Important! Read the instructions carefully before using the product. Save the instructions for future reference. If the instructions of use are lost, new ones can be found on the ARGO-HYTOS website www.argo-hytos.com. This is the original instruction manual number 19155 _1en_de_cz_05/2022, issued by the manufacturer: ARGO-HYTOS s.r.o.
8.7.2 Processing of set points 8.7.3 Solenoid current processing and outputs 8.7.4 Controller structure 8.8 Software block diagram Mode 3, valve with 2 solenoids and spool position feedback (EL8) 9. Functions 9.1 Display parameter 9.2 Output stages 9.3 Control circuits with feedback signal adjustment 9.3.1 Adjustment of the actual value signal Fb1...
Description Amplifier module Amplifier for proportional valves which has modular structure AH Hub Software tool provided by Argo-Hytos in order to adjust and parametrize EL8 units CANopen Bus interface for digital communication USB-C connector Connector type used on the USB interface...
This manual was prepared with great care and the contents reflect the author’s best knowledge. However, the possibility of error remains and improvements are possible. Please feel free to submit any comments regarding errors or possibly incomplete information to Argo-Hytos GmbH.
Liability for any content of this document is rejected! Any claims against Argo-Hytos GmbH – based on whatever legal reason – resulting from the use of the information, programs, engineering and performance data etc., described in this document shall be excluded.
The operation of other inductive or resistive loads is not recommended (motors, heaters, etc.). If you are considering any applications like this please contact Argo-Hytos GmbH. If used correctly, the safety of the user as well as the safe and proper function of the amplifier EL8 is given. 5.6 Non-intended product use The digital amplifier modules “EL8”...
5.8 Introduction The digital amplifier module EL8 features leading edge technology. This electronic device meets the industrial standards for EMC. This ensures a high interference security and low interference emission. The performance characteristics are possible through the use of the most current microprocessor technology (32 bit floating point CPU) combined with other state of the art components.
› all kinds of valves used in applications with process value feedback (e.g. cylinder position, pressure, velocity, rpm, etc.) For versions to be used in open loop applications please contact your distributor or Argo-Hytos GmbH for further information. 5.10 Software version attribution This manual is applicable for EL8 with software version V1.02* or higher!
PRL2 version Total number of variants: 12 / 24V DC; STD / PRL EL8-STD EL8-PRL (only with 24V coil!) Figure 3: Ordering Code 7. Installation 7.1 Mounting › Compare module type (refer to label on side of the module)
The information in this document is subject to change without notice. 7.2.3 EMC Devices EL8 series are class “A” equipment and therefore only suitable for industrial surroundings. The distance between a source of interference (device emitting interference) and an interference sink (a device under the influence of interference) is very important.
D-74549 Wolpertshausen Tel.: (+49) 7971 - 96810 Fax.: (+49) 7971 - 968150 Avoid under all circumstances to use logical signals from the module (i.e. “Error”) for switching machine safety WARNING circuits (refer also to EU standard EN13849)! Page 13 www.argo-hytos.com EL8_Instructions_Hinweise_Pokyny_19155_1en_de_cz_05/2022...
Page 14
› single chokes in the current path of the incoming and outgoing lines. These chokes are effective for symmetrical interferences and increase the impedance of the symmetrical interference circuit. Figure 5: EMC – interferences and remedies Page 14 www.argo-hytos.com EL8_Instructions_Hinweise_Pokyny_19155_1en_de_cz_05/2022...
Page 15
Shields of digital signal - or data transmission lines should be connected at both ends! Chassis of machine (symbolic) Figure 6: EMC – adequate design of switchgear cabinets and facilities Page 15 www.argo-hytos.com EL8_Instructions_Hinweise_Pokyny_19155_1en_de_cz_05/2022...
Setpoint, S1.06- / IN- X4/13 Power supply sensor 0V X4/14 Power supply sensor 24V X4/15 EL8 Supply 0V X4/16 EL8 Supply 24V Please pay attention to the correct polarity of the feedback connection! Table 9: Front elements Page 16 www.argo-hytos.com...
Interface USB-C Also for diagnosis function with oscilloscope built into AH Hub Figure 9: Front view of unit 8.2 Parameter setting Available parameters for version EL8: display Set point / ramps Controller Extended A complete list of parameters is available. Refer to: d1.01...
Only the mode relevant parameters are made available for each of the modes. Mode Description / Module Version Closed loop, 1 proportional valves with 2 solenoid and one valve feedback (version EL8-xxx) Table 11: Operation modes 8.4 Description of software program 8.4.1 General availability and assignment of parameters...
