- Page 1 PEL BB01 Under Counter Bottle Crusher User Manual Serial No.: ___________________________ Serial No.: ____________ Date of Purchase: ______________________ Date of Purchase: ______________ IMPORTANT PLEASE READ INSTRUCTIONS CAREFULLY FOR SAFE OPERATION OF MACHINE Tel: +353 94 93 66 923 Email: info@pelmfg.com Web: www.pelmfg.com...
- Page 2 PEL Under Counter Bottle Crusher 013-02-01_V12...
-
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ............................4 PEL BB01 BOTTLE CRUSHER ........................ 5 SETUP ................................5 KNOW YOUR UNIT ........................... 5 MOVING THE BOTTLE CRUSHER......................5 SAFETY ................................ 6 OPERATING INSTRUCTIONS ......................... 7 MAINTENANCE, INSPECTION & ADJUSTMENT ................8 TROUBLESHOOTING ..........................9 TECHNICAL SPECIFICATIONS: ...................... -
Page 4: Introduction
All information, illustrations, and specifications in this manual are based on the latest information available at the time of publication. It is the policy of PEL Recycling Equipment, to improve its products whenever possible and practical to do so. We reserve the right to make changes or improvements at any time without incurring any obligation to make such changes on products sold. -
Page 5: Pel Bb01 Bottle Crusher
MOVING THE BOTTLE CRUSHER The machine moved by trolley place machine on trolley and move with care. Ensure the BB01 Bottle Crusher is isolated from power supply before attempting to move the machine. PEL Under Counter Bottle Crusher... -
Page 6: Safety
Always allow yourself enough working space. Always insure feed flap is closing properly. Never use the machine if you are unsure. Contact PEL. WARNING: The Bottle Crusher was not designed to grind metal, rocks or such similar material. Always be cautious of what you grind and use good judgement. -
Page 7: Operating Instructions
If the chamber chokes up turn off the machine and disconnect power. Also, keep alert for heavy metal objects that may be mixed with the bottles. These can be thrown back at you, or severely damage the crusher. PEL Under Counter Bottle Crusher 013-02-01_V12... -
Page 8: Maintenance, Inspection & Adjustment
Maintenance, Inspection & Adjustment The Bottle Crusher should receive regular maintenance for continued good performance. The frequency will depend upon your operation, recommended 1 service by a PEL trained technician over a 12-month period. There are two bearings that hold the crusher rotor shaft and they must be greased monthly. -
Page 9: Troubleshooting
Insure feed flap is opening and closing fully. Model: BB01 Crushed glass storage container emptied. Overall Height: 840mm Crushed glass storage area is clean. Width: 700mm Emergency stop and Door switch are Depth: 600mm working. Electrical Requirement: Single Phase 230v PEL Under Counter Bottle Crusher 013-02-01_V12... -
Page 10: Parts List
BB01 -25 Pipe Support Bracket BB01 -26 Handle BB01 -27 Collection Box Door Switch BB01 -28 Side Access Panel BB01 – 29a Flap Switch BB01 – 29b Bin Full Switch BB01 -30 Solenoid Switch PEL Under Counter Bottle Crusher 013-02-01_V12... -
Page 11: Spare Parts
SPARE PARTS FIGURE – 1 PEL Under Counter Bottle Crusher 013-02-01_V12... -
Page 12: Electrical Circuit
ELECTRICAL CIRCUIT FIGURE – 1 PEL Under Counter Bottle Crusher 013-02-01_V12... - Page 13 PEL Under Counter Bottle Crusher 013-02-01_V12...
- Page 14 CONTROL PANEL PEL Under Counter Bottle Crusher 013-02-01_V12...
-
Page 15: Ec Declarataion Of Conformance
PEL Under Counter Bottle Crusher 013-02-01_V12... -
Page 16: Terms And Conditions
TERMS AND CONDITIONS DEFINITIONS “The Company” means PEL Waste Reduction Equipment. “The Customer” means the person, firm or company whose order for goods referred to in the Company’s quotation, tender, invoice or advice note is accepted by the Company. GENERAL... - Page 17 Company within 6 months of delivery and in the case of goods installed by the Company have notified the Company within 6 months of completion of installation. PEL Under Counter Bottle Crusher 013-02-01_V12...
- Page 18 Terms and Conditions of Business PROVIDED THAT the Company may at its absolute discretion and without prior consent employ such sub-contractors as it may deem suitable. 21. IRISH LAW This contract shall be governed and construed in all respects in accordance with the laws of the Republic of Ireland. PEL Under Counter Bottle Crusher 013-02-01_V12...
-
Page 19: Warranty And Manual Registration
Please sign the following declaration to state that on the day you (the Purchaser) purchased your Machine, you received an Operators Manual and Training Instructions. I, the purchaser have received my PEL Operators Manual and Training from the below dealer/installation engineer. -
Page 20: Installation & Training
Safe removal of the tote from machine Machine safety features Machine reset I confirm that all aspects of using the above machine have been explained to my satisfaction Name (Print) ____________________________________________________________________ Name (Sign) ____________________________________________________________________ Position ____________________________________________________________________ Date _______________________________________________________________________ Trainer _______________________________________________________________________ PEL Under Counter Bottle Crusher 013-02-01_V12... -
Page 21: Pel Training Record
Safe method of connecting/disconnecting power supply Safe use of operational controls Safe loading of machine Machine Safety features Name Date Position Trainer Operator Signature PEL Under Counter Bottle Crusher 013-02-01_V12... - Page 22 PEL Under Counter Bottle Crusher 013-02-01_V12...
