    INSTRUCTION MANUAL • Type: Supply system for solid fuel fi replaces • Model: FIREPOD universal • Revision 1.0.1 System FIREPOD universal INDEX INTRODUCTION 1.1 Using the manual WARNINGS PRODUCT DIMENSIONS AND TECHNICAL DATA 3.1 Identifi cation plate 3.2 Safety symbols KIT AND ACCESSORIES INSTALLER’S RESPONSIBILITIES...
  • Page 4 Universal system instruction manual 1 INTRODUCTION Dear Customer, We would like to thank you for choosing to purchase an our product, the technical characteristics of which are certain to satisfy your needs. Our products have been designed and built according to current regulations, having chosen the best materials in order to obtain a user friendly and highly durable product.
  • Page 5 3 PRODUCT DIMENSIONS AND TECHNICAL DATA Firepod English FIRE POD Model Item AP3400.00.20 Attachments Ø mm Electric motor protection level Level of electrical protection control panel Level of electrical protection suction inlet Operating temperature min/max °C 0 ÷ 50 Min/max humidity level 30 ÷...
  • Page 6 Universal system instruction manual 3.1 Identifi cation plate The CE identifi cation plate is present on each component of the system Universal. Do not remove or damage the nameplate. Identifi cation of the manufacturer System type ......................CE conformity Model: marking P/N:...
  • Page 7 4 KIT AND ACCESSORIES The system sales package includes: 1 x rectangular dispenser tank English 1 x motor 1 x motor fi xing plate 1 x control panel 1 x complete suction inlet 1 x fl exible pipe 1,5 meters 2 x fi...

  • Page 8: Installer's Responsibilities

    Universal system instruction manual 5 INSTALLER’S RESPONSIBILITIES To ensure proper operation of the product, follow these guidelines: • Only perform the activities described in these instructions • Perform all activities in accordance with applicable regulations • Explain to the user the operation and use of the product •...
  • Page 9 English 20/10/21 Rev:1.0.1...
  • Page 10 Universal system instruction manual 7 INSTALLATION OF THE BASIC COMPONENTS Before commencing installation of the system, it is useful to know that some of its components require particular precautions regarding their positioning, in particular the control panel. It is essential that it is easily visible by the system user, to facilitate ignition and adjustment procedures.
  • Page 11 Before proceeding with the fi nal fi xing of the dispenser tank, make sure that it is easy to open its upper cover by means of the two hooks, to facilitate access to its interior for any maintenance. Also check that the lower discharge door of the dispenser tank can be completely opened and closed without impact on the tank walls.
  • Page 12 Universal system instruction manual 7.5 Suction inlet The suction inlet is designed to be positioned on a masonry or plasterboard wall and is composed of: - the mounting plate, to be applied in the masonry or to be fi xed fi rmly on the back of the plasterboard wall (see fi...
  • Page 13 Using the copper fi lament inside it, each section of pipe must be connected to an grounding point of the electrical system, to ensure the dispersion of static charges (see fi gure 11). English Figure 11 7.7 Flexible pipe with suction lance This 1.5 meter pipe must be assembled by screwing in the rubber fi...
  • Page 14 Universal system instruction manual 7.8 Electrical connection cables The electric cables supplied are all equipped with different wiring to avoid positioning errors. The cables allow the connection of power supply to the control panel (see fi gure 15) and the connection of the suc- tion inlet to the control panel (see fi...
  • Page 15 8.2 Air exhaust silencer The silencer has the task of damping the noise caused by the expulsion of air. If it is conveyed as it is towards the outside, it must be connected to the end of the air discharge pipe just before the expulsion outlet (see fi...

  • Page 16: Pipes Connections

    Universal system instruction manual 8.6 Adjustable shelf for rectangular dispenser tank The pair of shelves is suitable for easy dispenser tank mounting above the tank loading mouth, allowing a series of adjustments that permit the dispenser tank to be positioned level and correctly (see fi gure 25) Figure 25 8.7 Electrical wiring extensions The extension cables are supplied with the relevant connectors to extend the wiring from the motor to the...

  • Page 17: Electrical Wiring

    10 ELECTRICAL WIRING The control panel is equipped with a cable which guarantees the power supply to the entire system. In the control panel there are also connectors for the other components of the system English to be made using the cables supplied. To avoid incorrect connections, each cable has a unique connector (see fi...
  • Page 18 Universal system instruction manual Now check that the duration of each suction cycle is long enough to fi ll the dispenser tank with the right amount of fuel, at least up to half of its internal volume. To make this check at the end of a suction cycle, keep the outlet door closed after completing a cycle and turn off the system, then open the lid of the dispenser tank and check the contents.
  • Page 19 14 MAINTENANCE AND END OF LIFE Good maintenance of your system will guarantee a long operating life and reduce its electricity consumption. English Always keep the dust fi lter bag clean where installed, replacing it when full. Clean the lower fuel discharge fl ap of the metering device if dust or deposits settle on it. (see fi...

  • Page 20: Troubleshooting

    Universal system instruction manual 15 TROUBLESHOOTING The suction force is reduced or zero - there is a blockage of material in the lance holder hose or in the connection pipe between the suction inlet and the dispenser tank - there is a split, a hole, a cut, or an air leak, in the lance holder hose, or in the connection pipe between the suction inlet and the doser, or in the connection pipe between the doser and the motor - the air outlet is blocked...

  • Page 21: Warranty

    16 WARRANTY PRODUCT LIMITED WARRANTY CONDITIONS English The Manufacturer guarantees to the original purchaser the absence of defects in material and workmanship of the product for the period stated, from the date of purchase. Except as prohibited by applicable law, this warranty is non transferable and it is limited to the original purchaser.
  • Page 22 Universal system instruction manual 17 CERTIFICATION Declaration of absence of harmful substances The manufacturer declares that their products and equipment are made with materials compliant with the current regulations regarding protection of health and the environment and does not contain sub- stances classifi...
