Summary of Contents for Roccat ARVO
- Page 1 MANUAL IMPORTANT DOCUMENT WWW.ROCCAT.ORG / SUPPORT...
-
Page 2: Table Of Contents
CONTENTS Limitation of Liability Safety Instructions Introduction What’s Included System Requirements Connecting Installation under Windows ® Game Mode/Num Pad Mode Configuration Menu Main Control Macro Manager Game Profiles Enable/Disable Keys Reset to default Update Warranty/Support WWW.ROCCAT.ORG / SUPPORT... -
Page 3: Limitation Of Liability
SAfETy iNSTRUCTiONS Troubleshooting/repairs Disposal Do not attempt to service or repair the product The markings on the product and on the yourself; leave any maintenance to qualified associated literature show that this product experts. Do not attempt to modify the product in must not be disposed of together with normal any way as doing so will invalidate the warranty. household waste at the end of its useful life. Please dispose of this device separately from other waste in order not to cause harm to Moisture/heat the environment or human health through uncontrolled refuse disposal. Recycle the device Only use the keyboard in dry, interior rooms. Do to facilitate the sustainable recycling of material not operate the device near water and keep it resources. Private users should contact the away from damp areas and areas where liquids dealer from whom the product was bought, or the are likely to drip or be sprayed in order to prevent authorities responsible for recycling, to find out damage occurring. how to recycle the device in an environmentally friendly way. Commercial users should ask their Physical harm suppliers and consult the sales contract terms. This product must not be disposed of together Some experts are of the opinion that the using a with other commercial waste. keyboard may lead to health problems with the hands, wrists, arms, neck and/or back. Please seek specialist medical advice if you notice any pain, numbness or weakness in any of these areas. WWW.ROCCAT.ORG / SUPPORT... -
Page 4: Introduction
ROCCAT™ Arvo Compact Gaming Keyboard – the smallest and most innovative gaming keyboard on the market. Designed by product designers with years of gaming experience, it gives you a better overview of your desktop and in the game – and you‘ll be able to react faster and more flexibly than ever before. Its compact size means the Arvo only has a small footprint, leaving you with lots of room to move your mouse and for your individual style of gaming. Num pad gamers in particular will benefit from being able to place this keyboard across the desktop without the risk of it immediately falling off. Based on a standard keyboard layout, key height, stroke and layout are tailored precisely to gamers’ needs. The flat keys and the noticeable pressure points make the Arvo perfect for precise gaming. In addition, this keyboard is the first and only keyboard which finally gives your thumbs a bigger role than just simply hitting the spacebar: three freely definable macro keys (thumbsters) now lie within striking distance of your thumbs. These allow you to quickly trigger macros, while the optimum pressure point of the thumbsters prevents the keys from being accidentally pressed. But that’s not all: there aren’t just three macro keys – in game mode another two are available. In this mode the standard number pad acquires special gaming functions. It features blue illuminated arrow keys, with two additional, individually programmable macro keys to the side. Other keys, such as the Caps Lock or Windows keys, which are a frequent source of annoyance during gaming, can be quickly and easily deactivated. WWW.ROCCAT.ORG / SUPPORT... -
Page 5: What's Included
UNdER WiNdOWS XP/ViSTA ® ® Insert the supplied CD into your CD-ROM drive and double click the file ‘setup.exe’. Follow the on-screen instructions. Click ‘Continue Anyway’ if Windows logo testing is not passed. Note: The driver will automatically uninstall older ROCCAT driver versions. It may take a while until the driver is installed and ready for use. Once the installation process is completed, restart your computer. The ROCCAT symbol will now appear on the right-hand side in the taskbar. You can access the ROCCAT™ Arvo configuration menu by right clicking it. GAmE mOdE V. NUm PAd mOdE The Arvo features a dual assignment num pad. If... -
Page 6: Configuration Menu
Note: As soon as you’ve configured a setting you can assign the function to the keyboard by clicking the ‘Apply’ button without having to exit the ROCCAT menu. It may take a few seconds until the information is transferred to the keyboard. - Page 7 – three – two – one – go!’ You can assign the ‘Stop timer’ command to another key. This will allow you to cancel the countdown at any time at the press of a key. Assign a shortcut You can assign a shortcut to the selected key using the ‘Assign a shortcut’ option. You can combine the Ctrl, Shift, Alt and Windows keys with any other key and assign it to a single key. For instance, this means you only need to press a single key to call up the Task Manager instead of pressing Ctrl+Alt+Delete. ‘Assign a shortcut’ also gives you the opportunity to remap keys. To do that, select ‘None’ and press the key whose function you’d like to remap. You can, for example, assign a key which is out of reach, but which you need during the game, to one of the easily reachable macro keys. For multimedia functions • Open player • Pre track • Next track • Play/Pause • Stop • Mute • Volume up • Volume down • Select player Für den Internet Explorer • Search • Home • Back • Forward • Stop • Refresh • Favorites WWW.ROCCAT.ORG / SUPPORT...
