DANGER
If you smell gas:
1.
Shut off gas to the appliance.
2.
Extinguish any open flame.
3.
If odor continues, keep away from the
appliance and immediately call your gas
supplier or fire department.
WARNING
Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
An LP-cylinder not connected for use shall
not be stored in the vicinity of this or any
other appliance.
WARNING
Improper installation, adjustment, alteration,
service or maintenance can cause property
damage, injury or death. Read the
installation, operating and maintenance
instructions thoroughly before installing or
servicing this equipment.
WARNING
For outdoor use only.
Customer Service Hotline
1-866-994-6390
DO NOT RETURN YOUR PATIO
HEATER TO THE STORE
Before visiting your local retailer, call our customer service
department at 1-866-994-6390 from 9:00 am
to 5:00 pm Eastern time, Monday through Friday
or email us at consumercare@thefulhamgroup.com.
CALIFORNIA PROPOSITION 65 WARNING:
•
WARNING: This product may expose you to
chemicals including Carbon Monoxide- a
by-product of combustion of this product-
which is known to the State of California to
cause birth defects or other reproductive
harm. Incorrectly installed, maintained, and
inadequately ventilated heaters can cause
exposure to carbon monoxide. For more
information go to www.P65Warnings.ca.gov.
PORTABLE PROPANE
TABLETOP HEATER
Model NO: COH-500
CARBON MONOXIDE HAZARD
DANGER
This appliance can produce
carbon monoxide which
has no odor. Using it in an
enclosed space can kill you.
Never use this appliance in
an enclosed space such as a
camper, tent, car, or home.
Advertisement
Table of Contents
Summary of Contents for Cuisinart COH-500
- Page 1 PORTABLE PROPANE TABLETOP HEATER Model NO: COH-500 DANGER If you smell gas: Shut off gas to the appliance. Extinguish any open flame. If odor continues, keep away from the appliance and immediately call your gas supplier or fire department. WARNING Do not store or use gasoline or other flammable vapors and liquids in the vicinity...
-
Page 2: Product Specifications
TABLE OF CONTENTS Product Specification - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Safety Information - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Package Contents... -
Page 3: Safety Information
SAFETY INFORMATION DANGER: For your safety, if you smell gas: 1) Shut off gas to the appliance. 2) Extinguish any open flame. 3) If odor continues, keep away from the appliance and immediately call your gas supplier or fire department. WARNING: Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. -
Page 4: Explosion - Fire Hazard
SAFETY INFORMATION DANGER: EXPLOSION - FIRE HAZARD • Keep solid combustibles, such as building materials, paper or cardboard, a safe distance away from the heater as recommended by the instructions. • Provide adequate clearances around air openings into the combustion chamber. •... - Page 5 SAFETY INFORMATION WARNING: We cannot foresee every use which may be made of our heaters. Check with your local fire safety authority if you have questions about heater use. Other standards govern the use of fuel gases and heat producing products for specific uses. Your local authorities can advise you about these.
- Page 6 SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate or install the product. 1. The installation must conform with local codes or, in the absence of local codes, with the National Fuel Gas Code, ANSI Z223.1 /NFPA 54, Natural Gas and Propane Installation Code, CSA B149.1, or Propane Storage and Handling Code, B149.2.
- Page 7 SAFETY INFORMATION 15. Keep the ventilation opening(s) of the cylinder enclosure free and clear from debris. Use this appliance in a well-ventilated space only. Do not use it in a building, garage, or any other enclosed area. Use this appliance in outdoor areas described below: (a) With walls on all sides, but at least one permanent opening at ground level and no overhead cover.
-
Page 8: Package Contents
PACKAGE CONTENTS Part Description Quantity Dome 2 pcs Wire Guard 1 pc Emitter 1 pc Burner Assembly 1 pc Tank Housing 1 pc Base 1 pc... -
Page 9: Hardware Contents
HARDWARE CONTENTS HARDWARE DESCRIPTION (x8) M4 x 10 mm Screw (x3) ST M4X 8 Screw Reflector Spacer (x4) M5 Acorn Nut (x4) M5 x 8 mm Screw (x4) M5 Nut (x4) -
Page 10: Assembly Preparation
ASSEMBLY PREPARATION Before beginning assembly of product, make sure all parts are present. Use caution when removing the protective film. Recommended to wear gloves when assembling and handling loose parts. Compare parts with package contents list and diagram on page 5. If any part is missing or damaged, do not attempt to assemble the product. - Page 11 ASSEMBLY INSTRUCTIONS STEP 3 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Attach the Emitter Screen (C) to the Burner Assembly (D) using M4 x 10 mm Screws (AA).
- Page 12 ASSEMBLY INSTRUCTIONS STEP 5 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Lower the Guard (B) over the Emitter Screen (C) and insert the feet of the Guard into the holes near the edge of the Burner.
- Page 13 ASSEMBLY INSTRUCTIONS STEP 7 - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - Attach the dome assembly to the Burner Assembly by securing M5 Acorn Nuts (DD) to the Reflector Spacers (CC), tighten with a wrench.
- Page 14 ASSEMBLY INSTRUCTIONS Gas Tank Assembly • You must provide propane gas and propane cylinder. • Use a standard 1.02 lb. propane cylinder only. • Can be used with a 20 lb. propane tank for longer performance. This requires a tank conversion hose, sold separately (LP Adapter Hose SKU QG-012B).
-
Page 15: Safety Check
SAFETY CHECK Checking for Leaks Your table top patio heater has been checked at all factory connections for leakage. When using a conversion hose (not included) and a 20 lb. tank, check the connection at the gas hose/ regulator/cylinder: a. Make leakage solution by mixing 1part liquid dish soap and 3 part water. -
Page 16: Care And Maintenance
OPERATION INSTRUCTIONS For complete shutdown 1. Please turn the knob to LOW first, then push and turn to OFF for complete shut off. 2. Turn the gas tank off completely (Remove the 1lb tank from unit). 3. If you experience any ignition problem, turn off the heater and gas supply, and consult “Troubleshooting”... - Page 17 CARE AND MAINTENANCE • Check heater immediately if any of the following conditions exist: a. The smell of gas in conjunction with extreme yellow tipping of burner flames. b. Heater does not reach proper temperature. c. Heater’s glow is excessively uneven. d.
-
Page 18: Troubleshooting
TROUBLESHOOTING Problem Possible Cause Corrective Action Burner won’t light. the tank. position. replace the tank. blocked. 40°F and tank is less than 1/4 full. Carbon build-up. Thick black smoke. burner inside and outside. -
Page 19: Replacement Parts List
REPLACEMENT PARTS LIST Part Description Part # Dome Wire Guard Emitter Burner Assembly Knob Tank Hosing Base... -
Page 20: Warranty
This warranty gives you specific legal rights, and you may also have the other rights that vary from state to state. For troubleshooting, FAQs or customer service, visit us at www.cuisinart.com/outdoorgrilling, call us at 1-866-994-6390 or email us at consumercare@thefulhamgroup.com Model # COH-500...
