Mad4One MAD-freestyle Quick Start Manual

Hide thumbs
1
2
3
4

Advertisement

Table of Contents

THANK YOU !
Thank you for having chosen Mad4One.

How to remove the tire / inner tube of your MAD-freestyle

Please follow these simple steps for replacing it.

Deflate tire completely.

Even a small amount of air left in the tube
can make it more difficult to get the tire off.
For best results press downward on wheel
while deressing the valve.
Push one bead of tire toward rim center.
The tire bead will be pressed tight against
rim.
Pushing it inwards loosens the bead from
the rim.
0-2020/AB page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MAD-freestyle and is the answer not in the manual?

Questions and answers

Summary of Contents for Mad4One MAD-freestyle

  • Page 1 THANK YOU ! Thank you for having chosen Mad4One. How to remove the tire / inner tube of your MAD-freestyle Please follow these simple steps for replacing it. Deflate tire completely. Even a small amount of air left in the tube can make it more difficult to get the tire off.
  • Page 2 Do this on the same side all around the diameter of t he rim. THIS IS THE „KEY STEP“. Do not forget it ! Engage one tire lever under bead of tire. Pull the lever towards spokes to lift bead off rim, and hook it to a spoke.
  • Page 3 Releave one lever from the spoke and slide it along the rim under the bead by moving it away from the other lever. Proceed moving forward up to remove tire completely from rim on the side you are working on. Now you can take out the inner tube.
  • Page 4 When the tire comes out of the rim, help it with your hand. TO REASSEMBLE ALL PARTS, let’s repeat all steps, paying attention to the „Key Point“ described above. To remount the tire let‘s repeat all steps described above. Please do not forget the KEY STEP! 0-2020/AB page 4...
