Summary of Contents for AirMan DART 1300-027
- Page 1 1300-027 INSTRUCTION, DART™ CURRENT DRAW DATE DESCRIPTION DRAWN 2022-04-18 ORIGINATED 1300-027 INSTRUCTION, DART CURRENT DRAW Company Confidential...
- Page 2 DART ™ INSTRUCTION CURRENT DRAW Control TOOLS REQUIRED Wheel Display • AC/DC Ammeter / Multimeter with greater than 50 Amp DC Capacity • Example Brands: • Signstek / Uni-T, UT210E (100A) • Fluke, 325 (400A) • Fluke 365 (200A) 1300-027 INSTRUCTION, DART CURRENT DRAW Company Confidential...
- Page 3 DART ™ INSTRUCTION CURRENT DRAW STEP 1: TURN AMMETER ON Turn Control Wheel • Turn Control wheel to face high to Face high amp Display will amp (i.e. >50A) setting (i.e. >50A) Setting read A • Display will Read “A” •...
- Page 4 DART ™ INSTRUCTION CURRENT DRAW STEP 2: SWITCH TO DC SENSING Click Select Button Once Display • Click Select button so display (or till the Display reads should read reads “DC” • Note: instruction may vary depending on ammeter model/type used 1300-027 INSTRUCTION, DART CURRENT DRAW Company Confidential...
- Page 5 DART ™ INSTRUCTION CURRENT DRAW STEP 3: MEASURE CURRENT A. Put ORANGE Motor Cable through the hoop by pressing on hoop release B. While observing the ammeter, run the DART Actuator by pressing the rocker switch • If landing gear is in the UP POSITION, press the switch down to Hoop Release lower the landing gear •...
- Page 6 DART ™ INSTRUCTION CURRENT DRAW STEP 3: MEASURE CURRENT C. Observe sustained current for both directions • If observed current is > 18 Amps for more than 3 seconds in either direction • Read Current Value on the Inspect the landing gear legs for excess binding and consider replacement of landing gear legs then retest per 1300-030 Display (Troubleshoot Guide).
