28-APR-2005
LIBERTO
™
Pool Pilot
Digital 48
by R B F International Ltée/Ltd.
DOMESTIC Chlorine Generating Device
Installation and Operation Manual
MODEL DIG48 REGISTRATION NUMBER 28038 PEST CONTROL PRODUCTS ACT
Maximum Output Equivalent To 0.82 Kg. Of Free Available Chlorine Per Day
One DIG48 Unit Can Treat a Maximum Of 153,000 Litres Of Swimming Pool Water
Controls Bacteria And Algae In Swimming Pool Waters
(For Indoor or Outdoor Use)
RETAIN MANUAL FOR FUTURE REFERENCE
NSF50
C
IMPORTANT
READ THE LABEL AND THIS MANUAL BEFORE INSTALLING & OPERATING
Notice to User: This control product is to be used only in accordance with the directions on this label. It is
an offense under the Pest Control Products Act to use a control product under unsafe conditions .
R B F International Ltée/Ltd., 780 Nobel Street, Saint -Jerome, Quebec J7Z 7A3
(RBF LIBERTO DIG4 8 Residential English Final April 2 0 0 5 )
Advertisement
Table of Contents
Summary of Contents for RBF Industries LIBERTO Pool Pilot Digital 48
- Page 1 28-APR-2005 LIBERTO ™ Pool Pilot Digital 48 by R B F International Ltée/Ltd. DOMESTIC Chlorine Generating Device Installation and Operation Manual MODEL DIG48 REGISTRATION NUMBER 28038 PEST CONTROL PRODUCTS ACT Maximum Output Equivalent To 0.82 Kg. Of Free Available Chlorine Per Day One DIG48 Unit Can Treat a Maximum Of 153,000 Litres Of Swimming Pool Water Controls Bacteria And Algae In Swimming Pool Waters (For Indoor or Outdoor Use)
-
Page 2: Pool Pilot Digital
Section 1a – GENERAL PRODUCT INFORMATION Pool Pilot ™ Digital by R B F International Ltée/Ltd. Record The Following Information Installer: _____________________________Date of Installation: __________________________ Control Unit Control Unit Model Number: DIG48______________ Serial Number: # ____________________________ Cell Cell Model: # RC7 Serial Number: # ____________________________ Customer Assistance…... -
Page 3: Important Safety Instructions
Section 1b – GENERAL PRODUCT INFORMATION IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS INSTALLATION AND EQUIPMENT RELATED LIBERTO Installation of all R B F Pool Pilot Digital models: When installing and using your Pool Pilot Digital Control Box, basic safety precautions must always be followed, including the following: Follow all aspects of the local and National Electrical Code(s) when installing your Control Box. -
Page 4: Table Of Contents
Section 1c – GENERAL PRODUCT INFORMATION Table of Contents Pool Pilot Digital R B F International Ltée/Ltd. Section 1 GENERAL INFORMATION Product Information and Contact Numbers ............1 Important Safety Instructions ................... 2 Table of Contents ....................... 3 Section 2 INSTALLATION Main Components ...................... -
Page 5: Section 2 Installation
Section 2a – INSTALLATION Main Components Tri-Sensor Assembly DIG 48 = RC7 Cell union Flow In Flow Out to pool Control Box Flow Bypass Manifold Assembly CONTROL BOX converts incoming ELECTROLYTIC CELL TRI-SENSOR ASSEMBLY AC power to a Low Voltage DC current, receives Low Voltage DC current from ensures that adequate flow, which energizes the Cell(s). -
Page 6: Control Box Connections
Section 2b – INSTALLATION Control Box Connections Electrical Connections Autopilot recommends that a licensed electrician or certified electrical contractor perform the electrical connections. DANGER: ensure that the electrical panel or filter pump circuit breaker is turned OFF before wiring this unit. Your Pool Pilot™... -
Page 7: Cell And Manifold Installation
Section 2b – INSTALLATION Cell and Manifold Installation Your R B F LIBERTO System is adaptable for use with the 7 blade (RC7) cell. The manifold must be located as the last accessory in the POOL RETURN LINE only. For special plumbing configurations, please contact your representative for assistance in locating the manifold. -
Page 8: Section 3 Operation
Section 3a – OPERATION Key Features The Pool Pilot Digital display will show the SANITIZER OUTPUT LEVEL (in percent %) and whether the system is in BOOST or SUPER-BOOST Mode on the first line of the two line alphanumeric display. The second line will display the current TIME in either 12 or 24-hr mode, the TEMPERATURE in either Fahrenheit or Celsius, whether the cell is powered or not, shown as ON or OFF and Polarity Direction, shown as a “.”... - Page 9 Section 3a – OPERATION Key Features – continued POOL PILOT Digital S a n i t i z e r 100% 12:00P Check System Boost Menu Select Pump The MENU Button allows you to enter the programming and monitoring functions. Use UP/DOWN ARROW and SELECT to scroll through the Main menu and Sub-menu: Main Menu 1.0 Test Pool Pilot...
