LWIR THERMAL IMAGER
INSTALLATION GUIDE
PUBLICATION N
814975
O
LANGUAGE: ENGLISH
ISSUE: 1
DATE: 07 DECEMBER 2021
Long Wavelength Infrared Thermal Imaging Camera
i
Q U A L I T Y C U S T O M E R S O L U T I O N S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LAND LWIR and is the answer not in the manual?

Questions and answers

Summary of Contents for Metek LAND LWIR

  • Page 1 LWIR THERMAL IMAGER INSTALLATION GUIDE PUBLICATION N 814975 LANGUAGE: ENGLISH ISSUE: 1 DATE: 07 DECEMBER 2021 Long Wavelength Infrared Thermal Imaging Camera Q U A L I T Y C U S T O M E R S O L U T I O N S...
  • Page 2 IMPORTANT INFORMATION - PLEASE READ Health and Safety Information Read all of the instructions in this booklet - including all the WARNINGS and CAUTIONS - before using this product. If there is any instruction which you do not understand, DO NOT USE THE PRODUCT.
  • Page 3 Contact Us UK - Dronfield USA - Pittsburgh Land Instruments International AMETEK Land, Inc. Tel: +44 (0) 1246 417691 Tel: +1 412 826 4444 China India AMETEK Land China Service AMETEK Land India Service Tel: +86 21 5868 5111 ext 122 Tel: +91 - 80 67823240 Email:...

  • Page 4: Table Of Contents

    LWIR Thermal Imaging Camera Contents Introduction Points to note on installation Using compressed air for air purging Specifications Nomenclature 2.2 Specification Table LED Status Indicators Electrical Connections 3.1 Connecting the mains input to the TRACO Power Supply Unit 3.2 Using an alternative Power Supply Unit Installation Diagrams Using the Web Server Interface 5.1 Connecting to the Web Server 5.2 About the Web Server Interface 5.3 About the Web Server Menu Settings Frame Settings 5.6 Regions of Interest (ROI) 5.7 Working with Regions of Interest (ROI)

  • Page 5: Introduction

    Thermal Imaging Camera LWIR INTRODUCTION This guide gives you information on how to install the LWIR thermal imaging camera and its installation accessories. These instructions are provided as a series of simple installation diagrams, covering the installation of the LWIR thermal camera and its mountings, accessories and services. The equipment must be used, maintained and serviced by properly trained personnel, capable of following the procedures given in these instructions. Safety may be impaired if the system is not used as indicated. It is important to check the equipment with which you have been supplied and then read these instructions thoroughly before proceeding with installation. 1.1 Points to note on installation • When choosing a location to install the LWIR thermal imaging camera, ensure that the camera has an unobstructed view of the target to be measured.

  • Page 6: Specifications

    LWIR Thermal Imaging Camera SPECIFICATIONS 2.1 Nomenclature The thermal imager detail label is on the rear face of the thermometer above the LAND logo label. Make a note of your thermometers instrument Type and Serial Number in the space provided below. Type: Serial Number: In the example in the table below, we examine the nomenclature for a thermal imager with an instrument type label which reads: TYPE: LWIR 640 0/500C 50 LF Example Description Options Meaning LWIR Series Name LWIR Long wavelength infrared Pixel Resolution 640 x 480 pixels 0/500C 0 to 500 °C 0/500C...

  • Page 7: Specification Table

    Thermal Imaging Camera LWIR 2.2 Specification Table Camera Unit Measurement Range: 0 to 500 °C / 32 to 932 °F 100 to 1000 °C / 212 to 1832 °F Pixel Resolution: 640 x 480 Pixel Size/ Pitch 17 μm Spectral Response: 8 to 14 μm Max Frame Rate: * 60 fps / 7.5 fps Detector: 640 x 480 Amorphous Silicon Optic (HFOV x VFOV):...

  • Page 8: Led Status Indicators

    LWIR Thermal Imaging Camera Thermal Imaging PSU Module (UL Approved) Components & Power supply, Gb Ethernet communications (switch)/PoE+ Connections: Fibre optic data connection (option) Environmental Rating: IP65 / NEMA 4 Size: 380 x 380 x 211 mm / 15 x 15 x 8.3 in Weight: 15 kg (33.1 lbs) UL Approval: Listed to UL508A & CSA-C22.2 No. File Number E499440 Image Processing Software: IMAGEPro and IMAGEViewer IMAGEPro Application (e.g Asset Monitor) Workstation:...

