SolarBase Low Ballast Flat Roof System Installation Guide V 1.4 NO.:PZ30-IM01-14 Last Updated - Mar. 2022...
Page 2
Installation Guide /SolarBase Low Ballast Flat Roof System Introduction PVezRack® SolarBase system is a roof mounting system suitable for small and medium-sized commercial roof List of contents installations. Professional structure design greatly simplifies installation steps, under the premise of Introduction guaranteeing safety, which reduces cost and improves Tools &...
Page 3
Installation Guide / SolarBase Low Ballast Flat Roof System Tools and Components Tools 6mm inside Electric tool 5m tape Marking pen Torque spanner hexagonal spanner String Socket spanner Note: tools in the figure are only used for rack system (not included in supply scope); Consult system installation personnel about electronic part installation tools.
Page 4
Installation Guide /SolarBase Low Ballast Flat Roof System System Overview Overview of PV-ezRack SolarBase 1. Support Leg 2. Ballast Bar 3. Module Clamp 40 mm 4. Wind Deflector 5. Grounding Lug - System Overview - Installation Guide V 1.4 - NO.:PZ30-IM01-14...
Page 5
Installation Guide / SolarBase Low Ballast Flat Roof System Installation planning Note: Red circles highlight installation of Module Clamp 40; Take 1650x990x40 PV module as an example. Installation angle is 10° and distance between front and rear parts of component is 532mm.
Page 6
As a result, major components of the Clenergy PVezRack® SolarBase may be provided in section sizes and lengths that vary from those shown in this guide. The installation process detailed in this instruction guide remains the same regardless of the component size.
Page 7
Installation Guide / SolarBase Low Ballast Flat Roof System Installation Instructions Install Support Leg team According to specification of ballast, According to specification of ballast, adjust distance adjust distance between both square between two square neck bolts on Support Leg and fix neck bolts.
Page 8
Installation Guide /SolarBase Low Ballast Flat Roof System Install Wind Deflector and ballast (optional parts) Fix Wind Deflector on the pre-assembled bolts of Support Leg team and make it press against Support Leg, and make sure the position of Support Leg team unchanged as Figure 4 shown in Figure 4.
Page 9
Installation Guide / SolarBase Low Ballast Flat Roof System Install PV modules and Module Clamp 40 Rotate the right part of Support Leg to the required position as shown in Figure 10. Figure 10 Place PV module smoothly on Support Leg. According to...
Page 10
Installation Guide /SolarBase Low Ballast Flat Roof System Adjust Module Frame Back Mounting Clip along fore-aft direction; ensure the frame of PV module will be held by Mounting Clip as shown in Figure 16 and 17. Fasten Bolts M8*35 and Square Neck Bolts M8*45 tightly in order.
