- Page 1 XENON POWER SUPPLY for 10 kW Britelight Lamphead Rev. June 2004 STRONG INTERNATIONAL a division of Ballantyne of Omaha, Inc. 4350 McKinley Street Omaha, Nebraska 68112 USA Tel 402/453-4444 • Fax 402/453-7238 www.strongint.com...
-
Page 2: Table Of Contents
CONTENTS Page PREFACE ..........1 INSTALLATION ........1 Tap Adjustment ........ 2 INSTALLATION DIAGRAM ....5 TROUBLESHOOTING ......6 MAINTENANCE ........9 WIRING DIAGRAM ......10 PARTS ILLUSTRATIONS Figure 1 ..........11 Figure 2 ..........13 Figure 3 ..........14... -
Page 3: Preface
For operator safety, it is necessary to turn off all power to the unit when adjusting or servicing the xenon power supply. This safety switch or power disconnect should be tagged “OFF - UNIT UNDER REPAIR”... -
Page 4: Tap Adjustment
IGNITE THE XENON BULB and check the current as indicated on the control panel ammeter. Allow (30) seconds for the current to stabilize and provide an accurate reading. If the current is not within the above-noted range, extinguish the bulb. - Page 5 INSTALLATION (continued) FINE ADJUSTMENT of the DC current is made to the NUMBERED taps found on the upper three terminal blocks (TB4, TB5, TB6). Fine taps are numbered 1-2-3-4, with “1” providing the lowest output, increasing to “4,” yielding the highest output. A “fine” tap adjustment raises or lowers the current approximately four amperes.
- Page 6 AFTER PROLONGED OPERATION, the light output of the xenon bulb will decrease. This is a normal factor of bulb aging, and can be compensated by raising the DC output of the xenon power supply. If the bulb was first operated at “nominal” current, the power supply output can gradually be increased to, but not in excess of, he maximum current specified by the bulb manufac- turer.
-
Page 7: Installation Diagram
1 Green AC Input 2 Orange 3 Blue 4 Red 5 Black 6 White 7 Brown 8 Yellow SYSTEM MUST BE GROUNDED XENON All wiring must conform to local POWER electrical code; shield lamphead SUPPLY cable in conduit if required. -
Page 8: Troubleshooting
THE BOOST CIRCUIT generates the high open circuit (“no load”) DC voltage which, in conjunction with the igniter pulse, will ignite the xenon bulb. The open circuit voltage should measure at least 110 V.DC. It is displayed briefly on the lamphouse ammeter by pressing the “VOLT- AGE”... - Page 9 TROUBLESHOOTING (continued) POWER CONVERSION PROBLEMS RECTIFICATION (AC to DC) is performed by bridge diodes CR1 - CR6. CR1, CR2, and CR3 are forward diodes, and CR4, CR5, and CR6 are reverse diodes. The two types are not interchangeable. AN OPEN DIODE will cause a pronounced flicker in the light output. Two or more open diodes will disable bulb ignition.
- Page 10 2. Faulty bridge diode. See preceding DIODE TESTING section. 3. Faulty xenon bulb. Check for cracked or sagging electrode(s). 4. Leaking xenon bulb. Check for white or bluish discolored envelope, high current and low voltage (below 48 volts DC). Replace as required.
-
Page 11: Maintenance
3. Faulty xenon bulb. Check for cracked or sagging electrode(s). Replace as required. 4. Leaking xenon bulb. Check for white or bluish discolored envelope, high current and low voltage (below 48 volts DC). Replace as required. Elapsed Time Meter fails to record hours 1. -
Page 12: Wiring Diagram
WIRING DIAGRAM Britelight 10 kW Xenon Power Supply... -
Page 13: Parts Illustrations Figure 1
FIGURE 1... - Page 14 PARTS LIST Figure 1 Item Part No. Description 32-00215 Top Cover Panel 4100621 Mounting Screw, 10-32 x 5/8" 4107101 Flatwasher, #10 32-00412 Rear Panel 4100621 Mounting Screw, 10-32 x 5/8" 4107101 Flatwasher, #10 32-90014 Power Supply Chassis Assembly (see Figure 3) 4250752 Mounting Screw, 1/4-20 x 3/4"...
- Page 15 FIGURE 2 13 12 11 10 Item Part No. Description 31-30005 Indicator Light, Red 31-30006 Indicator Light, Green 31-32004 Elapsed Time Meter 31-32007 Volt Meter 31-32006 Ammeter 32-00218 Panel (less Components) 4100621 Mounting Screw, 10-32 x 5/8" 31-98160 Test Point Socket, Black 31-98162 Test Point Socket, Red 31-61049 “Focus”...
- Page 16 FIGURE 3 XENON POWER SUPPLY CHASSIS...
- Page 17 PARTS LIST Figure 3 Item Part No. Description 82-40264 Capacitor Mounting Bracket 61-06001 Capacitor Clamp (2 req’d.) 61-08027 Filter Capacitor, 5400 µf, 200 V.DC (C3, C7) 82-40248 Shorting Bar 82-40047 Terminal Board Mounting Plate, Phenolic 91-64011 Power Transformer (T1), 208/230 V.AC, 50/60 Hz. Input 91-64007 Power Transformer (T1), 380/440 V.AC, 50/60 Hz.
