MT950 User Manual V1.0

MT950 Low Power Analyzer

User Manual V1.0

Preface

Congratulations on choosing the Mictrack MT950 Low Power Analyzer. This manual

shows how to easily use the unit. Make sure to read this manual carefully before using this

product, so as to avoid delays or confusion with its operation. Please note that specifications

and instructions are subject to change without notice to facilitate product improvement.

Updates and changes will be integrated into the latest release. The manufacturer assumes no

responsibility for any errors or omissions in outdated documents.

http://www.mictrack.com

Table of Contents

Need help?

Do you have a question about the MT950 and is the answer not in the manual?

Questions and answers

Summary of Contents for Mictrack MT950

Page 1 User Manual V1.0 Preface Congratulations on choosing the Mictrack MT950 Low Power Analyzer. This manual shows how to easily use the unit. Make sure to read this manual carefully before using this product, so as to avoid delays or confusion with its operation. Please note that specifications and instructions are subject to change without notice to facilitate product improvement.
Page 2: Table Of Contents
MT950 User Manual V1.0 Contents 1. Overview..........................1 2. Features..........................1 3. System Requirements....................... 1 4. Specifications........................2 5. MT950 Interface......................... 2 6. In the box..........................2 7. Quick Start...........................2 8. Operations..........................3 8.1 Test Pause....................... 3 8.2 Automatic waveform zoom................... 4 8.3 Zoom in and out of the waveform via mouse roll........5 8.4 Display Ratio......................5...
Page 3: Overview
Mictrack R&D team felt that it was difficult to accurately measure power consumption data with ordinary instruments, and high-end instruments were too expensive. The MT950 can be used for power consumption testing and evaluation of NB-IoT, Cat M1, Bluetooth, Zigbee, LoRa, etc. It is very cost-effective and suitable for R&D, testing, production of small and medium-sized enterprises and learning of...
Page 4: Specifications
MT950 User Manual V1.0 4. Specifications Specifications Item Dimension 170*120*46mm Weight 700g Sampling frequency 10KHZ Input voltage: 0~12V Working temperature -20°C to 55°C Measuring Range: 1μA-2A Resolution 0.01uA Precision 5. MT950 Interface 6. In the box Power Analyzer MT950 ...
Page 5: Operations
MT950 User Manual V1.0 12V (It is recommended to supply 4V higher than the power supply of the test device), and press the power switch on the rear panel (press down to1 to turn on, press down to 0 to turn off).
Page 6: Automatic Waveform Zoom
MT950 User Manual V1.0 Click the “Pause” and “Continue” buttons to pause the automatic refresh of the chart  current waveform, which is convenient for viewing and analyzing. “Pause” does not stop the current data collection and recording, but the screen display ...
Page 7: Zoom In And Out Of The Waveform Via Mouse Roll
MT950 User Manual V1.0 8.3 Zoom in and out of the waveform via mouse roll You can specify the mouse roll to zoom in or out on the time axis (horizontal axis) or the  current axis (vertical axis) through the setting bar on the right.
Page 8: Statistical Area Description
MT950 User Manual V1.0 NOTE: The sampling frequency of the analyzer is fixed and will not change due to the adjustment of the display ratio. Different time scale gears are the average calculation results. For example: select the 100ms time file, a point on the screen represents 100ms time, calculated according to the sampling frequency of 10kHz, this point is the result of the average calculation of 1000 sampling points.
Page 9: Interval Settings And Cursor Definition
MT950 User Manual V1.0 8.6 Interval settings and cursor definition The interval setting area on the right can set the duration of the recent and cursor  statistics. For example, if the recent duration is set to 20s, the data displayed in the recent statistics window at the bottom of the graph waveform is the average result from 20s ago to the current time.
Page 10: File Operation And Version Information
MT950 User Manual V1.0 8.7 File operation and version information From the menu (file), you can perform typical file operations such as opening and saving.  Used for test record data archiving, analysis and communication. The saved file format is an internal format, which can be opened by the host computer itself.
