Full extension ball bearing drawer slide
Coulisse de tiroir à billes pleine extension
Corredizo de billas y plena extensión para cajones
Package contents:
• 1 pair of slides
Contenu de cet emballage:
• 1 paire de coulisses
Contenido de este paquete:
• 1 par de corredizos
9997
Full extension
Pleine extension
Plena extensión
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Onward 9997
- Page 1 9997 Full extension ball bearing drawer slide Coulisse de tiroir à billes pleine extension Corredizo de billas y plena extensión para cajones Full extension Pleine extension Plena extensión Package contents: • 1 pair of slides Contenu de cet emballage: • 1 paire de coulisses Contenido de este paquete: •...
- Page 2 INSTALLATION Mounting into frameless cabinets 1. Separate slide members by depressing the lever release 2. Install large cabinet members as shown in Fig. 1. 3. Check that both cabinet members are vertically and horizontally parallel. Make necessary adjustments. 4. Install drawer member as shown in Fig.2 through vertical slots. Adjust position and install two more screws in round holes.