  • Page 9: Electrical Connections

    Thermal Imaging Camera LWIR ELECTRICAL CONNECTIONS The basic system electrical connections are as follows: • Mains input to the TRACO Power Supply Unit* • 24V output from TRACO Power Supply Unit* to the LWIR camera • Ethernet cable from LWIR Camera to the Process Imaging Workstation * The LWIR Camera can be powered by an alternative power supply, via cable Part Nº 806032 or Part Nº 806033 (See section 3.2). 3.1 Connecting the mains input to the TRACO Power Supply Unit The TRACO Power Supply Unit is supplied with a 3-pin AC input connector (Fig. 3-1). You will need to disassemble this connector to install the cable. Unscrew the cover from the mains Input on the Power Supply Unit. Fig. 3-1 The easiest way to disassemble the 3-pin AC input connector is to first screw the connector assembly onto the input socket...
  • Page 10 LWIR Thermal Imaging Camera Grip the rear section of the input connector and unscrew it from the Power Supply Unit (Fig. 3-3). Fig. 3-3 The connection terminals inside the input connector will now be revealed (Fig. 3-4). Unscrew the connector front section from the Power Supply Unit and disassemble the remaining parts of the connector. Slide the rear locking ring, gasket and shell body over the mains input cable. Fig. 3-4 Strip back the mains cable wires to the appropriate lengths and connect them to the Input connector terminals (Fig. 3-5) as per the wiring schedule below: Pin 1 = Live Pin 2 = Neutral Pin 3 = N/C E = Earth Fig.
  • Page 11 Thermal Imaging Camera LWIR Attach the mains cable to the Input connector of the Power Supply Unit (Fig. 3-7). You can now connect the TRACO Power Supply Unit to the LWIR camera via Interface PCB (Part Nº 807941). Refer to the Installation Diagrams in Section 4. Fig. 3-7 Installation Guide 3 - 3...

  • Page 12: Installation Diagrams

    LWIR Thermal Imaging Camera INSTALLATION DIAGRAMS This section of the Installation Guide provides a series of simple installation diagrams, covering the installation of the LWIR thermal camera and its mountings, accessories and services. 4 - 0 Installation Guide...

  • Page 29: Connecting To The Web Server

    Thermal Imaging Camera LWIR USING THE WEB SERVER INTERFACE 5.1 Connecting to the Web Server You can access the LWIR Web Server via a computer/device with Internet access that is on the network to which the LWIR thermal imaging camera is connected. The following web browsers are supported by the LWIR Web Server: • Google Chrome • Microsoft Edge • Mozilla Firefox Connection can be made either directly to the Ethernet port on the camera or via an Ethernet switch on the network. A simple connection overview is given in Fig. 5-1. Refer to the Installation Drawings (Section 4) for more details of network connections. Mains In Desktop PoE Power Supply Computer/Device running LWIR Web Server software LWIR Thermal Imager Fig. 5-1 Connecting to the Web Server Installation Guide 5 - 1...
  • Page 30 LWIR Thermal Imaging Camera 5.1.1 Network Adapter Settings To communicate with the LWIR thermal imaging camera, you need to specify the correct Network Adapter Settings on your computer/device. The instructions below apply to Windows 10 systems. If you have a different operating system, refer to the user guide/help files for your system. In your computer’s Type here to search box (bottom left of screen), type Network Connections. The Network Connections window displays details of each network to which your computer is connected.

  • Page 31: About The Web Server Interface

    Thermal Imaging Camera LWIR 5.2 About the Web Server Interface A typical Web Server Interface is show in Fig. 5-2. Fig. 5-2 Typical Web Server Interface Item Description Thermal image (live image from LWIR) IP Address of Web Server Frame settings summary details Regions of Interest (ROI) controls and summary details. Up to three ROIs are available. See sections 5.6 and 5.7. LWIR camera summary details Web Server menu. See section 5.3 Colour/Greyscale of temperature range (Palette). Choice of six Palettes available. Temperature measurement span (user-adjustable). Upper and lower limits can be set to any points within measurement range of LWIR. Full screen ON/OFF control Save Camera Settings. Allows you to save any changes to the settings of the LWIR Thermal Imager. Load Camera Settings. Allows you to upload previously saved settings into the LWIR Thermal Imager. 5.2.1 Web Server Interface Password The Password prompt will appear whenever: Any Settings button other than the Info button is pressed, or •...

