Summary of Contents for Van Raam City walking support
- Page 1 User manual City walking support Van Raam Guldenweg 23 7051 HT Varsseveld, The Netherlands +31 (0)315 – 25 73 70 info@vanraam.com Version 22.03 www.vanraam.com...
-
Page 2: Table Of Contents
Frame number ............................... 10 Maintenance recommendation ....................... 11 Service plan ..............................13 Delivery and service form Delivery and service form ............... 15 Manufacturer contact details Van Raam Guldenweg 23 7051 HT Varsseveld, The Netherlands +31 (0)315 – 25 73 70 info@vanraam.com www.vanraam.com... -
Page 3: Conformity
Conformity Van Raam declares as manufacturer that the walking support bicycle has been produced in accordance with the Medical Devices Regulation (EU) 2017/745, risk class 1. All products have been produced in accordance with the 2006/42/EG guidelines. The signed declaration of conformity can be found on the Van Raam website. -
Page 4: Safety Measures
Safety measures Check every time before you go for a ride: the brakes; • the tire pressure; • that all parts are fitted properly. • Load The maximum load should not be exceeded. See the information in the technical data table in the ‘Technical Specifications’... - Page 5 Saddle height When the person is sitting on the walking support and can put both feed on the floor, the saddle height is correct. Adjust the saddle height in such a way that the leg is stretched but relaxed in that position. To adjust the saddle: Open the quick clamp a few turns.
- Page 6 Steering Position You can tilt the handlebar. This affects the distance from the handlebars to the upper body. Feel free to determine what setting is most comfortable for you. To tilt the handlebar: Loosen the screw using an Allen key. Place the handlebars in the desired position and firmly tighten the screw.
-
Page 7: Technical Specifications
Technical specifications Length (cm) Width (cm) Height (cm) 70 – 96 (customizable) Front wheel 12,5“ Back wheel 12,5“ Weight (kg) about 9 Max. user weight (kg) , 150 Brakes, front Cantilever brakes Standard ¹ Maintenance and adjustments by owner Below are some instructions for maintenance and adjustments that you can perform on a regular basis. -
Page 8: Disposal
If you choose to replace components by yourself, you will be liable for any damage or injury caused by improperly installed components. Only use original Van Raam spare parts. You can purchase these from your dealer. Upon request, the dealer will provide the necessary information for repair and maintenance. -
Page 9: Guarantee
This is also the case if unauthorized maintenance is carried out or if technical changes or additions are made with non-original Van Raam parts without permission of Van Raam. The original CE certification will become nul-and-void if modifications are done by third parties. -
Page 10: Frame Number
Frame number The frame number is printed on the sticker. This sticker is located on the frame, see the image below. Example sticker: Position of sticker: Backside of the frame Version 22.03 10/15... -
Page 11: Maintenance Recommendation
A Van Raam bike often is subject to extensive use and must perform in all weather conditions. By correctly maintaining the bike, the lifecycle can be extended greatly. This maintenance can be done by a Van Raam dealer. In most cases, you can do the monthly and annual inspection yourself. - Page 12 Service moment 15-30 minutes Among them: Check tyres and inflate • Check the spoke tension • Check the chain tension and grease • Tighten any bolts and nuts if needed • Check all brake cables and brake calipers • Check the gears •...
-
Page 13: Service Plan
Service plan Service moment Yes/No Date: Dealer: Mechanic: Remarks: ………………………………………………………………………………………………………………………………………… …………..…………………………………………………………………………………………………………………………… ………………………..……………………………………………………………………………………………………………… ……………………………………..………………………………………………………………………………………………… Service moment Yes/No Date: Dealer: Mechanic: Remarks: ………………………………………………………………………………………………………………………………………… …………..…………………………………………………………………………………………………………………………… ………………………..……………………………………………………………………………………………………………… ……………………………………..………………………………………………………………………………………………… Service moment Yes/No Date: Dealer: Mechanic: Remarks: ………………………………………………………………………………………………………………………………………… …………..…………………………………………………………………………………………………………………………… ………………………..……………………………………………………………………………………………………………… ……………………………………..………………………………………………………………………………………………… Version 22.03 13/15... - Page 14 Annual inspection Date Dealer Mechanic Remarks Extra Maintenance and Check-ups you can do yourself: Do you want ore tips and tricks on how to keep your bike in perfect condition? Check out the article: ’10 tips for the maintenance of a (special needs) bike’ on our website.
-
Page 15: Delivery And Service Form Delivery And Service Form
Congratulations on your purchase of your Van Raam walking support. This walking support is produced with utmost care. To guarantee the quality as much as possible Van Raam produces the cycles according to the ISO 9001:2015 quality standards. Van Raam has been certified by DNV GL Business Assurance BV.
