THE
MODEL 1324TK - 1624TK
HYDRAULIC TRACK TRENCHER OWNER'S MANUAL
CONGRATULATIONS!
You are now the proud owner of the BARRETO trencher. The OPERATOR'S MANUAL is attached
to the machine. Please study it and this manual to become familiar with the trencher, its
characteristics, and method of operation. Pay particular attention to the safety and operating
instructions to prevent personal injury or equipment damage.
If you have any questions or need any replacement parts in the future, please contact us at your
convenience. Our toll-free phone number, fax and email are listed below.
THANK YOU for your patronage and confidence in BARRETO equipment.
Barreto Manufacturing, Inc.
Innovative Equipment Engineered to Last
66498 Hwy 203, La Grande, OR 97850
(800) 525-7348 (541) 963-7348
FAX (541) 963-6755
E-Mail:
info@barretomfg.com
Web Site:
http://www.barretomfg.com
Machine Identification Record
BARRETO Customer number
Machine model number
Machine serial number
Engine manufacturer
Engine model number
Engine serial number
Page 1 of 22
1324TK - 1624TK OWNER'S MANUAL
12/4/14
Advertisement
Table of Contents
Related Manuals for Barreto 1324TK
Summary of Contents for Barreto 1324TK
- Page 1 HYDRAULIC TRACK TRENCHER OWNER’S MANUAL CONGRATULATIONS! You are now the proud owner of the BARRETO trencher. The OPERATOR’S MANUAL is attached to the machine. Please study it and this manual to become familiar with the trencher, its characteristics, and method of operation. Pay particular attention to the safety and operating instructions to prevent personal injury or equipment damage.
-
Page 2: Table Of Contents
ELECTRICAL SCHEMATIC – HONDA GX390 ELECTRICAL SCHEMATIC – SUBARU EX40 ELECTRICAL SCHEMATIC – BRIGGS VANGUARD 16HP HYDRAULIC SCHEMATIC – 1324TK HYDRAULIC SCHEMATIC – 1624TK TRACK TRENCHER TROUBLESHOOTING GUIDE SPECIFICATIONS INDEX Page 2 of 22 1324TK - 1624TK OWNER’S MANUAL 12/4/14... -
Page 3: Trencher Assembly Instructions
Damage resulting from this will void your engine warranty and not be covered. IMPORTANT - The engine on the Barreto trencher may or may not have been serviced prior to shipping. Shipping regulations may prohibit shipping with fuel or oil in the engine. Check levels and add oil and fuel as required before starting engine. -
Page 4: Hour Meter
Your DGI® hour meter is pre-set at the DGI® factory to go into Flash Alert mode at 25-hour intervals. Although the engine manufacturer does not require changing engine oil this often, due to heavy-duty use and extreme conditions inherent to tiller use, Barreto Manufacturing strongly recommends frequent oil changes. -
Page 5: Trencher Intended Use
LUBRICATION REQUIREMENTS Grease at the intervals indicated per the illustration of grease lubrication points. There is also a grease diagram decal on the machine. Page 5 of 22 1324TK - 1624TK OWNER’S MANUAL 12/4/14... -
Page 6: Chain Installation
• Starting up the engine. • Loading the trencher onto the trailer and securing it for road transport. • Unloading the trencher from the trailer. • Trenching procedure - Operation of the trencher. Page 6 of 22 1324TK - 1624TK OWNER’S MANUAL 12/4/14... -
Page 7: Warranty Of Barreto Manufacturing Equipment
WARRANTY OF BARRETO MANUFACTURING EQUIPMENT Barreto Manufacturing, Inc. warrants all BARRETO equipment to be free of defects in material and workmanship for a period of one (1) year, dating from delivery to the original user. This Warranty is in lieu of all other warranties, whether written or implied, and is limited to: Replacement of parts returned to the dealer and/or factory and determined defective upon inspection. -
