Summary of Contents for Huchez 797
- Page 1 © 2011 by Huchez Treuils S.A.S. Jacks Rack-and-pinion jacks Reference 797 Instruction manual _________________________ 5.360.11...
- Page 2 2011 by Huchez Treuils S.A.S. REGISTERED DESIGN To ensure the constant improvement of its products, HUCHEZ reserves the right to change the equipment as described below and, in this case, to supply products which differ from the illustrations in this instruction manual.
- Page 3 © 2011 by Huchez Treuils S.A.S. 2.1. Technical specifications and construction: • Cast-iron structure. • Reducer with wheel and endless screw. 2.2. Dimensions: 500-kg model Travel: 800 mm PAINTED MODEL FORCE kg Load on the handle Lifting by turning the handle...
- Page 4 © 2011 by Huchez Treuils S.A.S. 1,000-kg model Travel: 800 mm FORCE kg Load on the handle Lifting by turning the handle Weight kg 1,000 2.3. Operation: The load is lifted or pulled by turning the handle in one direction or the other. For lifting, the load is held in every position when the handle is released.
- Page 5 © 2011 by Huchez Treuils S.A.S. 4 – Assembly and start-up The machine must be fastened to a suitable flat surface. Calculate and check that the mounting is markedly stronger than the nominal operating load. 5 – Servicing and maintenance Regular lubrication with high-pressure grease (e.g.
- Page 6 © 2011 by Huchez Treuils S.A.S. In France, since 1 April 2005, the owner of a lifting apparatus must: 1. Pursuant to the provisions of the order of 2 March 2004, keep a maintenance log in which the following must be recorded: ▪...
- Page 7 © 2011 by Huchez Treuils S.A.S. 9 – Spare parts 797 jacks – 500 and 1,000 kg Description 20963 Tube 20049 Grip 20962 20956 Casing 20957 Endless screw 20960 Rack and pinion 20961 Cover 20958 Toothed wheel 20959 20968 Rack and pinion...
