Laser Power Supply BJ-801
Thank you for choosing Leetro' s product.
Leetro keeps all right to vary the specification without further notice.
1. Introduction
This power supply is exclusively designed for CO
current can be set by user within the max.
2. Specifications
Working
Environment Condition
Output
Input
Accuracy
Efficiency
Protected Current
Response Time
Switch
Power Adjustment
Size
Weight
3. Wiring Method
-
Connect the RED wire to the laser tube positive end.
-
Connect the BLACK wire to the laser tube negative end.
-
Details refer to the Port Definition diagrams.
User Manual for
(Updated: May 2010)
Temperature
Moisture
Voltage
Current
L, N and PE Wires, 50Hz 220V± 10%
2%
95%
28± 1mA
0.2 ms
O and 1, TTL
0～5V analog or PWM signal
245× 185× 100 mm
Net 3.1 Kg, Gross 3.5Kg
laser machine. The output
2
-10 ～ +40 ℃
≤85％
Max DC35KV
DC (0～28) mA
- 1 -
Advertisement
Summary of Contents for Leetro BJ-801
- Page 1 User Manual for Laser Power Supply BJ-801 (Updated: May 2010) Thank you for choosing Leetro’ s product. Leetro keeps all right to vary the specification without further notice. 1. Introduction This power supply is exclusively designed for CO laser machine. The output current can be set by user within the max.
