Sanyo ECO-i WCHDZ32053 Datasheet

ECO-i Submittal Data
™
WCHDZ32053
Heat Recovery: 25 tons VRF Outdoor Unit
Job Name:
Location:
Engineer:
Submitted to:
Submitted by:
Reference:
Capacities
Cooling: Btu/h
Power Input: KW
Heating: Btu/h
Power Input: KW
Cooling Mode Nominal Conditions
Indoor: °F DB/°F WB
Outdoor: °F DB
Pipe Length (feet):
Level Difference (feet):
Heating Mode Nominal Conditions
Indoor: °F DB
Outdoor: °F DB/ °F WB
Pipe Length (feet):
Level Difference (feet):
Operating Range
Cooling: °F DB:
Heating: °F DB:
Heating + Cooling °F DB
Compressor
1 Inverter driven rotary & 2 f xed speed scroll (each)
Quantity/Type:
Capacity Control Range:
Approval:
Date:
Construction:
Unit #:
Drawing #:
Compressor Warranty: 6 Years
Parts Warranty: 1 Year
Coil Coated to Protect Against Corrosion
Salt Protection also available
Fan
307,200 Quantity/Type:
13.3 (each) Fan Motor Output (KW):
341,200
13.3 (each) Power Supply
V/PH/Hz.
Minimum circuit Amps (MCA): Amps
Max. Overcurrent Protection (MOCP):
80/67
95
25 Weight (lbs):
0
Refrigerant:
70 Coil
47/43 Coil Face Area (sq. ft.):
25 Number of Rows:
0
Protection Devices
High Pressure Switch:
14 to 113 Overcurrent (CT Method):
-4 to 59 Crankcase Heaters (W):
14 to 113
External Finish:
10-100%
Print Form
1 Propeller (each)
0.7 (each)
208-230 / 3 / 60
59 (each)
70 (each)
789 (each)
410A
22.5 (each)
4 (each)
Yes
Yes
25 + 32 x 2 (each)
Electrostatic Powder Coating
