- Page 1 HR4136-B1 Reference Manual TIRIS PROXIMITY TAG CID/Data Read/Write Controller With SECS I/II Protocol VERSION: 1.04 HEART TECH ENTERPRISE CO., LTD.
-
Page 2: Precautions In Using The Product
PROFITS OR COMMERCIAL LOSS IN ANY WAY CONNECTED WITH THE PRODUCTS, WHETHER SUCH CLAIM IS BASED ON CONTRACT, WARRANTY, NEGLIGENCE, OR STRICT LIABILITY. In no event shall responsibility of HEART TECH for any act exceed the individual price of the product on which liability is asserted. -
Page 3: Performance Data
Performance data given in this document is provided as a guide for the user in determining suitability and does not constitute a warranty. It may represent the result of HEART TECH’s test conditions, and the users must correlate it to actual application requirements. -
Page 4: Connector Description
HR4136-B1 Consult the dealer or an experienced radio/TV technician for assistance. FCC ID : 2AB67-HR4136-B1 Compliance with : FCC Code of Fedral Requlations,Part 15 Subpart C, Section §15.205 FCC Code of Fedral Requlations,Part 15 Subpart C, Section §15.209 WARNING... -
Page 5: Installation
Tighten the M3 - M4 screws with a torque not exceeding 1.2 Nm. Do not apply organic solvents used with screw locking agents at the locations where the screws are inserted. HEART TECH ENTERPRISE CO., LTD. BEST SERVICE FROM HEART... - Page 6 HR4136-B1 Antenna Stick antenna Rectangular antenna Note： Mount with the two M3 - M4 plastic screws . Champ Core Installation Instructions HEART TECH ENTERPRISE CO., LTD. BEST SERVICE FROM HEART...
-
Page 7: Wiring Diagram
HR4136-B1 Wiring Diagram: RS232 RS485 Pin No. RS485 R+ / D+ R- / D- Pin No. RS232 Ground Antenna cable length : 2M with RP-TNC connecter HEART TECH ENTERPRISE CO., LTD. BEST SERVICE FROM HEART... -
Page 8: Systems Architecture
1. Each HR4135 gate controller has two RS485 communication ports. Each RS485 communications port Maximum connections of 32 sets HR4136-B1 CIDRW controller. Recommended maximum number of connections each RS485 communications port is not over 25 sets HR4136-B1 CIDRW controller. 2. RS485 maximum connection distance: from HRP485 Repeater to last one HR4136-B1 CIDRW Controller total 1000 m. - Page 9 HR4136-B1 1. Use HRP485 Repeater can be connected up to 99 set HR4136-B1 CIDRW Controller. 2. RS485 the maximum connection distance: from HRP485 Repeater to last one HR4136-B1 CIDRW Controller total 1000 m. HEART TECH ENTERPRISE CO., LTD. BEST SERVICE FROM HEART...
- Page 10 The transmission area diagram going through the center of the antenna and indicated on a flat surface vertical to the antenna surface is as indicated below. Legend : Normal area Recommended area Unrecommended area 10 11 HEART TECH ENTERPRISE CO., LTD. BEST SERVICE FROM HEART...
- Page 11 Tag : TEXAS INSTRUMENTS 32mm Glass Transponder part number RI-TRP-DR2B The transmission area diagram going through the center of the antenna and indicated on a flat surface vertical to the antenna surface is as indicated below. HEART TECH ENTERPRISE CO., LTD. BEST SERVICE FROM HEART...
-
Page 12: General Specifications
Total Character format (fixed) None Error control FCS (Frame Check Sequence) RS-232C 15 m Max. ; Total cable length RS-485 : From HR4135 to last one HR4136-B1 Total 1000 m Max. HEART TECH ENTERPRISE CO., LTD. BEST SERVICE FROM HEART... - Page 13 1 ~ 2 Baud rate The beeper is enabled when a correct Stream Function executed. Beeper status The beeper is disabled. The controller automatic read tag RFID repeatedly. Test mode Normal operation. HEART TECH ENTERPRISE CO., LTD. BEST SERVICE FROM HEART...
