- Page 1 Installation Instructions TOILET Castello & Sienna Back-to-Wall NOTE: Our Back-to-Wall toilet suites are suitable for both a rear & side entry water inlet.
-
Page 2: Before You Begin
Vitreous china can break or chip if the product is handled carelessly. • Observe all local plumbing and building codes. Installation shall be in accordance with AS/NZS 3500 and AS/NZS 6400. • Carefully inspect the new toilet for damage. CASTELLO & SIENNA BACK-TO-WALL |... -
Page 3: Parts Identification
Supplied Pack A: ± Pan Fixing Kit ± 2 x Stainless Steel Bolts and Rubber Seal (supplied) Supplied Pack B: ± 4 x Stainless Washer ± 2 x Stainless Nut ± 2 x Stainless Wing Nut CASTELLO & SIENNA BACK-TO-WALL |... -
Page 4: Preparing To Install
For Side Entry/Bottom Inlet installations, proceed with instructions, below 2. For Side Entry/Bottom Inlet installations, check the shut-off valve position. Side entry hole Side entry hole Shut-off Shut-off valve valve Left-hand Right-hand valve position valve position CASTELLO & SIENNA BACK-TO-WALL |... - Page 5 (Not supplied) 4. Connect the supply hose to the shut-off valve to test the system for leaks. Shut off the water supply and disconnect the hose. Insert a capping plug into the unused hole. Capping Plug CASTELLO & SIENNA BACK-TO-WALL |...
- Page 6 Offset Pan Collar Setout 2. Mark the positions of the floor fixing kit holes. N.B. If floor has had waterproof membrane applied, we recommend just siliconing the pan to the floor. Fixing hole locations Template CASTELLO & SIENNA BACK-TO-WALL |...
- Page 7 5. Position the toilet in the marked location, while ensuring an effective connection is made with the pan connector. 6. Install the plastic screw sleeves and use the screws to fix the toilet to the brackets. Attach the chromed caps to the screw heads. CASTELLO & SIENNA BACK-TO-WALL |...
- Page 8 4. Insert cappling plugs into the side entry holes in the pan. 5. Connect the supply hose to the shut-off valve to test the system for leaks. Shut off the water supply and disconnect the hose. CASTELLO & SIENNA BACK-TO-WALL |...
-
Page 9: Push Button Installation
FLUSH VALVE REMOVAL AND INSTALLATION Flush Valve A 1. Release flush valve by turning 2. Assemble flush value by anti-clockwise and pulling pushing straight down into the straight up on the canister. canister and turning clockwise. CASTELLO & SIENNA BACK-TO-WALL |... - Page 10 9. Align the posts and carefully 11. To remove the seat, press the quick lower seat back into place (‘click’ will release button (‘click’ will confirm) and be heard). open seat & lid to vertical position. CASTELLO & SIENNA BACK-TO-WALL |...
- Page 11 Do not force closure of the seat or lid, allow mechanism to close naturally. Be careful of damaging the toilet seat. This includes standing on the toilet seat, or overloading the toilet seat, which can result in broken hinges. CASTELLO & SIENNA BACK-TO-WALL |...
- Page 12 4. Apply a suitable sealant between the pan and adjacent surfaces. Head Office 281 Heads Road, Wanganui PO Box 2050, Wanganui sales@newtech.co.nz Auckland Showroom 525 Great South Road, Penrose, Auckland aucklandshowroom@newtech.co.nz 0800 728 662 www.newtech.co.nz CASTELLO & SIENNA BACK-TO-WALL |...