  • Page 32: About The Web Server Menu

    LWIR Thermal Imaging Camera 5.3 About the Web Server Menu The Web Server menu buttons are explained in the table below. Item Description Settings - opens the camera settings options, which allow you to Focus the camera in/out, perform a non-uniform correction (NUC) on the camera, select the Unit of temperature measurement, and change the system Password. For more information see Section 5.4. Frame Settings - allows you to set the Emissivity, Background Temperature, and any Time Function to be used in temperature measurement for the entire thermal image. For more information see Section 5.5. Regions of Interest (ROI) - you can create up to three Regions of Interest (ROI) on the thermal image. For each ROI you can specify the Emissivity, Background Temperature, Temperature Threshold, and any Time...

  • Page 33: Frame Settings

    Thermal Imaging Camera LWIR 5.5 Frame Settings Frame Settings are applied to the entire area covered by the thermal image. To use different settings for individual areas, you can set up Regions of Interest (ROI). For details of ROI refer to Section 5.6. The following options are available in the Frame Settings menu. Item Description Emissivity To measure temperature correctly with an infrared camera, the Emissivity of the target must be known. You can select a Source for the Emissivity: • Manual - If you know the Emissivity of the area covered by the thermal image, use the slider to set the required value, or type it into the text-input box. • mA In - with this option, you can use a current loop input to set the emissivity value, where: 4 mA = 0.10 and 20 mA = 1.00 For more information on Emissivity, visit www.ametek-land.com. Background The temperature of the area surrounding an object being measured Temperature can have an effect on the temperature value calculated by the thermal imaging camera e.g. if an object is inside a heated chamber or furnace, the temperature of the furnace wall will affect the reading. You can select a Source for the Emissivity: •...

  • Page 34: Regions Of Interest (Roi)

    LWIR Thermal Imaging Camera 5.6 Regions of Interest (ROI) Regions of Interest (ROI) allow you to create up to three areas within the thermal image and apply individual measurement settings to each one. The settings applied to an ROI will override any settings specified in the Frame Settings. The following options are available for each ROI. Item Description Emissivity To measure temperature correctly with an infrared camera, the Emissivity of the target must be known. If you know the Emissivity of the area covered by an ROI, use the slider to set the required value, or type it into the text-input box. For more information on Emissivity, visit www.ametek-land.com. Background The temperature of the area surrounding an object being measured Temperature can have an effect on the temperature value calculated by the thermal imaging camera e.g. if an object is inside a heated chamber or furnace, the temperature of the furnace wall will affect the reading. You can use the Background Temperature setting to input this temperature value which will be taken into account when calculating the actual temperature of the target in the ROI.

  • Page 35: Working With Regions Of Interest (Roi)

    Thermal Imaging Camera LWIR 5.7 Working with Regions of Interest (ROI) You can create up to three areas within the thermal image and apply individual measurement settings to each one. Creating an ROI To create an ROI, click on the required ROI information panel to the left of the Web Server thermal. The ROI information panel is highlighted and the ROI is displayed on the thermal image in the same colour as the Information panel border. On the thermal image, click and drag the mouse pointer to create a rectangle in the location where you want the ROI to be. The ROI details are updated to show the co-ordinates and size of the ROI. To help see the ROI, use the colour swatch controls to select a colour for the ROI that contrasts against the thermal image.
  • Page 36 LWIR Thermal Imaging Camera Showing and Hiding an ROI When an ROI is active, a box the same colour as the ROI is displayed around the ROI information panel to the left of the thermal image. To hide the ROI, click on its information panel. The ROI disappears from the thermal image and information panel is greyed-out. To activate the ROI, simply click on its information panel again. Note: The ROI will still function in the thermal imaging camera, but will not shown in the Web Server. ROI Settings To adjust the settings of an ROI, click on the required ROI numbered button in the Web Server menu, to the right of the thermal image. The ROI settings are displayed. You can adjust the colour of the ROI by clicking on the colour swatch and selecting the required colour from the palette. To set the Emissivity of the area covered by the ROI, you can either select a Manual input and type in the required Emissivity value (or set it via the slider), or you can...

