Summary of Contents for ELEVATE OUTDOOR BR-STD
Page 1
2 Bike Storage Rack Instructions for Part #BR-STD GENERAL GUIDELINES & SAFETY • It is the user’s responsibility to read and follow all instructions. • Keep these instructions with the product at all times and review before each use. • It is the responsibility of this product’s owner to furnish the instructions to any person that borrows or purchases the product.
Page 2
PARTS Part Description Quantity Top Vertical Upright Bottom Vertical/Leg Upright Back Leg Front Stabilizer Bar Middle Logo Plate Top/Bottom Connectors Bike Arm Bar Plastic Bike Cradle Rubber insert Bike Cradle Upright Internal Connectors Small Parts Bag SHC screw(25mm) 4mm head Cap Nut Washer 13mm Hex Head Bolt(40mm) Small Hex Key(4mm)
Page 3
ASSEMBLY Step 1: Unload all contents from box and check to make sure all parts and components are present. Step 2: Thread knob into the 4 Bike Arm Bars (G). Set these parts aside. Repeat until all 4 Bike Arm Bars have in them.
Page 4
Step 5: In this Step you will need the assembly imaged above and Part D, 2 Long SCH Screws, 4 Washers, and 2 Cap Nuts. Line up Part D so the holes line up with the holes on the forward legs of the above assembly. Insert 1 Cap Nut into the back of the above assembly mounting hole and hold it in place.
Page 5
Step 7: For this Step you’ll need the assembly we’ve created, and 2 Part G (Bike Arm Bars), 2 Part H (Plastic cradles), 2 Part I (Rubber Insert For Bike Cradles). We are now ready to slide two of the Bike Arms on the Part B uprights. For straight tube bikes, slant tube frames 19’’...
Page 6
Step 8: For this Step you’ll need the assembly we’ve created, 1 Part J ( Upright Internal Connector), Part E (Connector Plate), 2 Short SHC Screws, and 2 Cap Nuts. This Step is easiest achieved by laying the assembly down on the floor. First, take Part J and insert it into one of the Part B uprights as shown below making sure holes are lined up.
Page 7
Step 9: For this Step you’ll need the assembly we’ve created, 1 Part J ( Upright Internal Connector), 2 short SHC Screws and 2 Cap Nuts. Repeat Step 8 for the other Part B upright using the other Part J (Upright Internal Connector). Do not tighten completely, see image below. Step 10: For this Step you’ll need the 2 Part A, and 2 Part G (Bike Arm Bars), 2 Part H (Plastic Cradles), 2 Part I (rubber insert for bike cradles).
Page 8
Step 12: For this Step you’ll need our assembly so far, 1 Part A, 2 short SHC screws, 2 Cap Nut, small Hex key, large hex key. Repeat Step 10 for other side. Finished assembly should appear like image below: Step 13: For this Step you’ll need our assembly so far,1 Part F, 2 Short SHC Screws, 2 Cap Nut, Small Hex Key, Large Hex Key.
Page 9
PRODUCT WARRANTY & LIABILITY GENERAL PRODUCT WARRANTY: Products purchased from the Authorized Dealer (original place of purchase) or Merchant (“Dealer”) will be free of defects in material and workmanship at the time of receipt, and will meet the specifications stated at the place of purchase transaction or online at the Dealer’s website, under normal use and service when correctly installed, operated and maintained.
