STRONGHOLD ACCESSORIES
There are several Jaws Sets which can be quickly and easi-
ly inter-changed on the Stronghold Chuck. Some of these
are listed below:
* #1 Jaws (Spigot Jaws)
Part Number: 2104
* #3 Jaws
Part Number: 2106
* Jumbo Jaws
Part Number: 2136
* Flat Jaws
Part Number: 2756
* Dovetail Jaws
Part Number: 2948
Want more information about the Stronghold Chuck?
Visit our website at http://www.oneway.on.ca
Want to place an order?
Call Toll Free: 1 800 565-7288
STRONGHOLD
4 JAW KEY-OPERATED SAFETY SCROLL
CHUCK
THE ULTIMATE CHOICE!
Advertisement
Summary of Contents for Stronghold 5141239
- Page 1 STRONGHOLD ACCESSORIES STRONGHOLD There are several Jaws Sets which can be quickly and easi- ly inter-changed on the Stronghold Chuck. Some of these are listed below: 4 JAW KEY-OPERATED SAFETY SCROLL CHUCK * #1 Jaws (Spigot Jaws) Part Number: 2104...
- Page 2 Method Two: Large Drill chuck, installation instructions are on page 8. Mounting the Adaptor Method Three: Glue Block Certain features of the STRONGHOLD are patented under one or more of Removing the Adaptor Differentiating Left & Right Hand the following patent numbers:...
- Page 3 YOUR CHUCK DESCRIPTION YOUR CHUCK DESCRIPTION Top view of STRONGHOLD chuck. The Back view of STRONGHOLD chuck GEARED KEY: To open and close TAPERLOCK ADAPTOR: chuck is shown partially disassembled to with the adaptor removed. Made with various threaded sizes the chuck.
- Page 4 FEATURES OF YOUR CHUCK WHY YOU HAVE BOUGHT A SUPERIOR CHUCK BY BUYING The STRONGHOLD is equipped with The groove on the base THE STRONGHOLD: ONEWAY's patented profile top jaw shape. This jaw is tapered. This groove •Base jaws are made from carbon steel. Precision grinding on the sides pro-...
- Page 5 These are used as jack screws if the adaptor needs to be removed. MOUNTING THE STRONGHOLD ON YOUR LATHE. It is important that your chuck is put on your lathe properly. Proceed as fol- OUNTING THE ADAPTOR: --(your adaptor may already be mounted)-- lows: 1.
- Page 6 5. After removing the snap ring, turn the chuck upside down into your hand and the scroll should fall straight out. The STRONGHOLD is manufactured To clean your chuck, simply brush clean. If it is sticky, soak in varsol or with very tight tolerances, and sometimes a little jiggling is necessary to get mineral spirits with about 10% oil added.
- Page 7 There are two slots: STRONGHOLD with Top Jaws removed. After replacing base jaws, you must check that they all meet in the centre. The Long Slot is for experienced turners. It is machined to allow the jaws...
- Page 8 For finishing the backside of your bowls up to 12" in diameter, the Jumbo Right out of the box, the STRONGHOLD will be ready to be used for most Jaws are unsurpassed. Jumbo Jaws are aluminum plates machined from the turning applications.
- Page 9 SECTION 5 - ONEWAY TURNING TIPS off the screw, it helps if you loosen the jaws off of the screw just enough to break contact with the jaw faces). Next, turn the blank around and grip on This section of this instruction manual is devoted to turning tips, and ways to the spigot or the recess.
- Page 10 cially appropriate when you don't want a foot, or tenon and don't have a TO MAKE TOPS or similar small components, simply mount a suitable means to turn it off. This method is also less wasteful if you are working piece of stock, square or preferably round.
- Page 11 By using properly sharpened tools and good technique, you will be guaranteed better results and safer turning. 3. The capacity of the STRONGHOLD depends on various factors such as whether the wood is wet or dry, soft or hard or whether turning end grain or 10.
- Page 12 STRONGHOLD WARRANTY CARD GUARANTEE If you are not completely satisfied with this product for any reason, Name: please return it to us within two years of purchase. Please mail the warranty card to us immediately upon purchase. Address: OUR PROMISE TO YOU City: No false claims.
- Page 13 Foot Specifications for Chucking Board Grain Specifications for Chucking Spindle Turning (End Grain) When gripping the outside When gripping round end grain of a board grain foot stock, make the spigot the same 1 Make the foot 1/4" deep shape as for board grain. or more.
