Summary of Contents for Bretford CUBE Micro Statio
- Page 1 User Guide 031-11214 Rev. 1 05/2022 1 of 9...
-
Page 2: About Your Product
About Your Product Product Overview The CUBE Micro Station® Charging Station Lift Handles Programmable combo padlock Courtesy Removable Modules Outlet 9 Foot Power Cable accommodate up to 14 in devices TVS10 Power Switch TVS16 Adapter storage below the module tray 031-11214 Rev. - Page 3 About Your Product Technical Specifications CUBE Micro Station ® TVS10PAC CUBE Micro Station® 10 TVS10USBC CUBE Micro Station® 10 Pre-Wired Model TVS16PAC CUBE Micro Station® 16 TVS16USBC CUBE Micro Station® 16 Pre-Wired Outer Dimensions (TVS10) 18.25 x 17 x 16.5 in / 46.4 x 43.2 x 41.9cm (TVS16) 27 x 17.75 x 17.63 in / 68.6 x 45.3 x 45cm (W x D x H) Slot Dimensions...
-
Page 4: Using Your Product
Using Your Product CUBE Micro Station® Setting the Combination Lock Your new CUBE Micro Station® comes equipped with a resettable Combination Padlock. You can program the lock with your own combination. The lock starts with 0-0-0-0. Follow the directions with the look for changing the combination. - Page 5 Using Your Product CUBE Micro Station® Wiring your CUBE Micro Station® Cont… 5. One-by-one, plug each AC adapter into one of the AC outlets. 6. Route each power cable through the front, corresponding holes on the lower portion of the unit. 7.
- Page 6 Using Your Product CUBE Micro Station® Placing your CUBE Micro Station® Your CUBE Micro Station® can be placed on a cabinet, stacked, daisy- chained (TVS10 only) or wall mounted. Stacking and wall mounting kits are available upon request. Stacking 1. Carefully place two CUBE Micro Station®’s on top of each other to avoid scratching or denting either station.
- Page 7 Using Your Product CUBE Micro Station® Daisy-Chaining Cont… 1. Shutdown both CUBE Micro Stations using the power switch and unplug each unit from the wall. 2. With two units securely placed in adjacent positions, take the AC power cord from one CUBE Micro Station® and plug into the rear courtesy outlet of the adjacent CUBE Micro Station®.
- Page 8 Important Information Safety Notice • Product for indoor use only • Do not plug the unit in if the switch or power cord has been damaged. • For safety purposes, make sure all electrical components do not exceed the maximum load rating of 12 amps. •...
-
Page 9: Additional Resources
Hours of Operation: M-F, 7:30am - 4:30pm CST Telephone: +1-800-521-9614 Email: customerservice@bretford.com Website: www.bretford.com/contact Bretford, CUBE, and CUBE Micro Station ® are trademarks or registered marks of Bretford Manufacturing, Inc. Patents pending. © 2022 Bretford Manufacturing, Inc. All rights reserved. 031-11214 Rev. 1 05/2022 9 of 9...
