Summary of Contents for Magnum Industrial MI-12910
- Page 1 MODEL NO.: MI-12910 C A U TI NO. : MOD EL NO. : MFG . NO. : R.P.M . SER IAL TR. / MN. H.Z . H.P. VOL T DAT E PHA SE: EN TAIW AMP . RIQ UÉ AN / FAB...
-
Page 2: Table Of Contents
CONTENTS: IMPORTANT SAFETY RULES-------------------------------------------------------------- IMPORTANT SAFETY RULES FOR DUST COLLECTORS--------------------------- GROUNDING INSTRUCTIONS------------------------------------------------------------- SPECIFICATIONS------------------------------------------------------------------------------ UNPACKING CONTENTS-------------------------------------------------------------------- HARDWARE PACKAGE---------------------------------------------------------------------- ASSEMBLY INSTRUCTION----------------------------------------------------------------- EXPLODED DIAGRAM---------------------------------------------------------------------- PARTS LIST-------------------------------------------------------------------------------------- WARNING! Please read this manual carefully before assembly, testing and operating. WARNING! Do not operate this unit until hose or pipe is installed onto the dust inlet port. -
Page 3: Important Safety Rules
IMPORTANT SAFETY RULES Wood working can be dangerous if safe and proper operating procedures are not followed. As with all machinery, there are certain hazards involved with the operation of the product. Using the machine with respect and caution will considerably lessen the possibility of personal injury. However, if normal safety precautions are overlooked or ignored, personal injury to the operator may result. -
Page 4: Important Safety Rules For Dust Collectors
IMPORTANT SAFETY RULES FOR DUST COLLECTORS WARNING: DO NOT pull the dust collector by the power cord. Basic precautions should always be followed when using your dust collector. To reduce the risk NEVER allow the power cord to come in contact with of injury, electrical shock or fire, comply with the safety sharp edges, hot surfaces, oil or grease. -
Page 5: Grounding Instructions
GROUNDING INSTRUCTIONS The appliance must be grounded, if it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This appliance is equipped with a cord having equipment-ground conductor and grounding plug. The plug must be inserted into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances. -
Page 6: Specifications
Specifications: Motor---------------------------------------------------------------------------------------------------------------------- 1/2HP AMP------------------------------------------------------------------------------------------------------------------------- 2.8A Motor Speed-------------------------------------------------------------------------------------------------------- 3450RPM Suction Capacity----------------------------------------------------------------------------------------------------- 472CFM Static Pressure----------------------------------------------------------------------------------------------------- 2.44 inH Impeller Size---------------------------------------------------------------------------------------------------------------- 6.7” Inlet Size------------------------------------------------------------------------------------------------------- 5”x3”(1)x2”(1) Switch-------------------------------------------------------------------------------------------------------- Magnetic Switch Packing Size of Base------------------------------------------------------------------------------------- 910x480x525MM N.W.-------------------------------------------------------------------------------------------------------------------- 42.6KGS G.W.-------------------------------------------------------------------------------------------------------------------- 49.5KGS Cuft.--------------------------------------------------------------------------------------------------------------------------- 8.1’... -
Page 7: Unpacking Contents
UNPACKING & CHECKING CONTENTS: A: Main Body B: Inlet Adaptor C: Tray D: Fixing Pad... -
Page 8: Hardware Package
Hardware package: Q’TY Description Specification Part List No. NO. 27 Foot Pad 5/16” Nut with cap 5/16” NO. 28 Hex Flange Screw 1/4”x1/2” NO. 10 Hex Flange Screw 1/4”x3/4” NO. 18 Open-end Wrench 10x12 NO. 44... -
Page 9: Assembly Instruction
ASSEMBLY INSTRUCTION: STEP 1-1. Assemble the fixing pad (NO. 29) on the main body (NO. 16) with hex flange screw (NO. 10). STEP 1-2. Tight the foot pad (NO. 27) with the fixing pad (NO. 29) by using nut with cap (NO. 28). STEP 1-3. - Page 10 PARTS LIST FOR MI-12910...
-
Page 11: Exploded Diagram
PARTS LIST FOR MI-12910 PART NO. DESCRIPTION Q'TY MI-12910-1 Motor 1/2HP MI-12910-2 Phillips Head Screw 1/4”x1/2” MI-12910-3 Motor Cord MI-12910-4 Motor Plate MI-12910-5 Lock Nut MI-12910-6 Impeller MI-12910-7 Lock Nut MI-12910-8 4x4x20 MI-12910-9 Impeller Housing MI-12910-10 Hex Flange Screw 1/4”x1/2”...
