ONLINE OWNERS MANUAL

LINK 2000-R IDEAL REGULATOR OPTION

INSTALLERS!!! THIS DOCUMENT IS IMPORTANT FOR

OPERATION, PLEASE LEAVE IT WITH THE OWNER!!!

The LINK 2000-R is an integrated battery monitor, inverter/charger

control, and advanced alternator regulator. This manual only pertains

to the alternator regulator features. All other features and functions

are described in the LINK 2000 Owners Manual (Part # 890024). You

must be familiar with that manual before using the LINK 2000-R.

For use only with externally regulated

"P" Field type alternators.

See Required Reading page 8.

FAST START: For installation details skip to the Required

Reading section on page 8. Please read manual prior to using.

All warranty issues must be resolved through Heart Interface or Cruising

Equipment Co. Please do not return to the retailer, or route warranty issues

through the retailer.

21440 68

Ave. So. Kent, WA 98032

(206) 872-7225 Toll Free 1-800-446-6180

Mfg. by

(206) 782-8100

6315 Seaview Ave. NW Seattle, WA 98107

C:\WORK\LINK\NEWLINK2000\NEWREGINSTALL.PM6
