Quick Setup Guide

Congratulations on the purchase of your new Samsung TV.
Read this setup guide to get your TV up and running quickly.
1-800-SAMSUNG (1-800-726-7864)
STOP
Samsung Electronics America, Inc.
85 Challenger Road Ridgefield Park, NJ 07660-2112
Please do not return this unit.
Samsung Electronics Canada Inc.
55 Standish Court Mississauga, Ontario L5R 4B2
If you have problems operating your
Call Center hours of operation: Mon-Sun, 9:00 AM -12
TV, call:
AM EST.
1-800-SAMSUNG (1-800-726-7864)
To register this product, visit: www.samsung.com/
For web support please visit:
register.
www.samsung.com/support
Step 1
: Install the Stand
Follow the steps below to connect the TV to the stand.
✎
NOTE
x
Make sure to distinguish between the front and back of the Stand and
Guide Stand when assembling them.
x
Make sure that at least two persons lift and move the LED TV.
x
Stand the product up and fasten the screws. If you fasten the screws with
the LED TV placed down, it may lean to one side.
UN19C4000, UN22C4000, UN22C4010
1
Insert the stand body into the stand
base.
2 3
Screw the stand base to the stand Slide the TV onto the stand
body. body.
UN26C4000
Screws (M4 X L12)
1 Guide Stand
Connect the Guide Stand to the
Stand
Stand using four screws (M4 X
L12) as shown
Rear
3
2
Fasten three screws (M4 X L8) at
With your TV upright, connect the position 1, and then fasten three
TV to the Stand as shown. screws (M4 X L8) at position 2.
2
Front
1
Rear
Step 2
: Connect Antenna or Cable
VHF/UHF Antenna
Antenna Cable (Not Supplied)
or
Use a 75 ohm (round) cable.
Make sure the AC power cord is plugged in securely to
the wall outlet and the TV.
Step 4
: Run Plug & Play
When you turn on your TV for the first time, it automatically launches the Plug &
Play function. With Plug & Play, you can select the On Screen Display language,
set the clock mode, and launch the TV's channel memorizing process.
It also displays connection instructions similar to those in this guide.
To navigate while Plug & Play is running, press the Up, Down, Left or Right arrow
buttons on your remote. To make a selection, press the ENTERE button.
To skip a screen, press the button. To turn on your TV, press the
MENU
button on the remote or on the TV. To run Plug & Play, follow these steps:
1
Using your remote control, select
the language for the On Screen
Select Language of the OSD.
Display (OSD), and then press the
ENTERE button.
Menu Language
2
Select Home Use, and then
press the ENTERE button. If
you select Store Demo, the TV
will reset your picture and audio
Anrenna Source
settings every 30 minutes.
Digital Cable System
3
Analog Cable System
Select Antenna Source to
memorize. If Antenna Source is
Cable or Auto, you must select
your cable system type. After
selecting source, select Search; then press the ENTERE button on your
remote.
✎
Most cable systems are Standard (STD) systems, If you are not sure about
what kind of cable system you have, contact your cable company.
✎
If your TV is attached to a cable or satellite box, skip Steps 3 through 5. After
Plug & Play is complete, set your TV to Channel 3 or 4, according to the
directions for your cable or satellite box.
4
The TV memorizes the available channels. This process can take up to 45
minutes.
5
Top view
After the TV has memorized the channels, choose the Clock Mode. Select
Auto if you have a digital channel in your area. Select Manual if you don't, or
if you have a cable or satellite box. When done, press the ENTERE button.
✎
If you select Manual, the clock setting screen appears.
6
Select the daylight savings time setting: Off or On, and then press the
ENTERE button.
7
Select the time zone in which you live, and then press the ENTERE button.
8
After the time zone screen, The connection method for best HD screen
quality is displayed. Press Right arrow button on your remote to view each
screen in succession. Press the Blue button to skip this section.
9
The Enjoy your TV. screen appears. Then press the ENTERE button.
If You Want to Rerun Plug & Play
1. Press the SOURCE button on your remote, then select TV mode.
2. Press the MENU button on your remote to display the menu.
3. Press the ▲ or ▼ button to select Setup, and then press the ENTERE
button.
4. Press ENTERE again to select Plug & Play.
Step 3
: Connect External Devices
Connecting an AV device (DVD / Blu-ray player, cable/satellite box, etc.)
Connect Ant In to
Use one of the connections below to
connect your TV to an external A/V
• Wall cable jack
device.
• VHF/UHF Antenna
• Cable or Satellite box
We recommend using HDMI for the
Ant or Cable Out
highest picture quality.
POWER
Plug & Play
English
Español
:
Français
U Move E Enter
Audio Cable
(Not Supplied)
Plug & Play
:
Air
:
Cable
Auto
:
Search
U Move E Enter
Connecting an audio device (Home Theater, etc.)
Connect your TV to your Home Theater or other audio device to enjoy enhanced
Sound quality.
headphone
Optical Cable (Not Supplied)
Audio Cable (Not Supplied)
Optical Cable (Not Supplied)
HDMI Cable (Not Supplied)
HDMI to DVI Cable (Not Supplied)
Audio Cable (Not Supplied)
Video Cable (Not Supplied)
Good Connection
Component connection (up to 1080p)
Using a Component Cable
DVD / Blu-ray player / Cable Box / Satellite receiver / VCR
DVD / Blu-ray player
COMPONENT OUT AUDIO OUT
Component Cable
(Not Supplied)
Connecting a PC
Connect your TV to a PC to use it as a Monitor.
Analog Audio connection
Using a Headphone
Digital Audio connection
Using an Optical Cable
Digital Audio System
OPTICAL
Analog Audio connection
Using an Audio Cable
D-Sub Cable (Not Supplied)
Amplifier / DVD home theater
AUDIO IN
Using an EX-Link Cable Connection
Digital Audio connection Available Devices: External devices that support EX-Link.
Using an Optical Cable
Digital Audio System
OPTICAL
Best Connection
HD connection (up to 1080p)
Using an HDMI Cable
HDMI OUT
DVD / Blu-ray player
/ HD Cable Box / HD
Device
Satellite receiver (STB)
Very Good Connection
HD connection (up to 1080p)
Using a HDMI to DVI Cable
DVI OUT
Device
AUDIO OUT
Video Cable (Not Supplied)
Lowest Quality Connection
Audio/Video connection (480i only)
Using an Audio/Video Cable
DVD / Blu-ray player / Cable Box / Satellite
receiver / VCR
Device
VIDEO OUT AUDIO OUT
HD connection
Using a HDMI to DVI Cable
HDMI to DVI Cable
(Not Supplied)
DVI OUT
AUDIO OUT
Audio Cable
(Not Supplied)
Using a D-Sub Cable
Audio Cable
(Not Supplied)
AUDIO OUT
PC OUT
EX-LINK: Connector for service only.
