AE-48100 Lithium Battery Module User Manual Safety Precautions Warning Please do not put the battery into water or fire, in case of explosion or any other situation that might endanger your life. Please connect wires properly while installation, do not reverse connect.
Preface Manual declaration AE-48100 Lithium-iron phosphate battery energy storage system can provide energy storage for photovoltaic power generation users through parallel combination. Our product can store extra electricity into battery from photovoltaic power generation system in daytime and supply stable power to user’s equipment as power backup at nighttime or any time when needed.
AE-48100 Lithium-iron phosphate battery system is a standard battery system unit, customers can choose a certain number of AE-48100 according to their needs, by connecting parallel to form a larger capacity battery pack, to meet the user’s long-term power supply needs. The product is especially suitable for energy storage applications with limited installation space, long power backup time and long service life.
Page 8
AE-48100 Lithium Battery Module User Manual Figure 1-1 Battery Energy Storage System nameplate Figure 1-2 Battery Energy Storage System Warning Label Battery voltage is higher than safe voltage, direct contact with electric shock hazard. Be careful with your actions and be aware of the dangers.
AE-48100 Lithium Battery Module User Manual Figure 2-1 Panel Interface Definition Table 2-3 Interface Definition Item Name Definition Power Switch OFF/ON, remains ON when using Green light. When power switch is in “on”, it is Power Light normally on. When power switch is in “off”, it is off.
AE-48100 Lithium Battery Module User Manual Address DIP switch position 2.3.2 Communication port definition and description Table 2-5 Communication Definition RS232 Communication Port Foot position Definition RS485/CAN Communication Port...
Page 12
AE-48100 Lithium Battery Module User Manual Foot position Definition Foot position Definition RS485-B 9/10/11/14/16 RS485-A CANL CANH RS485/RS485 Communication Port Foot position Definition Foot position Definition RS485-B 9/16 RS485-B RS485-A 10/15 RS485-A 11/14 12/13 2.3.3 LED indicator description Table 2-6 LED Status Indicator...
Page 13
AE-48100 Lithium Battery Module User Manual Over- voltage Protecti Over- tempera ture/Un rgin der- Stop tempera charging ture/Ove r-current Protecti Normal Flash3 Display according to SOC Warning Flash3 Flash3 Under- Stop voltage dischargi Protecti Over- tempera rgin ture/Un der- tempera...
AE-48100 Lithium Battery Module User Manual discharging, the over-discharging protection is activated, and the battery buzzer makes an alarm sound. Then battery system stops supplying power to the outside. When the voltage of each cell back to rated return range, the protection is over.
Page 16
AE-48100 Lithium Battery Module User Manual If a short circuit occurs, the system starts short-circuit protection. It will recover after 60s if unload. It won’t recover, if it still loaded. Self-Shutdown: When device connects no charge and discharge and no external communication for over 48 hours, device will dormant standby automatically.
AE-48100 Lithium Battery Module User Manual 3 Installation and Configuration 3.1 Preparation for installation Safety Requirement This system can only be installed by personnel who have been trained in the power supply system and have sufficient knowledge of the power system.
AE-48100 Lithium Battery Module User Manual Operating environment: Indoor installation, sites avoid the sun, dry and natural ventilation, no conductive dust and corrosive gas. No water is allowed. And the following conditions are met: Install location should be away from the sea to avoid brine and high humidity environment.
AE-48100 Lithium Battery Module User Manual Confirm whether the user’s PV power generation equipment, power supply or other power supply equipment has a DC output interface, and measure whether the DC power output voltage meets the voltage range requirements in Table 2-2.
3.2.1 Installation preparation Prepare equipment and tools for installation. Check the AE-48100 unit and confirm that the ON/OFF switch is in the “OFF” state to ensure the device is shut off. 3.2.2 Mechanical coordination Installation method 1: With battery cabinet installation 1.
Page 22
AE-48100 Lithium Battery Module User Manual reference only) Figure3-2 2. Secure the AE-48100 unit to the cabinet with a nut through the mounting holes top on the hanging ears of the AE-48100 unit. Figure3-3 Installation method 2: With simple bracket installation 1.
AE-48100 Lithium Battery Module User Manual Figure3-6 4. Stack the required number of battery and bracket combinations as described above. Figure3-7 3.2.3 Electrical installation Before connecting the power cables, use multimeter to cable continuity, short circuit, confirm positive and negative, and accurately mark the cable labels.
AE-48100 Lithium Battery Module User Manual Figure 3-8 Wiring Diagram Note: After the whole system connection, set the master DIP and slave DIP according to Table 2-4. The communication cable to inverter is from inverter communication port to master CAN port, communication parallel cable is from master RS485 port to slave RS485 port or from slave RS485 port to slave RS485 port.
Page 25
AE-48100 Lithium Battery Module User Manual Shut Down (cut off) SOC: 20% Max Charge Current: 75A*battery QTY Max Discharge Current: 75A*battery QTY...
AE-48100 Lithium Battery Module User Manual 4 Use, maintenance and troubleshooting 4.1 Battery system usage and operation instructions After completing the electrical installation, follow these steps to start the battery system. Refer to the description of the DIP switch of Table 2-4 to prepare the battery module before starting up, the press the ON/OFF button to the ON position.
AE-48100 Lithium Battery Module User Manual through the working status indicator on the front panel of the AE-48100. The BMS can query the specific alarm categories. Table 4-1 Main Alarm and Protection Status Alarm category Alarm indication Processing Power indicator light, run...
Page 28
AE-48100 Lithium Battery Module User Manual ALM light RED the short circuit The DIP setting of the master is wrong/ The battery type of the inverter is wrong/ Communication cable used incorrectly/ The communication Check these possible Communication fault cable is incorrectly connected at...
Page 29
AE-48100 Lithium Battery Module User Manual ALENA ENERGY TECHNOLOGY CO., LTD Address: 2G Nguyen Thanh Y street, Da Kao ward, District 1, Ho Chi Minh city, Vietnam TEL: +84 (28) 39 26 26 83 Email: sales@alena-energy.com Website: https://alena-energy.com...
