Page 1 SAFELINE VARIO Diagnosis I nstruction Manual dina.de...
Page 2 Mail info@dina.de www.dina.de © Copyright by DINA Elektronik GmbH 2021 All parts of this documentation are protected by copyright. Any use beyond that permitted under copyright law is not permitted without express written con- sent from the publisher. This applies in particular to the reproduction, distribution and translation of this documentation or parts thereof, as well as the storage and processing of this content using electronic data processing systems.
Page 3: Table Of Contents
2.9. Status information about In/Output Module IOV 2.10. Status information about module RMV 2.11. Status information about network module NIV 3 Error Diagnostics Show detailed information 4 History 4.1. Read out History 4.2. Delete History Instruction Manual SAFELINE VARIO Diagnostics...
Page 4 USB port.There are two diagnostic options available: In the online diagnostic conditions can be detected with an open application. The rack diagnostics, the states can be read out to the connected modules without opening an application. Instruction Manual SAFELINE VARIO Diagnostics...
Page 5: Online-Diagnostics
A color change of the button indicates the active diagnostics. (Fig. 1-4) Fig. 1-4 During the diagnosis not all functions of the Designer are available. Blocked functions are displyed in grey. (Fig. 1-5) Fig. 1-5 Instruction Manual SAFELINE VARIO Diagnostics...
Page 6: Display Of The Symbols In The Online Diagnostics
Terminal grey = Input off (also for safety-related functions) Terminal green = Input on Terminal orange = error at the input, e.g. clocked input is activated static Output Terminal grey = output off Terminal green = output on Instruction Manual SAFELINE VARIO Diagnostics...
Page 7 Timer is indicated Upper value (black): Counter parameterized count value Lower value (blue): Current count value Black: set parameter Safe brake test Blue: current values T1: Stabilization time T2: Testing time Step: Test step Timeout Instruction Manual SAFELINE VARIO Diagnostics...
Page 8 Terminal red: short circuit or wire break or voltage/current more than 13.5V / 25mA Setpoint for Fx3 Multiplexer Setpoint for Fx2 Setpoint for Fx1 Setpoint for Standstill according to DNCO table and selected terminal Green: Selected terminal Instruction Manual SAFELINE VARIO Diagnostics...
Page 9 ANA terminal changes from gray to green when voltage is in the configured range Q: analog value at the given source Copier Act: Copied value Blue: current values Blue: current values ERR-MESS of encoder 1 and 2 Instruction Manual SAFELINE VARIO Diagnostics...
Page 10: Rack-Diagnostics
Start a new application. „File New“ (Fig. 2-1) Fig. 2-1 Adjust interface in the menu “transmission-interface” (Fig. 2-2), see designer manual. Fig. 2-2 Select „Rack diagnostics“ in the menu “logic”. (Fig. 2-3) Fig. 2-3 Instruction Manual SAFELINE VARIO Diagnostics...
Page 11 In Section 3 is located in the right corner of the window. The modules selected by the operater from area 2 are shown here enlarged. For more information see chapter „Modul Diagnostics“. In Section 4 status information selected modules related to area 3 are displayed. More information in chapter “Status information“. Instruction Manual SAFELINE VARIO Diagnostics...
Page 12: Diagnostics Buttons
2. Thus, the update time can be increased for the diagnostics data of selected modules. 2.3. Read out Rack information Section 2 shows the entire rack, the states at the inputs and outputs of the SL VARIO modules and fault states. Instruction Manual SAFELINE VARIO Diagnostics...
Page 13: Overview Of Possible Representation Types Of Modules
For these modules, the associated diagnostic information is not updated. Modules that are configured in the application, but not present in the rack as hardware (muting), are shown in gray. Instruction Manual SAFELINE VARIO Diagnostics...
Page 14: Module Diagnostics
In order to clear this error message the application must be provided by the element RTSK. Digital inputs Green signal level corresponds to H-level Gray corresponds to signal L-level Flashing output terminal: Short circuit on output Clocked output pairs are flashing. Outputs Instruction Manual SAFELINE VARIO Diagnostics...
Page 15: Overview Of Led Display Possibilities
• LED for standstill switches on again if the actual frequency < the parameterized frequency (at ZMV/ZMVK <4Hz). • LED for over speed switches on if the actual frequency < the parameterized frequency (at ZMV/ZMVK <4Hz) and the acknowledgement has happened with RTDS. Instruction Manual SAFELINE VARIO Diagnostics...
Page 16 Mixed one-channel and two-channel sensor monitoring at ZMV/ZMVK The LEDs for the two-channel monitoring switch as described above. The LED for the both one-channel monitoring switches, if the conditions for both single-channel monitoring are met. Instruction Manual SAFELINE VARIO Diagnostics...
Page 17: Status Information
Release of network input information is reset. RTSM Acknowledgment of the reclosing lockout at safety mats is due. RTSK Acknowledgment of the safety circuit error message and the latch error message is due. RTFB Fieldbus outputs are activated. Instruction Manual SAFELINE VARIO Diagnostics...
Page 18 In the display field for the corresponding setpoint the text appears „NO LIMIT“. If "position monitoring" is activated, instead of the desired and actual frequencies, the incremental values are displayed. In this case the term "ink" is displayed behind the numbers. Instruction Manual SAFELINE VARIO Diagnostics...
