Summary of Contents for BE USB-RS485
- Page 1 BE USB-RS485 EXTERNAL DEVICES FOR INSTRUMENT REMOTE CONTROL...
- Page 2 This operating instructions contains safety information that if ignored can endanger life or result in serious injury. Read these instructions carefully before use and keep them for future reference. Information and specifications on this manual could be uncorrect or could have printing errors. Specifications are subject to change without notice. Version: R1-06-13...
- Page 3 Manufacturer is not liable for any unauthorized use or misuse of this product that may cause injury, damage to persons or materials. Device must be accessible at all times for both operating and servicing. Access must not be obstructed in any way.
- Page 4 INTRODUCTION BE USB-RS485 Interface converter RS485-USB for PC connection to LD multichannel, MAX5, MTOWER and WDPHxx. Features Power supply ..........230 VAC (180-270 VAC) Environment temperature ......10 ÷ 45°C (32 ÷ 113°F) Transportation and storage temperature ..10 ÷ 50°C (32 ÷ 122°F)
- Page 5 Download drivers/ERMES on PC from: http://tinyurl.com/ku8jemf. If ERMES is already installed, drivers are present on you PC. Connect to the PC only after the drivers of the BE USB-RS485 converter have been correctly installed. If you use a third-party RS485/USB converter, follow the relative instructions.
- Page 6 Application scheme...
- Page 7 Dimensions 95 mm 72,5 mm...
- Page 8 Disposal of end-of-life equipment by users This symbol warns you not to dispose of the product with normal waste. Respect human health and the environment by giving the discarded equipment to a designated collection center for the recycling of electronic and electrical equipment. For more information visit the online site.
