Electrical press assembly tool for Press-Fitting systems
AC-FIX PRESS COMPACT 3
Keep lubricated.
Balanced energy can be displayed when press button.
Remark: Keep ratchet and roller lubricated can help to longer the life of the tool.
INSTRUCTIONS
Crimping done when indicator lights.
Tool protective cover,
anti-drop and anti-vibration.
Pressing cycle counter.
Advertisement
Summary of Contents for AC-FIX PRESS COMPACT 3
- Page 1 INSTRUCTIONS Electrical press assembly tool for Press-Fitting systems AC-FIX PRESS COMPACT 3 Crimping done when indicator lights. Tool protective cover, anti-drop and anti-vibration. Keep lubricated. Pressing cycle counter. Balanced energy can be displayed when press button. Remark: Keep ratchet and roller lubricated can help to longer the life of the tool.
- Page 2 It is essential to make a maintenance review 13. Belt after 10,000 pressing cycles or at least once a 14. Charger year. Consult your dealer for technical services 15. Allen wrench authorized by AC-FIX to perform maintenance 16. Interchangeable jaws reviews.
- Page 3 PROCEDURE Ex-factory setting pressure value Press the security pin to replace is aproximately 50. This value the insert. When replacing an should never be more than 56. insert, remove the battery from the tool to prevent any accidents. Place the insert corresponding to Make sure that the inserts close If there is any space between the the diameter of the fitting and se-...
- Page 4 11. It is better to recharge the battery after it is exhausted completely. 12. If the battery is unused for a long period of time, it is best to fully charge it before using it again. 13. If the tool is not used, recharge the battery every two months. Keep lubricated! www.ac-fix.com...