Page 19: Latch For Speed Monitoring At Zmv
Restores the state of the outputs at shut down. F11-F13;MT1 Restores the state of the inputs at shut down. L / R Describes the direction at shut down mode. A PDF file will be created out of this data release Instruction Manual SAFELINE VARIO Diagnostics...
Page 20 Only possible in SL VARIO DSV modules. If the option is selected in the designer and the Sin / Cos signal is not equivalent to Sin² + cos² = 1, this error occurs, for example, on EMC problems. Instruction Manual SAFELINE VARIO Diagnostics...
Page 21: Status Information About Timers
• [x]: the respective timer is configured and is in use. • [ ]: ZTimer in the application is not in use. • actual value in s.. • State of input T • State of output Fig. 2-9 Instruction Manual SAFELINE VARIO Diagnostics...
Page 22: Status Information About Counters
Fig. 2-11 To delete/acknowledge these lat- ched values, the icon RTSK to be wired in the application. Instruction Manual SAFELINE VARIO Diagnostics...
Page 23: Status Information About Copier
Only the cams used in the application are visible . • State of output „Range“ • upper and lower limit • Slot of SIV module • Actual value on encoder input (Encoder No. : increments/ frequency) Fig. 2-13 Instruction Manual SAFELINE VARIO Diagnostics...
Page 24: Status Information About Synchronicity Comparator
To delete/acknowledge these latched values, the icon RTSK has to be wired in the application. Instruction Manual SAFELINE VARIO Diagnostics...
Page 25: Status Information About Analog-Terminals
To delete/acknowledge these latched values, the icon RTSK has to be wired in the application. Instruction Manual SAFELINE VARIO Diagnostics...
Page 26: Status Information About Analog-Input Comparator
• Display of actual / setpoint Stabilization time Testing time Timeout • Step Actual Test Step An explanation of the test step, see Designer manual. Fig. 2-17 Diagnostic box: These indicate the status of the brake test. Instruction Manual SAFELINE VARIO Diagnostics...
Page 27: Tables
Conditions for safety circuit 1 ... safety circuit 4 are met. Conditions for two-hand control are met. RTDS Acknowledging of triggered Speed monitoring is due. O1+O2:CLK O1 and O2 are configured as clock outputs. O3+O4:CLK O3 and O4 are configured as clock outputs. Instruction Manual SAFELINE VARIO Diagnostics...
Page 28 In this case the term "ink" is displayed behind the numbers. No encoder signals available To access the trigger conditions press this button with the left mouse button. For more informationen see chapter “Latch function”. Instruction Manual SAFELINE VARIO Diagnostics...
Page 29: Latch Function
Restores the state of the outputs at shut down. F11-F13;MT1 Restores the state of the inputs at shut down. L / R Describes the direction at shut down mode A PDF file will be created out of this data release Instruction Manual SAFELINE VARIO Diagnostics...
Page 30 Only in SL VARIO DSV modules possible. If the option is selected in the designer and the Sin / Cos signal is not equivalent to Sin² + cos² = 1, this error occurs, for example, on EMC problems. . Instruction Manual SAFELINE VARIO Diagnostics...
Page 31: Status Information About Fieldbus Module Fbv
In the left pane, the following states are displayed. The boxes are checked, if the conditions are met. SK1 - SK4 Conditions for safety circuit 1 ... safety circuit 4 are met. Conditions for two-hand control are met. RTFB Fieldbus outputs are activated. Instruction Manual SAFELINE VARIO Diagnostics...
Page 32: Status Information About Input Module Inv
Conditions for safety circuit 1 ... safety circuit 4 are met. Conditions for two-hand control are met. O1+O2:CLK O1 and O2 are configured as clock outputs.. O3+O4:CLK O3 and O4 are configured as clock outputs. Instruction Manual SAFELINE VARIO Diagnostics...
Page 33: Status Information About Module Rmv
NIV module. The first digit indicates the network address from where the signals were sent. OUT1…OUT8 shows the state of the outputs of this NIV module. The first digit indicates the network address to which the signals were sent. Instruction Manual SAFELINE VARIO Diagnostics...
Page 34: Error Diagnostics
After selecting this red highlighted slot number field the present errors on the respective module are displayed. (Fig. 3-2) Fig. 3-1 Show detailed information Detailed information about error conditions can be accessed via the error-diagnostic button. (Fig. 3-3) Fig. 3-3 Instruction Manual SAFELINE VARIO Diagnostics...
Page 35 The errors stored in SL VARIO can be deleted with this button. If SL VARIO was provided with a password, the password is required here. Print By pressing this button a PDF document is created, which contains the information on this page. Instruction Manual SAFELINE VARIO Diagnostics...
Page 36 Firmware version of the connected device • Application-specific data, such as machine name, author, date • Spezielle Funktionen, die die Applikation beinhalten, wie z.B. Analogklemmen oder DNCO which can be used for more precise error analysis. Instruction Manual SAFELINE VARIO Diagnostics...
Page 37: History
Diese sind nicht in der Projektdokumentation sichtbar. Press the button “History” (Fig. 4-1) Fig. 4-1 The stored history data is read out and displayed. (Fig. 4-2). If SL VARIO was provided with a password, a password will be asked at first. Instruction Manual SAFELINE VARIO Diagnostics...
Page 38: Delete History
History 4.2. Delete History To delete the history press the button “Delete History”. (Fig. 4-3). If SL VARIO was provided with a password a password will be asked. Fig. 4-3 Instruction Manual SAFELINE VARIO Diagnostics...
