Summary of Contents for GatesAir Intraplex IP Link 100e
- Page 1 IP Link 100e Audio over IP Card For FAX Compact Series Transmitter 888-2944-001 Revision A Oct 2021...
-
Page 2: Publication Information
Except for making a reasonable number of copies for your own internal use, you may not reproduce this publication, or any part thereof, in any form, by any method, for any purpose, or in any language other than English without the written consent of GatesAir. All others uses are illegal. - Page 3 Intraplex ® IP Link 100e Quick Start Guide v1.0 ® Intraplex IP Link 100e Quick Start Guide Figure 2. Flexiva Modulator Board 4. From the back of the transmitter remove the 3 screws securing the bottom-most knock out panel. Keep these screws as they will be used in ®...
- Page 4 Intraplex ® IP Link 100e Quick Start Guide v1.0 6. (If other cards are installed) For 8. Install supplied cables as shown those customers with an Orban below (Figure 7). processor or Exgine card installed you will not see empty standoffs. Remove the two screws shown in Figure 5 that hold the top card onto the standoffs below.
- Page 5 Intraplex ® IP Link 100e Quick Start Guide v1.0 6. Click to add a user to the 1. After the page loads, the 100e login system. The Add User Account page appears (Figure 9). window appears (Figure 12). Figure 12. Add User Account Figure 9.
- Page 6 Intraplex ® IP Link 100e Quick Start Guide v1.0 4. Click OK to reset the system and 4. Click on the active network interface load the IP Link 100e Software. to bring up its settings. 5. Either enable DHCP or disable DHCP to set a static IP Address and Subnet Mask for the connected network.
- Page 7 Intraplex ® IP Link 100e Quick Start Guide v1.0 the input and output channel settings. 4. To begin streaming, right-click the You can change the sample rate and stream and click Connect. The channel sources. stream will turn green if connected to a receiving stream and working properly.
- Page 8 Not Used Additional Help GPIO Pin Assignments If you have questions or any difficulties installing or configuring your Ascent system, please call or send non- emergency email to GatesAir Customer Support: • U.S., Canada, and Latin America: • 1-217-222-8200 or tsupport@gatesair.com...
