- Page 1 LEAF BLOWER BE-LBR55 OPERATIONS & PARTS MANUAL FOR MODELS: • BE-LBR55 PURCHASE DATE MODEL NO. SERIAL NUMBER DEALER MANUAL CODE: 102.102B...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY INSTRUCTIONS SPECIFICATIONS, PARTS DRAWING AND SAFETY LABELS OPERATING SAFETY IN GENERAL AND MAINTENANCE SAFETY IN GENERAL ENGINE SPECIFIC SAFETY ASSEMBLING OPERATION CHECK IST STORAGE TROUBLESHOOTING CHART PARTS LIST LB55 USER MANUAL... - Page 3 WARNING SYMBOL WARNING: This is the warning symbol to get your high attention for the instruction notice, which should be followed to avoid any potential serious personal injury. Anyone to use this equipment should read all the instructions of this manual. Keep this instruction manual for future reference.
- Page 4 SPECIFICATIONS ITEM BE-LBR55 Size (L*W*H) 40.2*22.9*43.3 inch Weight 51KGS Front wheel 8”, Back Wheel Size wheel 10” Wheel Material Rubber Impeller Size 13.5” (340mm) Noise 95.9db @3600rpm PARTS DRAWING Handle Engine Base 10" Back wheel Universal wheel rack 8" Front wheel...
- Page 5 OPERATING SAFETY IN GENERAL 1. Be very careful when loading or unloading the leaf blower. 2. Slow down and use caution when making turns and crossing roads and sidewalks. 3. Do not run the engine in an enclosed area where dangerous carbon monoxide fumes can collect. 4.
-
Page 6: Engine Specific Safety
Rotating Impeller 1. Don’t attempt to remove materials from intake or discharge when unit is running or impeller is rotating. 2. Fan coasts after the engine is turned off. 3. Only replace impeller. Never straighten or weld them. 4. Keep other persons away from impeller. 5. -
Page 7: Assembling
Adding Fuel To add fuel: 1. Remove the fuel cap. 2. Fill the tank. Do not overfill. Leave room in the tank for fuel expansion. Refer to your engine manual for specific fuel recommendations. 3. Install and hand tighten the fuel cap. Starting the Engine 1. -
Page 8: Operation Check Ist
Install handle bar 1. Fix the handle rod (A) and (B) with M8x45 flange bolt (D) and M8 flange loosening nut (C). 2. Fix the assembled handle rod (A & B) and base (E) with M8x45 flange bolt (D) and M8 flange loosening nut (C). -
Page 9: Storage
STOPPING THE ENGINE When operation is complete or the unit needs to be checked or a clog needs to be cleared: 1. Move the throttle to SLOW. 2. Set the engine switch to the OFF position. 3. Close fuel valve. Note: Impeller will continue to rotate for several seconds after engine is stopped. -
Page 10: Troubleshooting Chart
To put the equipment into service after an extended period of storage. 1. Check for loose parts and tighten if necessary. 2. Fill the fuel tank and then check the engine oil level. Top off if necessary. See engine manual for details. 3. -
Page 11: Parts List
PARTS LIST 21 41 7 22 23 26 27 18 28 29 43 03 REF DESCRIPTION QTY REF DESCRIPTION 8“ Front wheel Flat washer 8 Block Large washer Universal Wheel Shaft Hexagonal bolts 5/16-24UNFx0.75 Flange Nut M8 Star grip handle Support Frame Large washer 8 Flange Bolt M8x45... - Page 12 B RA B E R EQ .CO M WGSALES@BRABEREQ.COM PHONE: 604-850-7770 FAX: 604-850-7774 TOLL FREE PHONE: 1-877-588-3311 TOLL FREE FAX: 1-800-665-7334 LB55 USER MANUAL...
