- Page 2 GETTING STARTED BEFORE INSTALLING THIS PRODUCT GETTING TO KNOW YOUR RF CONTROLLER To avoid potential shorts in the electrical system, be sure to disconnect the (–) battery cable before installation. Use this unit with a 12-volt battery and negative grounding only. Failure to do so may result in a fire or malfunction.
- Page 3 TROUBLE SHOOTING GUIDE WIRE DIAGRAM YOUR AMPLIFIER TROUBLE CAUSE SOLUTION The fuse is blown Check / replace the fuse RGB Unit will not turn on Switch not engaged Turn to on position Blown speaker Replace faulty speaker BLACK REMOTE OUT GROUND CABLE Volume is low / muted Press the volume level up...
Need help?
Do you have a question about the 72118 and is the answer not in the manual?
Questions and answers
How do I connect two set of 72108 to 72118
To connect two sets of SEACHOICE 72108 speakers to the SEACHOICE 72118 LED Speaker Module, follow these general steps:
1. Power Supply: Ensure the SEACHOICE 72118 LED Speaker Module is properly connected to a 12V power source.
2. Speaker LED Wires: Each SEACHOICE 72108 speaker set has LED lights. Connect the LED wires from both speaker sets to the corresponding output terminals or wires on the SEACHOICE 72118 module. Match color codes if available.
3. Control Signal: The SEACHOICE 72118 module coordinates the LED lights. Use its remote control to manage lighting effects for both speaker sets.
4. Audio Wiring: The SEACHOICE 72108 speakers' audio wires should be connected to your stereo or amplifier separately, as the 72118 module handles only LED control, not audio.
Make sure all connections are secure and weatherproof if used in marine environments.