- Page 10 Section 3a – OPERATION Key Features – continued POOL PILOT Digital S a n i t i z e r 100% 12:00P Check System Boost Menu Select Pump 3.0 MAINTENANCE MENU Use UP/DOWN ARROW and SELECT to scroll through the sub-menu. After completing a step, it displays the next step: 3.1 Test: same as 1.0 above plus cell Amp-hrs –...
-
Page 11: Pool Water Preparation
Section 3b – OPERATION Pool Water Preparation Salt Requirements It is important that with typical pools, a salt residual of 2.8 – 3.2 gm/l (2800 to 3200 ppm) be maintained at all times for peak efficiency. NOTE: Maintaining high salt levels above recommended range can contribute to corrosion of pool/spa equipment. Salt levels exceeding the recommended concentration can be reduced by diluting the pool/spa with fresh water. -
Page 12: Monitoring And Maintenance
Section 3c – OPERATION Monitoring and Maintenance Water Chemistry Parameters - Your Pool Pilot Digital is designed to provide Sanitizer on a daily VERY IMPORTANT NOTE! basis. We recommend the following water chemistry ranges and periodic checks to monitor your systems efficiency. A lways follow local health requirements. -
Page 13: Section 4 Service And Maintenance
Section 3c OPERATION (cont’d) Additional notes: For proper sanitation, spa must be completely drained periodically. The number of days between COMPLETE SPA DRAINAGE is equal to the volume of spa water in liters, divided by 10 times the maximum number of daily spa users. -
Page 14: Cell
Section 4b –SERVICE and MAINTENANCE Cell The Cell is installed with Unions on each end of the cell to allow quick and easy removal. Loosen the unions and remove the cell from the plumbing. Side View of Cell and Unions VISUAL CELL INSPECTION: The titanium Cell blades, seen inside the Cell body, should be straight and clear of any debris between the blades. -
Page 15: Parts Explosion
Section 4c –SERVICE and MAINTENANCE Parts Explosion Manifold Assembly: Manifold Union w/Strainer: (#941) (#19065) TRI-SENSOR Union Nut Union O-Ring (#19014) Strainer (#19064) CELL w/ UNIONS MANIFOLD UNION w/Strainer MANIFOLD BASE w/Check Valve Electrolytic Cell: (Cell Unions and Cord ordered separately) Red Cap Plug for RC7 cell cord (#19050) 12 ft. -
Page 16: Section 5 Troubleshooting
Section 5a – TROUBLESHOOTING TROUBLESHOOTING PROBLEM CAUSE SOLUTION Insufficient Sanitizer Production. A) The test kit reagents or test strips are old or expired. A) Retest with new Reagents or Strips. B) The unit is set too low in relation to sanitizer demand. B) Increase the Sanitizer % output. - Page 17 28-APR-2005 R B F International Ltée/Ltd., 780 Nobel Street, Saint- Jerome, Quebec J7Z 7A3 REGISTRATION NO. 28038 PEST CONTROL PRODUCTS ACT RBF LIBERTO MODEL DIG48 Chlorine Generating Device One DIG48 unit can treat a maximum of 153,000 Liters of swimming pool wat er. Notice to User: This control product is to be used only in accordance with the directions on this label.
- Page 18 28-APR-2005 Cell Model RC-7 This is a replacement cell for the chlorine generating device RBF LIBERTO Digital Model DIG 48 REGISTRATION NUMBER 28038, PEST CONTROL PRODUCTS ACT. This cell must only be used on this model of chlorine generating device. Read the Label and the Installation and Operation Manual of the chlorine generating device RBF LIBERTO Digital Model DIG 48 before using.
- Page 19 ****************************** This label transcript service is offered by the Pest Management Regulatory Agency to provide efficient searching for label information. This service and this information do not replace the official hard-copy label. The PMRA does not provide any guarantee or assurance that the information obtained through this service is accurate, current or correct, and is therefore not liable for any loss resulting, directly or indirectly, from reliance upon this service.
