Summary of Contents for Jiafu YSH-B18T1
- Page 1 JIAFU YSH-B18T1 Electric Kettle Instruction Manual – 1.5L Please read this manual thoroughly before operating this unit. This unit must only be serviced by the authorized seller.
-
Page 2: Important Safeguards
IMPORTANT SAFEGUARDS When using electrical appliances, basic safety precautions should always be followed including the following. Read all instructions. Do not touch hot surfaces. Use handles or knobs. To protect against electrical hazards, do not immerse cord, plugs, or the appliance in water or other liquids. -
Page 3: Before First Use
BEFORE FIRST USE Before using for the first time, it is recommended to clean the interior of the kettle thoroughly. Please follow the procedures below before using the kettle: Read all instructions and important safeguards. Remove all packing materials and make sure that the product has been received in good condition. -
Page 4: Specification
SPECIFICATION Product name Jiafu Multifunctional electric heating pot (healthy pot) Product model YSH-B18T1 Rated voltage 220V Rated frequency 50Hz Capacity 1.5L Rated power 600W Dimensions (length x width x height) 268 * 188 * 246mm PARTS IDENTIFICATION Glass cover Pot body... - Page 5 CONTROL PANEL Soup Porridge Grain porridge Herbal Noodle Dessert Function/ Cancel Preset Fruit Tea Hotpot Steam egg Timer Power Scented Tea Steam/Stew Boil Milk heating Keep warm Sterilize Milk Formula FUNCTIONS （1） Stew Including flower tea, fruit tea, desserts, medicated meals, soup, white porridge, coarse grain porridge, steamed eggs, noodles, hot pot, cooking Hot milk, soaking milk, disinfection, heat preservation and other functions.
-
Page 6: Function Selection
Warm reminder: When some foamy soups or desserts, after the water boils, you can lift the glass cover or turn down the power to prevent overflow (2) Function selection 1. Plug in, display the initial standby status, and display the time. 2. - Page 7 (4) Water boiled dry state. When the water boils up, the product will make a dripping sound, and the time will show. Show: E00, after adding water to cool, it will return to the initial standby state. THE TIME DISPLAY IS: 0:00. (5) Adjust the power.
- Page 8 Warm reminder: 1. The function of soaking milk is to keep warm at 50 °C after the water boils; 2. Steamed eggs, boiled noodles and disinfection functions do not enter the insulation state, and directly return to the initial standby state; 3.
- Page 9 Functional timetable Serial Function Default time Maximum Minimum Temperature number setting time setting time Boil water 60 °C Scented tea 0:10 0:20 0:05 60 °C Fruit tea 0:10 0:20 0:05 60 °C Dessert 0:40 1:30 0:05 70 °C Herbal 0:40 2:00 0:05 70 °C...
-
Page 10: Maintenance
Maintenance 01 • Clean Water Scale Clean scale Scale is a natural deposit formed when water is heated. It often adheres to the inner wall of the pot and the heating plate, which will affect the service life of the pot body and the quality of the water, so it should be removed regularly;... -
Page 11: Warranty
Q & A 1. There is no display on the digital tube, and the product cannot be used normally: a. Is there a power outage? b. Is the power plug properly inserted? c. Is the power outlet turned off? 2. The food is not cooked: a.