This enables to change the direction of a valve as well as the scaling of the set point signals. Scaling for the set point is in the range of 0.00 … ± 4.00. Page 19 www.argo-hytos.com EL8_Instructions_Hinweise_Pokyny_19155_1en_de_cz_05/2022...
If C1.00 = 3 or C1.00 = 4 (dff controller), than C1.13 is the amplification of the dff controller and C1.16 is the P-amplification of the remaining PT1-I-DT1 controllers. C1.15 will be without effect in these cases Page 20 www.argo-hytos.com EL8_Instructions_Hinweise_Pokyny_19155_1en_de_cz_05/2022...
› C1.18 is a D-portion and together with Cx.19 forms a PT1 term (differential controller). › C1.19 is a T-portion for Cx.18 to form a DT1 term. 8.4.15 Additional (P-) multiplier (C1.20) C1.20 › C1.20 additional proportional factor to increase the effect of C1.13 and C1.16, especially for process control. Page 21 www.argo-hytos.com EL8_Instructions_Hinweise_Pokyny_19155_1en_de_cz_05/2022...
Bring sensor signal to “center position” value (“zero posiiton”) Click 4 – wait for green checkmark Bring sensor signal to maximum “A” side Click 5 – wait for green checkmark Verify procedure Table 13: Semi-automatic feedback calibration procedure Page 22 www.argo-hytos.com EL8_Instructions_Hinweise_Pokyny_19155_1en_de_cz_05/2022...
It is always recommended to have a fuse (quick reacting, 3.15 A) in the + power supply line to the EL8. Error message in case of short circuits, overloads or open circuits is either “- - 3” or “- - 8”.
8.5.3 Operation mode (E00) This parameter is predetermined by selection of the module version. For modules version EL8 2-01 it is “1” and for modules version EL8 2-02 it is “2”. 8.5.4 Selection of set point (E15) This parameter is used in order to select the type of Analog set point. Either a voltage input (0 … ± 10 V) or a current input can be selected. If the current input is selected than the measuring resistance of 250 Ohm is automatically activated.
5 = 12 mA + -8 mA w/o cable fracture detection 6 = 12 mA + -8 mA with cable fracture detection 8.7.2 Processing of set points 8.7.3 Solenoid current processing and outputs 8.7.4 Controller structure Page 25 www.argo-hytos.com EL8_Instructions_Hinweise_Pokyny_19155_1en_de_cz_05/2022...
Through combination of hardware and software functions for the actual value adjustment guarantees highest resolution and precision. Therefore, the advantages to a system with analogous adjustment using potentiometers are obvious. Adjustment: CAUTION Activate the “enable” signal. If C1.09 = 10, 11 or 12, d1.11 will not show any values < 0.000. Page 28 www.argo-hytos.com EL8_Instructions_Hinweise_Pokyny_19155_1en_de_cz_05/2022...
By setting the threshold value of the comparator (C1.21 and C1.22) = 0, the “S1.01” input can be used directly to activate the controller. This allows to activate the controlling by to external factors. C1.23 does not have any function when the “switching controller” is activated. C1.24 can be used to delay controller activation Page 29 www.argo-hytos.com EL8_Instructions_Hinweise_Pokyny_19155_1en_de_cz_05/2022...
Wire break at the output stages Negative or overload current >22 mA sensor FB1 (Input Fb1) Negative or overload current >22 mA at input (Input S1.05) Negative or overload current >22 mA at input (Input S1.06) Table 20: Error list Page 30 www.argo-hytos.com EL8_Instructions_Hinweise_Pokyny_19155_1en_de_cz_05/2022...
11.2 Physical interface data The connection cable must the following conditions: › USB-C connector on the EL8 side › Depending on the PC the other side of the cable has to be selected (USB-A; USB-B or USB-C) 11.3 Parameterization Tool Figure 11 : Parameterization Tool screen After starting AH Hub the program can either be used “offline”...
Remark: The monitor also will display error codes and status of digital inputs. For further information about AH Hub please contact the manufacturer or any of our distributors and partners. 12 Complete parameter list Parameter list for version EL8-03-xxxx-S0 Display-Parameters: Function...
Page 33
Command signal hysteresis 0.001 -9.999 +9.999 C1.33 I-Portion output value limitation 0.001 0.000 +9.999 Sensor signal correction factor for 0.01 -1.00 +1.00 C1.36 values < 0 (related to C1.10) Table for linearization Adjustment of 8 individual points Page 33 www.argo-hytos.com EL8_Instructions_Hinweise_Pokyny_19155_1en_de_cz_05/2022...
