Master MFG 3PT-AC Assembly

BEFORE ASSEMBLING YOUR 3-POINT MOUNT
FOLLOW INSTRUCTIONS IN YOUR SPOT
SPRAYER ASSEMBLY MANUAL
TOOLS REQUIRED
1/2" SOCKET WRENCH
NOTE:
THIS 3-POINT MOUNT COMES PRE-ASSEMBLED. ONLY STEP REQUIRED IS
TO INSTALL BOOM KIT. FOLLOW BOOM ASSEMBLY INSTRUCTIONS BEFORE
INSTALLING TO 3-POINT MOUNT.
1a.
PARTS
Line up holes of the PNB Boom Assembly with the holes of the
Boom Brackets on the rear of 3-Point Mount Frame.
Install with 4 Bolts and Flange Nuts from Boom Assembly. Tighten
with a Socket Wrench.
INCLUDED
COMPONENTS
Tank Assembly (1)
1b.
NOTE: Reference Boom
Assembly Card for needed
components to install Boom
Assembly to 3-Point Mount
Frame. Boom Upright
Brackets that may come
with Boom Assembly are not
needed. Use your Tractor's
height control to manage
your spray height.
Attaches Boom Assembly to 3-Point Mount
Line up holes of the 620 Boom Assembly with the holes of the
Boom Brackets on the rear of 3-Point Mount Frame.
Install with 2 Bolts and Flange Nuts from Boom Assembly. Tighten
with a Socket Wrench.
HAVING TROUBLE? CALL SUPPORT AT: 800.825.5397
PARTS
NOTE: Reference Boom
Assembly Card for needed
components to install Boom
Assembly to 3-Point Mount
Frame. Boom Upright
Brackets that may come
with Boom Assembly are not
needed. Use your Tractor's
height control to manage
your spray height.
Attaches Boom Assembly to 3-Point Mount