  • Page 37: I/O

    Thermal Imaging Camera LWIR Time Function - this option allows you to select an Input value from the ROI - either the Min, Max, Mean or >% (Percentage above Threshold) and apply a time function to it. The time functions available are Average, Peak Picker or Sample and Hold. F or more information on Time Functions, see Section 5.11. 5.8 I/O You can use the Web Server to set up and control up to three outputs, or two outputs and one input for the LWIR thermal imaging camera. A typical I/O interface is shown in Fig. 5-3. Fig. 5-3 Typical Web I/O Interface The interface also shows the pin connections for the outputs/ inputs on the LWIR cable connector. The following outputs/inputs are available: • Output 1 - 0 to 20 mA or 4 to 20 mA current output; • Output 2 - 0 to 20 mA or 4 to 20 mA current output or Relay output; Input/Output 3 - 0 to 20 mA current input or Relay output or Command input. •...
  • Page 38 LWIR Thermal Imaging Camera Output 2 For Output 2, the mA Out settings are identical in operation to those of Output 1. For the Relay settings, use the drop-down boxes to select the source of the output e.g. ROI 1, and the type of output required e.g. Maximum temperature. Use the text input field or the slider bars to set the upper and lower limits for this setting For example, for ROI 1 you could set the Maximum Temperature to activate the relay output if it goes outside the range 600 °C to 750 °C. You can specify multiple triggers for the relay by simply clicking on the Add button. For a relay output with multiple triggers, if the Alarm logic control is set to OR, the relay is triggered when at least one of the alarm conditions is met.
  • Page 39 Thermal Imaging Camera LWIR Input/Output 3 For mA In, use the drop-down boxes and text input fields to the set the required values for this input. For example, you could set a Background Temperature input for ROI 1 where 4 mA corresponds to 0 °C and 20 mA corresponds to 50 °C. For Input/Output 3, the Relay settings are identical in operation to those of Output 2. The options available for the Command input (Cmd In) for Input/Output 3 each relate to the LWIR Camera and are as follows: •...

  • Page 40: Selecting A Colour Palette

    LWIR Thermal Imaging Camera 5.9 Selecting a Colour Palette The LWIR Web Server has a range of colour/greyscale palettes available. You can select which colour/greyscale give you the best results for your particular application. To select a palette, click on the colour/greyscale to the right of the thermal image. A pop-up window displays the range of available palettes. Click on the required palette to activate it. The thermal image is displayed using the new palette. 5.10 Adjusting the Temperature Span By default, the LWIR Web Server colour/greyscale palette covers the entire temperature range of your LWIR Thermal Imaging Camera - either 0 to 500°C, or 100 to 1000 °C. However, your application may have temperatures which are well within these lower and upper limits. You can adjust the temperature measurement span limits as follows: On the grey vertical bar to the left of the palette, drag the upper and lower temperature limit setting boxes to match the temperature span you want to measure e.g. 200 to 400 °C. The values displayed at the top and bottom of the palette are adjusted to match your span settings, and the thermal image will be updated to use these values.

