Your spotlight has been engineered and manufactured to our high standard for dependability, ease of operation, and operator
safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNiNg:
To reduce the risk of injury, the user must read and understand the operator's manual before using
this product.
Thank you for your purchase.
SAvE ThiS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
18 vOLT SPOTLighT
P715
bATTERiES ANd ChARgERS SOLd
SEPARATELy
ACCEPTS ALL ONE+ bATTERy PACKS

Advertisement

loading

Related Manuals for Ryobi P715

Summary of Contents for Ryobi P715

  • Page 1 To reduce the risk of injury, the user must read and understand the operator’s manual before using this product. Thank you for your purchase. SAvE ThiS MANUAL FOR FUTURE REFERENCE OPERATOR’S MANUAL 18 vOLT SPOTLighT P715 bATTERiES ANd ChARgERS SOLd SEPARATELy ACCEPTS ALL ONE+ bATTERy PACKS...

  • Page 2: Table Of Contents

    WhAT ThiS WARRANTy COvERS: This warranty covers all defects in workmanship or materials in your RYOBI tool for a period of two years from the date of purchase. With the exception of batteries, power tool accessories are warranted for ninety (90) days.

  • Page 3: General Safety Rules

    MOdEL bATTERy PACK (P104) (Li-ion) 13049001 (P113) 140501001 P715 1304900 (P100) (Ni-Cad) 13055004 (P110) 143701 130408  Remove battery pack from spotlight before replacing bulb or performing any routine maintenance or cleaning.

  • Page 4: Symbols

    Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SyMbOL NAME Volts Amperes Minutes Alternating Current Direct Current No Load Speed Class II Construction...

  • Page 5: Features

    PROdUCT SPECiFiCATiONS Bulb ...6 V Halogen KNOW yOUR SPOTLighT See Figure 1. The safe use of this product requires an understanding of the information on the product and in this operator’s manual as well as a knowledge of the project you are attempting.Before use of this product, familiarize yourself with all operating features and safety rules.

  • Page 6: Assembly

    Operate in a well ventilated area. Do not block vents. Keep them clear to allow proper ventilation. This product will accept Ryobi One+ 18 V lithium-ion battery packs and Ryobi One+ 18 V nickel-cadmium battery packs. Both types of battery packs are shown on this page. Following pages will show the lithium-ion 18 V battery pack.
  • Page 7 TO iNSTALL bATTERy PACK See Figures 3 - 4.  Place the switch trigger in the OFF position.  Place the battery pack in the spotlight.  Make sure the latches on each side of the battery pack snap in place and that battery pack is secured in the spotlight before beginning operation.

  • Page 8: Maintenance

    WARNiNg: When servicing, use only identical replacement parts. Use of any other parts may create a hazard or cause product damage. WARNiNg: To avoid serious personal injury, always remove the battery pack from the product when cleaning or performing any maintenance. gENERAL MAiNTENANCE Avoid using solvents when cleaning plastic parts.

  • Page 9: Maintenance

    CAUTiON: Do not use a higher rated fuse other than the specified amperage. This could cause damage to the product. REPLACEMENT FUSE See Figure 8. If the spotlight blows its fuse, you will need to replace it. Look for replacement fuses where you purchased this product.  Remove the battery pack from the fuse housing.
  • Page 10 1-800-55-579. • HOW TO OBTAIN CUSTOMER OR TECHNICAL SUPPORT: To obtain Customer or Technical Support please contact us at 1-800-55-579. RYOBI is a registered trademark of Ryobi Limited used under license. ® 987000-151 09-4-07 (REV:01) OPERATOR’S MANUAL 18 vOLT SPOTLighT...
