Top Signal Cel-Fi GO G32 Smart Signal Booster TS559129 Installation Manual


A
There are three main components to install:

Outside antenna with coax cable. This kit includes your choice of outside
antenna:
A.
POYNTING PUCK-1 ANTENNA
van with the magnetic base, the 3M
bracket. (See the PUCK-1 user guide for installation instructions.)
PUCK-1 antenna magnetic
w/cable base plate
B.
TOP SIGNAL 5G OTR ANTENNA
exit adapter, spring mount, and mast extension to set your
preferred height for the antenna. (See the Top Signal
5G OTR installation guide for setup instructions.)
C. . Attach the spring mount at the
RFI WHIP ANTENNA
bottom of the antenna to a ladder or rail using the 3-way
mount, fold-down "bull bar" mount, or MagMAX 3X magnet mount.
Insert the connector at the end of the cable into a 0.35-inch (9 mm) hole or
other opening and pull the cable to the booster. For the RFI and Top Signal
antennas, use the barrel connector to adapt the end of the cable to the ᴅᴏɴᴏʀ
port (the cell tower icon) on the booster.
Do not kink, loop, or coil the cable.
Continued on the back side...

C

B
. Attach the antenna to the roof of your
®
adhesive pad, or the pole-mount
®
3M foam pole
adhesive pad bracket
. Choose a combination of side
You can install the Top Signal Cel-Fi GO Class B Van kit
yourself or you can have it installed by an RV dealer or
service center. Installation requires running a coax cable into
your van through an available opening or a specially drilled
0.35-inch (9 mm) entry point. (Speak with a professional if
you're not sure how to run cable into your van.)


Top Signal
5G OTR antenna
height options
or
TS053019
Installation tip:
We strongly recommend that
you do a "soft installation"
before permanently mounting
the antennas and pulling cable.
Drive to an area with weak
cell signal, then lay out and
connect all the components
inside your van. Power up
the booster and check the
signal you receive from the
inside antenna using the
Cel-Fi WAVE smartphone app.
The app will tell you if the
booster is experiencing any
errors and, if so, how to resolve
them.
v.20220429