  • Page 41: Time Function Processing

    Thermal Imaging Camera LWIR 5.11 Time Function Processing The LWIR Web Server software contains a number of Time Function algorithms which help deliver a more consistent temperature reading from a sometimes noisy, changeable reading from the LWIR thermal imager. The following sections help you choose and configure the time function most appropriate for your application. 5.11.1 None The Web Server will display the raw output from the LWIR thermal imaging camera. 5.11.2 Averager Refer to Fig. 4-2. The Averager time function can be used to ‘smooth’ the temperature output signal in relation to the temperature input. The Averager response can be adjusted to suit your application. With a fast response speed, the temperature output signal tracks the input signal closely, any rapid fluctuations in the input are reflected in the output. With a slow response speed, the temperature output signal is much smoother, displaying more the ‘trend’ of the input signal rather than rapid changes. Fast averager response speed Slow averager response speed Time Fig. 5-4 Graphical representation of the Averager time function Installation Guide 5 - 13...
  • Page 42 LWIR Thermal Imaging Camera 5.11.3 Peak Picker The Peak Picker function can be used to monitor the highest temperature measured in the thermal image (or ROI). This feature is useful especially for moving targets and/or where the target is obscured partially e.g. a steel slab on a rolling mill where parts of the surface are covered with scale. The ‘clean’ area will be at the higher (i.e. true) temperature. The Peak Picker used in the LWIR Web Server processors has the following features. Threshold level Temperature above which the Peak Picker is active, used in conjunction with the ON and OFF delay. ON delay Time period between the temperature rising above the threshold level and the Peak Picker function switching on. OFF delay Time period between the temperature falling below the threshold level and the Peak Picker function switching off. In ‘Hold’ mode, at the end of the ‘OFF’ delay, the temperature output value is held constant until the temperature input next rises above the threshold level. In ‘Reset’ mode, at the end of the ‘OFF’ delay, the temperature output signal falls to ‘under-range’ until the temperature input next rises above the threshold level. In ‘Sample’ mode the peak picker samples for a pre-defined period, then outputs this value. Decay rate A user-adjustable value at which the stored temperature output signal decays. The Peak Picker function can be reset via the CMD (Command) input.
  • Page 43 Thermal Imaging Camera LWIR 5.11.4 Sample and Hold Time Sample Hold Sample Hold Command Command signal = Closure of potential-free contacts, s/c = Hold TTL level (0 to 5V) +5V = Track or 0 to 24V +24V = Track 0V = Hold Fig. 5-6 Graphical representation of Sample and Hold time function Refer to Fig. 5-6. The Sample and Hold time function is useful especially for measuring intermittent processes e.g. items on a conveyor belt. The presence...

  • Page 44: Spares & Accessories

    LWIR Thermal Imaging Camera SPARES & ACCESSORIES 6.1 Standard Power Supplies Description Part Nº Thermal Imaging Power Supply (UL Approved) 813478 Thermal Imaging Power Supply PoE+ (UL Approved) 815177 Process Imager Power Supply 805753 Process Imager PSU Mains Power Connector 805755 DIN Rail Mounted 24V PSU 404.156 6.2 Power over Ethernet (PoE) Power Supplies Description Part Nº DIN Rail Mounted 24V PSU and PoE Switch Assembly 815153 DIN Rail PSU, Interface PCB and Ethernet Switch 815180 Desktop PoE Power Supply 805024 6.3 Power I/O Cables Standard Temperature Cables Camera to DIN Rail PSU/Connection PCB/Thermal Imaging PSU...

  • Page 45: Communications/Poe Cables

    Thermal Imaging Camera LWIR Camera to Process Imager PSU only Description Part Nº 5 m Imager to Power Cable with 2 x Connectors 815154 Standard temperature 20 m Imager to Power Cable with 2 x Connectors 815155 Standard temperature 50 m Imager to Power Cable with 2x Connectors 815156 Standard temperature 6.4 Communications/PoE Cables Camera to Thermal Imaging PSU only Description Part Nº 25 m M12 to M12 communication cable 2 x Connectors 810794 Standard temperature...

  • Page 46: Housings And Accessories

    LWIR Thermal Imaging Camera 6.5 Housings and Accessories Description Part Nº LWIR/MWIR Industrial Jacket 815150 LWIR/MWIR Industrial Air Purge 815126 LWIR/MWIR Industrial Back cap 815121 LWIR/MWIR Industrial Housing 815120 Industrial Mounting Pan and tilt assembly 813472 Industrial Mounting Splash protection plate 813479 Suitable for use with cameras with Horizontal FOV 11 or 6 deg Industrial Mounting Splash protection plate 814876 Suitable for use with cameras with Horizontal FOV 50 or 28 deg LWIR-640 light housing with purge 815130 Light Housing - Provides basic protection of the camera with an air purge to keep the lens clean. A prewired connection PCB is located inside the housing for making terminal connections. Pan and tilt bracket assembly 806761 For mounting camera only (without protective housings) Wall bracket assembly...
  • Page 48 LWIR HIGH PRECISION LONG WAVELENGTH THERMAL IMAGING CAMERA CONTACT US www.ametek-land.com land.enquiry@ametek.com AMETEK Land’s AMECare Performance Services ensure peak performance and maximum return on investment over the life of your equipment. We deliver this by: • Proactively maintaining your equipment to maximize availability. •...
