Bticino 3527 Quick Start Manual

Radio remote control 6 channels
Description
This remote control is a transmitting radio device that can drive the radio actuators item
F470/1, F470/2, 3526, 3526/10 and 3526/16; when used in conjunction with receiving
interfaces HC/HS4575 and L/N/NT4575N, it can also be used to control devices of the
MY HOME system. This remote control has six radio channels and six customisable keys
which are back-lit and emit a sound when selected.
The remote control can also be used as a flashlight. There is an orange LED which
indicates that the radio transmission has occurred after pressing a key; if this indicator
turns red, it means that the batteries are dead and must be replaced.
Technical data
Power supply: 2 AA 1.5 V pen batteries
(not provided, min. duration: 3 years)
Operating temperature: 0 – 40 °C
Radio frequency: 868 MHz
Range: 100 m in free field
(metal and reinforced concrete walls reduce the range)
Type of modulation: FSK
Torch function:
When you press keys 5 and 6, the remote control will act as a flashlight.
Warning, in this mode the duration of the battery is sensibly decreased.
BT00099-b-EN 05/06/2012
LED
key 1
key 2
key 3
key 4
key 5
key 6
Key 6
Key 5
3527
