Audley ADL-1600C1 Manual

ADL-1600C1 ADL-1600C1
ADL-1600C1 ADL-1600C1 Auto
I. I. I. I. Technical Technical Technical specification specification
Technical specification specification and
Laminating Width: 1520 mm(60〞)
Laminating Speed: 0—6 m/min
The Diameter of Roller: 130mm
The Lifting Height of Roller: 25mm
The Heating-temperature of Roller: When cold laminating, the temperature of the
upper roller can set 50-60℃; the highest temperature no more than 60℃.
Voltage: AC220-240V 50 Hz (optional 110 V)
Power: 1400 W/single roller heating
Rated Current: 10A/single roller heating
The Motor Power: 90 W
Packing Size: 2150 x 740 x 740 mm
Packing Weight: 180 kg
II. II. II. II. Installation Installation Installation
Installation
The notes during installing:
1. Before unpack the box, check the packing cases whether it is damaged during the
transportation in order not to cause the machine damaged.
2. After unpack the box, check whether parts are complete according to the packing
list (see appendix one).
3. The installation place should be in an enough operating space, which is clean, no
dust, no steam and corrosion gas pollution, no inflammable and explosive substances.
Don't put the machine in the air vents, otherwise it will affect the roller surface
temperature to cause laminating quality not stable.
4. The machine's truckle can only be in flat surface to do shortly move.
5. The voltage of this machine is 220-240 V (or 110 V need to order). Before connect
the electric power, should check the power source and capacity is enough. Need to fix
the breaker in 220-240 V/20 A, and have sound grounding device, in case cause
personal injury.
6. Front working-table can be turned over, which is a not-stress mechanical structure,
when you move the machine, pls turn the working-table over, don't put heavy things
on it to avoid to not damage it and the screws.
7. When use forklift to move the machine, need to put the forklift arm under the
under-beam, but both sides must have person to help protect it, to prevent the machine
from dumping front and back.
The The machine machine is is is is heavy machine
The The machine
All manuals and user guides at all-guides.com
Auto Auto Cold Cold
Auto Cold Cold Laminator
and and relevant relevant
and relevant relevant parameter
heavy heavy! ! ! ! When heavy When When moving moving, , , , must moving
When moving
Laminator Laminator Manual Manual
Laminator Manual Manual
parameter parameter
parameter
must must pay pay attention attention attention to to to to safety!
must pay pay attention
safety! safety!
safety!
