Confio CT-GS Manual

Gas Sensor
Introduction:
CONFIO Gas Leak Sensor is a fashion design, compact detector, we can install it on a wall or
ceiling. Its high sensitivity allows to detecting carbon monoxide (CO) , LPQ & natural gas in
order to prevent poisoning.
Triggered signal with a built‐in siren, blinking LED indicator and by sending commands to
Z‐Wave network devices. Also you can set the scene or condition you want it be.
Specifications:
Power supply 5V 1A adaptor
Operating temp -20~50 C
o
Detecting Natural gas & LPG & Carbon monoxide
Range 30m line of sight
Dimensions 78*78*40 mm
Z-Wave Frequency 868.40MHz
Product Net weight 150g
Gift box size 105x64x103 mm
Carton size 365x330x340 mm (60pcs per ctn)
Installation
1. Mount the cover on a wall.
2. Attach the device to its cover.
3. Turn the device clockwise to close it.
Z‐Wave Internet
1‐Inclusion
‐ Z‐Wave device learning mode, allowing add the device to existing Z‐Wave network.
‐ Place the device within direct range of the Z‐Wave controller.
‐ Set the main Z‐Wave controller in adding mode.
‐ Turn the cover counter‐clockwise, open the cover, insert 5V/1A adaptor powered on device,
and Blue LED blinking slowly & Buzzer make a sound "Bee‐Bee‐Bee".
‐ Press the Learn Button 3 times within 1.5 seconds, Red & Blue LED blinking till added
successful.
2‐Exclusion
CT-GS CT-GS
Page 1 / 3
Gas Sensor
‐ Z‐Wave device learning mode, allowing remove the device from existing Z‐Wave network.
‐ Place the device within direct range of the Z‐Wave controller.
‐ Set the main Z‐Wave controller in remove mode.
‐ Press the Learn Button 3 times within 1.5 seconds, Red & Blue LED blinking till added
successful.
3‐Factory Reset
‐remove from gateway is back to default.
‐ Long press Test Button more than 10 seconds to back to factory reset.
‐Please use this procedure only when the network primary controller is missing or otherwise in
operable.
Test Button
& Factory Reset
Button
4‐Device LED status and Test mode
‐LED status
Item Color
Power Blue Blink 20 times each
0.5s
Alarm RED Blink 5 times each
0.2s
Dis‐alarm Red Blink 5 times each
0.2s
Tamper switch turned on Blue Always on 1s
Fault Blue Always on
‐Test mode
When Device is pressed Test Button, buzzer make a sound "Bee‐Bee" two times and red LED
flash 5 times each 0.2s, means detect Gas.
2 seconds late, Red LED blinking 5 times each 0.2s, means alert is over..
‐Wake up time
Default each 4 hours
CT-GS
Learn Button &
Tamper Switch
LED status sound
"Bee‐Bee‐Bee"
"Bee‐Bee‐Bee"
No sound
No sound
Buzzer Always "Bee"
Page 2 / 3