Page 8: Routine Maintenance
Replacement parts and decals can be purchased from Barreto Manufacturing, Inc. When attaching decals, the temperature of the mounting surface must be at least 40°F (5°C) and must be clean and dry. -
Page 9: Track Tension Adjustment
1. Completely loosen tensioner nuts. 2. Retract idler completely. 3. Remove track from idler first, sprocket second and front roller last. 4. Reverse procedure to replace track. Adjust track tension per instructions and illustration. Page 9 of 22 1324TK - 1624TK OWNER’S MANUAL 12/4/14... -
Page 10: Track Drive Cable Adjustment
(shown). 4. Tighten cable nuts and replace back cover. 5. To see a video on how to do this adjustment, enter the following address into your browser URL window: https://www.youtube.com/watch?v=34B8phRm8m0 Page 10 of 22 1324TK - 1624TK OWNER’S MANUAL 12/4/14... -
Page 11: Track Drive Neutral Adjustment
The control cables should be adjusted so both tracks are in neutral or move at same speed. Check by starting engine and activating clutch lever with T-handle control in neutral. Adjust cables so both tracks are stationary or creep at same speed. Page 11 of 22 1324TK - 1624TK OWNER’S MANUAL 12/4/14... -
Page 12: Chain Valve Adjustment
3. Re-tighten the bolts and check the lever stroke. Adjust so the valve lever comes to the end of its stroke just as the clutch lever touches the handgrip when chain valve control is in ON position. Page 12 of 22 1324TK - 1624TK OWNER’S MANUAL 12/4/14... -
Page 13: T-Handle Control Tension Adjustment
If you tighten the socket head bolt (turn clockwise), the tension will increase. If you loosen the socket head bolt (counter-clockwise), the tension will decrease. LEFT HAND ADJUSTMENT RIGHT HAND Page 13 of 22 1324TK - 1624TK OWNER’S MANUAL 12/4/14... -
Page 14: Electrical Schematic - Honda Gx390
ELECTRICAL SCHEMATIC - HONDA GX390 Page 14 of 22 1324TK - 1624TK OWNER’S MANUAL 12/4/14... -
Page 15: Electrical Schematic - Subaru Ex40
ELECTRICAL SCHEMATIC – SUBARU EX40 Page 15 of 22 1324TK - 1624TK OWNER’S MANUAL 12/4/14... -
Page 16: Electrical Schematic - Briggs Vanguard 16Hp
ELECTRICAL SCHEMATIC – BRIGGS VANGUARD 16HP Page 16 of 22 1324TK - 1624TK OWNER’S MANUAL 12/4/14... -
Page 17: Hydraulic Schematic 1324Tk
HYDRAULIC SCHEMATIC 1324TK Page 17 of 22 1324TK - 1624TK OWNER’S MANUAL 12/4/14... -
Page 18: Hydraulic Schematic 1624Tk
HYDRAULIC SCHEMATIC 1624TK Page 18 of 22 1324TK - 1624TK OWNER’S MANUAL 12/4/14... -
Page 19: Track Trencher Troubleshooting Guide
Adjust Relief Valve to 3500 PSI or replace malfunctioning. relief spring if needed. 3. Chain drive pump worn. Replace pump. 4. Chain valve lever maladjusted. Adjust as shown in illustration elsewhere in this manual. Page 19 of 22 1324TK - 1624TK OWNER’S MANUAL 12/4/14... - Page 20 2. Boom cylinder piston seal damaged or rod Disassemble & replace parts as bent. required. 3. Boom pivot bushing seized. Disassemble, inspect, clean & replace parts as required. Page 20 of 22 1324TK - 1624TK OWNER’S MANUAL 12/4/14...
-
Page 21: Specifications
A1570 - Lift eye: for hoisting the trencher A1575 - Auxiliary Auger: extends removal of dirt to farther from the side of the trench A1580 - Backfill blade: to fill in trenches Page 21 of 22 1324TK - 1624TK OWNER’S MANUAL 12/4/14... -
Page 22: Index
T-HANDLE CONTROL TENSION ADJUSTMENT, 13 TRACK DRIVE NEUTRAL ADJUSTMENT, 11 TRACK DRIVE VALVE CABLE ADJUSTMENT, 10 TRACK TENSION ADJUSTMENT, 9 TRAILER, 6 TRANSPORT, 6 TRENCHER INTENDED USE, 5 TROUBLE SHOOTING, 19-20 WARRANTY, 7 Page 22 of 22 1324TK - 1624TK OWNER’S MANUAL 12/4/14...
