Audiovox MVGP1 Instruction Manual

MVGP1 WIRELESS GAME CONTROL INSTRUCTION
(For use with select Advent and Audiovox Headrest and Overhead Products)
REMOTE CONTROL WITH WIRELESS GAME CONTROL OPERATION
Battery Installation
Before attempting to operate your remote control, install the batteries
as described below:
1. Turn the game controller face down. Using your finger, lift the battery
cover tab and remove the cover.
2. Install three "AAA" batteries. Make sure that proper polarity
(+ or -) is observed.
3. Align the cover tab with the game controller and press down on the
cover tab until the cover locks.
WIRELESS GAME CONTROLLER FUNCTIONAL DESCRIPTION
DIRECTION
BUTTONS
1. Use the START button to enter the games list (1-54). Then use the direction buttons to move the arrow to the desired
game. Press the START button to select the game. Use the SELECT button to exit to the game list.
2. A Key: "A Function Key" activates the jump function and optional weapons.
3. B Key: " B Function Key" activates the fire and attack functions.
4. TA Key: TURBO "A" Function Key.
5. TB Key: TURBO "B" Function Key.
6. BACK Key: The Back key is used to return to the previous page. While playing a game pressing the Back button will
return to the games list. Pressing the Back button again will return to the games main page "54 Arcade Games".
7. Press the START button to begin the game. Press the START button again at any time to pause the game.
There are 54 games in the games list to choose from and 6 are for two players.
One-Player
The games can be selected from either the M1 monitor or the M2 monitor. Whichever viewer selects the game source
becomes Player 1 (and uses the P1 controller)
Two-Players
When there are two players, the first user to select the game source uses the P1 controller. Player 2 uses the P2
controller. The P1 controller is used for game selection. P2 controller can select a game but the game can only be
started by pressing the START button on P1 controller.
BACK
UP
SELECT START
DOWN
P1
SELECT START
UP
B
TB
TA
SELECT
DOWN
A
LED-POWER
INDICATOR
MANUAL
START
P2
128-9188
