User Manual and
Installation Instructions
BARBECUE GAS GRILL
MODEL: Hampton
-USE OUTDOOR ONLY.
-READ THE INSTRUCTIONS BEFORE USING THE APPLIANCE
-WARNING: ACCESSIBLE PARTS MAY BE VERY HOT. KEEP YOUNG CHILDEN AWAY
-THIS APPLIANCE MUST BE KEPT AWAY FROM FLAMMABLE MATERIALS DURING USING.
-TURN OFF THE GAS SUPPLY AT THE GAS CYLINDER AFTER USING.
Advertisement
Table of Contents
Summary of Contents for Metalcraft Hampton
- Page 1 User Manual and Installation Instructions BARBECUE GAS GRILL MODEL: Hampton -USE OUTDOOR ONLY. -READ THE INSTRUCTIONS BEFORE USING THE APPLIANCE -WARNING: ACCESSIBLE PARTS MAY BE VERY HOT. KEEP YOUNG CHILDEN AWAY -THIS APPLIANCE MUST BE KEPT AWAY FROM FLAMMABLE MATERIALS DURING USING.
-
Page 2: Gas Category
PLEASE DO - Use spanner to tighten all gas fittings - Check all gas hose and line connection for damage, cuts or cracks each time for using the appliance. - Always leak test with soapy water - Check all burners regularly for insect nets such as spiders, ants, etc. Nets are dangerous and need to be fully cleaned. - Page 3 GAS HOSE AND GAS REGULATOR Use only regulator and hose approved for LP Gas at the correct pressures. The pressure adjuster should comply with the standard EN16129 and current regulations in the country where it is installed, which may be found at your nearest retailer of gas items. Refer to the technical date. It is strictly prohibited to use adjustable pressure It is recommended that the regulator is changed within 10 years of the date of manufacture or the national conditions require it.
-
Page 4: Lighting The Appliance
Before connecting, please ensure there is no debris caught in the head of the gas cylinder, regulator, burner and burner parts. If the hose is replaced, it must be secured to the appliance and regulator connections. After connecting, GAS LEAKGE CHECKING is a must. Please follow following method to check for gas leakage. - Ensure the control valve is “OFF”. -
Page 5: Clean And Maintenance
CLEAN AND MAINTENANCE All cleaning and maintenance should be carried out when the appliance is cool and with the fuel supply turned OFF at the gas cylinder after each time use. DO NOT mistake brown or black accumulation of grease and smoke for paint. Interiors of gas grills are not painted at the factory (and should NEVER be painted). - Page 6 10. Replace grease tray and cooking grates. Inspect burner for any damage (cracks or holes). If damage is found, replace with a new burner. Reinstall the burner, check to ensure that the Gas valve orifices are correctly positioned and secured inside the burner inlet. We suggest three ways to clean the burner tubes.
- Page 7 TECHNIAL INFORMTION Appliance Name Outdoor Use Gas Grill PIN CODE:0845CQ0139 Model No. Hampton Appliance Category I3+(28-30/37) I3B/P(30) Type of Gas Butane Propane Butane, Propane or their mixtures Gas Pressure 20-30mbar 37mbar 30mbar Heat input 3.8kW 3.8kW Heat Input (Qn) 277g/h...
-
Page 8: Assembly Instruction
ASSEMBLY INSTRUCTION 1. Standing feet assembly 2. Temperature gauge assembly... - Page 9 3. Cooking grid assembly 4. Pizza stone...
- Page 10 5. Grease tray 6. Way to remove the lid...