-
Page 8: Macro Manager
Note: Two actions are performed when pressing a key: pressing and releasing. For example, the key combination Alt+Ctrl+t comprises 6 actions. Creating a macro (Basic Editor) Step 1: Click the upper line in the left-hand window. In the following dropdown menu you can add a macro set (Add Macro Set) or delete one (Delete Macro Set). Click ‘Add Macro Set’. Step 2: Give your macro set a name. To make things clearer, use a general name for the actions in the game you’re playing. For example, you can name the set ‘Magic buffs’ or ‘Weapons arsenal’. WWW.ROCCAT.ORG / SUPPORT... - Page 9 Assignment’ window, clicking next to the key you want to execute the macro with and selecting the ‘Assign Macro’ option from the dropdown menu. All the macro sets you’ve created will now be displayed from which you can search for the individual macro you want to use. Note: If you’ve edited a macro that’s already been assigned, you have to reassign it to the desired key. Step 6: You can assign the function to the keyboard by pressing the ‘Apply’ button without having to exit the ROCCAT menu. It may take a few seconds until the information is transferred to the keyboard. You can now store and save these settings under one of the five profiles that can be stored on the keyboard. Profiles will be easier to manage if you name them after the game, gamer or program. Note: A macro that is currently running can be stopped at any time by pressing the key again. WWW.ROCCAT.ORG / SUPPORT...
- Page 10 Integrated mouse clicks Another special feature of the ROCCAT driver is that it allows you to edit macros. To do that, in ‘Macro Basic Manager’ select the key command before or after which you want to insert a new action. A window with various options will open when you click the right mouse button: Start Record before: starts macro recording before the selected action. Start Record after: starts macro recording after the selected action. Insert Delay: manually lengthen or shorten the delay between two commands. Edit Delay: you can manually lengthen or shorten the delay here. You don’t need to enter the time designation of ‘ms’ (milliseconds), just the desired time. Note: Some games are unable to detect short delays.
-
Page 11: Game Profiles
Note: If you have assigned a program or game to a profile, the keyboard will switch to the relevant profile as soon as you launch the program or game. Load Profile You can also save more than 5 profiles on your hard drive and load these as profiles 1-5 as you wish. For example, this allows you to retain older profiles or your friends can give you profiles which you can then use on your keyboard. Edit Profile Here you can edit the names and the link of the selected profile. Use the link so that the keyboard automatically detects the program you have programmed specific keyboard settings or macros for. WWW.ROCCAT.ORG / SUPPORT... -
Page 12: Enable/Disable Keys
Tab Key dRiVER RESET TO dEfAULT This option resets the keyboard back to its default settings. Every single profile, macro and setting saved on the keyboard will be deleted. Note: You can also manually reset the Arvo back to its original default settings by pressing F1 and F4 at the same time while plugging the keyboard into a USB port. UPdATE You can update your ROCCAT™ Arvo Compact...
