Until now, you could only use the keypad itself, but now it is possible to connect other equipment to
it enabling you to control keypad codes remotely in real time.
• Real-time use facilitates keypad code updates without going on-site. It is also be possible to
take advantage of options such as event logs, alarms, timeslots for all codes, etc.
• Use of the stand-alone keypad remains unchanged.
A GSM unit and 2 central units now complete the product-offering compatible with the Haussmann
keypad:
EEN-CEN12
+
Your Haussmann Riri coded keypad was designed to be adaptable to everyone's needs: being
simple to use on a daily basis, this is the only coded keypad which complies fully with disability
legislation. Thanks to real-time operation, you can now manage it remotely from the
www.intratone.com
Everything is arranged to help you save time on fitting: it adapts to fit all facades (built-in and
surface-mounting) and all existing built-in boxes.
Your keypad has also been designed to reduce electricity consumption to a minimum; it enables
you to save up to 1kW/p.a. per apartment block.
2 LEDs
Green : Access permitted
Red: Access denied
Cover for insertion of
proximity reader
Page 1 / 13
The HAUSSMANN RIRI keypad
YOUR HAUSSMANN RIRI KEYPAD IS EVOLVING
website in the ʺmanagement website" tab.
Installing and using the HAUSSMANN RIRI keypad
"Unrestricted
access" door
12+1 Backlit keys
with an audible
beep and Braille
EEN-CIC12
+
EN-V233-0009-CA
NEW
Advertisement
Table of Contents
Summary of Contents for Haussmann RIRI
-
Page 1: Your Haussmann Riri Keypad Is Evolving
• Real-time use facilitates keypad code updates without going on-site. It is also be possible to take advantage of options such as event logs, alarms, timeslots for all codes, etc. • Use of the stand-alone keypad remains unchanged. A GSM unit and 2 central units now complete the product-offering compatible with the Haussmann keypad: EEN-CEN12... -
Page 2: Table Of Contents
WEEE (Waste Electrical and Electronic Equipment Directive) collection and recycling channel. REAL-TIME OPERATION "Real-time" operation takes priority when the Haussmann Riri keypad is connected to a central unit with a GSM unit. In this case, "stand-alone keypad" settings are totally disabled. The management website enables configuration: •... - Page 3 Cabling for the HAUSSMANN RIRI keypad with an EEN-CIC12 central unit and a GPRS unit EEN-CIC12 Door 1 Door 2 + - D+ D- PB1 DO - C R T Door 1 Door 2 Door Control Control Control The central unit "door control"...
- Page 4 Cablingfor the HAUSSMANN RIRI keypad with an EEN-CEN12 central unit and a GPRS unit *Warning* 12/24V DC EEN-CEN12 2A (door 1 and 2) In this configuration 3A with an the relays and PB on the keypad extension board for cannot be used.
-
Page 5: Alert And Unrestricted Access In Real-Time
Unrestricted access: A press of the button by a visitor will trigger the opening of door 1 on the HAUSSMANN RIRI keypad during the unrestricted access timeslot. This function may be useful in the event of independent professionals using the premises. It will then not be necessary to know a keypad code to open the door on working days. -
Page 6: Entering Programming Mode
This programming mode enables you to manage the master code and door-opening time. In stand-alone keypad use: This programming mode enables you to manage access codes and the master code, the door- opening time and to check memory capacity. Page 6 / 13 EN-V233-0009-CA Installing and using the HAUSSMANN RIRI keypad... -
Page 7: Stand-Alone Keypad Operation
STAND-ALONE KEYPAD OPERATION The HAUSMANN RIRI keypad can work as a stand-alone. It just needs to be programmed and installed at the entrance to the building. In this functioning mode, the keypad must be configured outside. Enter programming mode as described above and use the following functions:... - Page 8 The red LED goes out, thus confirming the return to normal operation. Exiting programming mode is automatic: 1. after 30 seconds of no activity 2. when the button on the keypad is pressed Page 8 / 13 EN-V233-0009-CA Installing and using the HAUSSMANN RIRI keypad...
-
Page 9: Connection To A Door
The button and the timeslots The HAUSSMANN RIRI keypad can be used with an external clock which enables • either the use of the button in "unrestricted access" mode to open 1 door only. • or the programming codes associated with timeslots. -
Page 10: Dimensions
DIMENSIONS Keypad Keypad without with reader reader Surface-mount Built-in wall Drill holes bracket Page 10 / 13 EN-V233-0009-CA Installing and using the HAUSSMANN RIRI keypad... -
Page 11: Surface-Mount Installation
Unscrew until just touching Hook onto the fixing point Hold against the wall and lift up the keypad Hold the keypad down Screw the keypad to the wall seal ATERTIGHT WALL Page 11 / 13 EN-V233-0009-CA Installing and using the HAUSSMANN RIRI keypad... - Page 12 Clipping action Watertight seal held against the wall Wall Page 12 / 13 EN-V233-0009-CA Installing and using the HAUSSMANN RIRI keypad...
-
Page 13: Fitting Record Form For A Stand-Alone Keypad
CODE CODE Master Key: Door 1 Door 1 with Timeslot Door 2 Door 2 with Timeslot Door 1 and door 2 Door 1 and door 2 with Timeslot Page 13 / 13 EN-V233-0009-CA Installing and using the HAUSSMANN RIRI keypad...
