Mounting recommendations with a standard cable ....10 Mounting recommendations with U-type cable ...... 11 LED indications ................12 Characteristics................12 Basic characteristics ..............12 Electrical characteristics ..............15 Safety information ..............16 Certification and Approvals ............17 Wiki FMC225 |...
Pinout Table 1 FMC225 2x6 socket pinout PIN NUMBER PIN NAME DESCRIPTION VCC (10-30)V DC (+) Power supply (+10-30 V DC). Analog input, channel 1. Input range: 0- AIN 1/DIN 2 30 V DC / Digital input, channel 2. RS232 – RX...
Please make sure that product casing corner clips are fixed tightly and cable is connected to the device in order to maintain the degree of IP67 protection. Figure 8 Attaching cover back Figure 9 Completely closed device Wiki FMC225 |...
Setup will continue installing the driver and eventually the confirmation window will appear. Click Finish to complete the 1. Power-up FMC225 with DC voltage (10 – 30 V) power supply setup. using supplied power cable. LED’s should start blinking, see “...
Page 8
Most important configurator section is GPRS – where all your server and GPRS settings can be configured and Data Acquisition – where data acquiring parameters can be configured. More details about FMC225 configuration using Configurator can be found in our Wiki. Figure 12 Configurator Status window Wiki FMC225 |...
120 seconds 2006 – Data sending protocol • After successful SMS configuration, FMC225 device will (0 – TCP, 1 – UDP) synchronize time and update records to configured server. Time intervals and default I/O elements can be changed by using Teltonika Configurator parameters.
▬ For better contact scrub paint from the spot where loop is power might be still available on the power wires. going to be connected. Depending on the car model, this may happen in 5 to 30 minutes period. Wiki FMC225 |...
Device power wire is designed to be directly connected to ▬ the positive terminal fastener of the vehicle battery • Connecting ground wire ▬ Device ground wire is designed to be directly connected to the negative terminal fastener of the vehicle battery. Figure 13 Device mounting Wiki FMC225 |...
Basic characteristics Table 5 Basic characteristics Table 3 Navigation LED indications MODULE BEHAVIOUR MEANING FMC225-MBIB0: MeiG SLM320-E with Teltonika TM2500 Permanently switched on GNSS signal is not received Name FMC225-MCIB0: MeiG SLM320-LA with Teltonika TM2500 Blinking every second Normal mode, GNSS is working...
Page 13
70,5 x 67,0 x 25,6 mm (L x W x H) Battery storage temperature -20 °C to +35 °C for 6 months Dimensions 85,0 x 67,0 x 25,6 mm (L x W x H) (length with connector socket) Wiki FMC225 |...
Input voltage (Recommended Operating OUTPUT SUPPLY VOLTAGE 1-WIRE Conditions) Input Voltage threshold (DIN1) Supply voltage +4.5 +4.7 Input Voltage threshold (DIN2) Output inner resistance Ω Output current (U > 3.0 V) Short circuit current (U = 0) Wiki FMC225 |...
CAUTION: Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to The device FMC225 is not designed as a navigational device for boats. the instructions. Do not disassemble the device. If the device is...
User‘s Manual before your start using the device. Full User‘s Manual version can be found in our Wiki. This sign on the package means that all used electronic and electric equipment should not be mixed with general household waste. Wiki FMC225 |...
More information can be found at teltonika.lt/warranty-repair • Repaired • Replaced with a new product • Replaced with an equivalent repaired product fulfilling the same functionality • TELTONIKA can also repair products that are out of warranty at an agreed cost. Wiki FMC225 |...
