choice of hydraulic connection and examples Thermics Energie panels can be connected in series in a battery having a total surface area up to 35 sq.m. The hydraulic inlet and outlet connections to the panel can be installed one on one side and one on the other, either on the right or left, or both on the same side, either right or left.
Page 15 Panel installation The following connection possibilities are available for 10 DTH V2 panels: - Conditions of use and period of use 15/48...
Page 16 Panel installation Note For collectors in rows of batteries it is recommended to keep a distance of at least 1500 mm between one battery and another for flat roof installations and at least 300 mm for pitched roof installations. However, it is essential that sufficient space is provided to allow operator access the space between one battery and another.
Page 17 Panel installation - Series of collectors connected with Tichelman reverse-return system 17/48...
Page 18 Panel installation Key to details and connection examples Detail Description Compression T fitting with thermowell for copper pipe Dn22 Cap for copper pipe Dn22 Straight copper - copper pipe fitting Dn 22 x 22 Curved or straight compression fitting for copper pipe Dn22 Cap for copper pipe Dn22 Curved or straight compression fitting for copper pipe Dn22 Cap for copper pipe Dn22...
Page 19: Examples
• pitched roof and trestle • flat roof and trestle • façade l. Standard support (composition) In order for the Thermics Energie panels to be installed correctly, please follow the instructions below for positioning the brackets on a sloping roof. 19/48...
Page 20 Panel installation 20/48...
Page 21 Panel installation 21/48...
Page 22 Panel installation - Distance between panels Below are examples of installations with one or more panels in series mounted on pitched roof brackets: Installation of one 10 DTH V2 collector A max (mm) C max (mm) Panel 10 DTH V2 1600 Note The slot at the bottom of the “Double T bracket”...
Page 23 Panel installation Installation of two 10 DTH V2 collectors in series. Panel A max (mm) C max (mm) 10 DTH V2 1600 Note The slot at the bottom of the “Double T bracket” allows the value of C to be varied according to the anchoring requirements of the substrate.
Page 24 Panel installation Installation of three or more 10 DTH V2 collectors in series Panel A max (mm) A1 max (mm) C max (mm) 10 DTH V2 1024 1600 Note The slot at the bottom of the “Double T bracket” allows the value of C to be varied according to the anchoring requirements of the substrate.
Page 25: Standard Support (Composition)
Panel installation Flat roof installation with trestle 25/48...
Page 26 Panel installation - Distances between panels: Examples of installations with a panel on flat roof brackets are shown below: Installation of one 10 DTH V2 collector A max (mm) C max (mm) Panel 10 DTH V2 2020 Note As explained above, you should select the angle required before installing the kits. The installation of a single collector requires 2 kits per collector installed.
Page 27 Panel installation Installation of two 10 DTH V2 collectors in series. Panel A max (mm) C max (mm) 10 DTH V2 2020 Note As explained above, you should select the angle required before installing the kits. The installation of two collectors in series requires 1 bracket kit per n° collectors in series +1.
Page 28 Panel installation Installation of three or more 10 DTH V2 collectors in series A max (mm) A1 max (mm) C max (mm) Panel 10 DTH V2 1024 2020 Note As explained above, you should select the angle required before installing the kits. The installation of three or more collectors in series requires 1 bracket kit per n°...
Page 29: Flat Roof Installation With Trestle
Panel installation n. Installation with brackets 29/48...
Page 30 Panel installation 30/48...
Page 31 Panel installation Hydraulic system assembly Both sides of the Thermics Energie panel have a delivery and a return connection DN22. 31/48...
Page 32 - Detail of the connection of the compression T fitting with thermowell at the outlet from the panel: Note If the inlet or outlet pipe is Dn 18, the reduction bush that is included in the Thermics Energie systems, and which can also be purchased as an accessory, can be used.
Page 33 Panel installation - Detail of the screw-on fitting with flat face for connecting the inlet and outlet of the panel with corrugated stainless steel hose: Depending on the type of connection, the panel can be connected on the right or left, with delivery and return on different sides or with the delivery and return on the same side.
Page 34 Panel installation - Detail of Pt 1000 probe installation at panel outlet: Position of probe at panel outlet Note the probe (that can be recognized by the grey silicone cable) must be installed in the thermowell of the T fitting, on the hot outlet. If there are several batteries of panels connected to each other, the probe must be positioned on the hot outlet of the last battery from which the hot delivery line to the heating system starts.
Page 35 Panel installation - Detail of closing panels with the caps - showing configuration with input and output from the same side: - Detail of copper pipe connection to the solar station using a female copper pipe fitting with flat seat DN 22 x 3/4” or 1": Note When installing the solar station using copper pipe, we recommend using the fitting shown in the first and second photos including the HT seal (available as an accessory).
Page 36: Hydraulic System Assembly
Panel maintenance and repair Charging the solar circuit and putting it into operation It is recommended to use Thermics Energie Mayline FSP transfer fluid in order to prevent freezing or corrosion of the solar pipework. Mayline FSP is a glycol-based fluid specially designed for evacuated tube thermal solar collector applications.
Page 37 Panel maintenance and repair - Filling the boiler: Open the utilities hot water tap and leave it open, open the mains water inlet to the boiler and fill it. Once the boiler is completely full, close the utilities hot water tap and wash the solar circuit.
Page 38 Panel maintenance and repair Connect the delivery (filling) and return (drain) lines to the filling and drain valves (5-9). Close the ball valve (10) by turning it clockwise, open the filling valve (5) and drain valve (9) and add the Mayline FSP antifreeze by turning on the charging pump so that it circulates in the same direction as for normal operation.
Page 39: Panel Maintenance And Repair
Panel maintenance and repair Panel maintenance and repair Annual inspection of the panel and solar system When visually inspecting the collectors, check the following: - Make sure that the panels are not damaged and that the evacuated tubes are not defective.
Page 40 Panel maintenance and repair by the steam generated as a result of stagnation, without causing the safety valves to open and vent. - Safety valve: Each solar station that has a circulation pump is fitted with a safety valve with a threshold pressure of 6 bar.
Page 41: Replacing The Evacuated Tubes
T <T (measured in the pipework via an NTC probe). It is recommended to use Thermics Energie control units as they are tested and pre- set for the system to operate correctly and to optimize the yield of Thermics Energie solar field.
Page 42 Panel maintenance and repair Remove the lid of the frame: Lift the tube to be replaced just enough to remove it. Lift and remove the tube to be replaced from the head with the hydraulic connections: 42/48...
Page 43: Disposal Of Waste And The Panel
The solar panel, accessories and packaging consist mainly of recyclable raw materials (98% of the 10 DTH V2 collector). In this case, they can be disposed of at special collection centres in compliance with the national and local regulations in force.
Page 44 44/48...
Page 45 45/48...
Page 46 46/48...
Page 47 47/48...
Page 48 Registered Office and Operational Headquarters: Via C. Pascoletti 2 – 33040 Povoletto (UD) Italy Tel. (+39) 0432 823600 – Fax. (+39) 0432 825847 www.thermics-energie.it | info@thermics-energie.it All rights reserved. Thermics Energie reserves the right to modify and update this document...
