Summary of Contents for IOT SmartRoom
- Page 1 本企业通过ISO9001：2008质量管理体系标准 SmartRoom 水浸监测器 使用说明书 2015 南京物联传感技术有限公司 出版号：2015-0512.V01...
- Page 3 欢迎您使用SmartRoom水浸监测器产品说明书 ● 是南京物联传感技术有限公司的注册商标。本说明书中提到所有其 他产品名称或商标是其各自品牌所有者的商标或注册商标。 ●使用前请您认真阅读本产品使用说明，确保正确、安全地使用。 ●SmartRoom水浸监测器（以下简称“本产品”）为南京物联传感技术有限公 司（以下简称“我司”）出品的智能家居安防类产品。本产品需要与智能家居 相应APP客户端同步使用，并须使用本产品自带的配件，如您未正确地操作本产 品，而造成的损失，我司将不承担任何责任。 ●我司随时可能对本说明书中的产品信息进行更新，恕不另行通知。请您及时 关注我司资讯，并下载最新版的APP客户端。 ●未经我司的明确书面许可，任何个人及企业不得复制本说明书的全部或部分 内容，不得使用我司注册商标。对非法使用我司商标的行为，我司将依法追究 行为人及企业法律责任。 ●欢迎您登录我司官网www.wulian.cc，了解更多智能家居产品信息。...
- Page 4 产品展示 水接触探针 水浸监测器 上壳 水浸监测器 下壳 正面 反面...
- Page 5 多功能按键 系统指示灯 电池仓 上壳 底壳...
- Page 6 基本功能 ● 可有效监测渗水漏水现象； ● 通过任何智能移动终端，可进行远程监控； ● 高灵敏度水接触探针，可及时监测到漏水点并发送报警信息； ● 可联动相关智能设备，如机械手。...
- Page 7 规格参数 结构参数 69mm 净重（g） 材质 PC+ABS 颜色 白色 安装方式 移动式 阻燃等级 UL94 V-2...
- Page 8 通用参数 DC 3V 电源参数 CR2*1 供电方式 ≤2μA 待机电流 ≥1mm 水位高度 IEEE 802.15.4 ZigBee/SmartRoom 通信协议 PCB天线 天线配置 -10℃~+45℃ 工作环境温度 ≤95%RH（不凝结） 工作环境湿度...
- Page 9 软件下载 下载方式一： 请扫描产品包装盒上的二维码，下载软件客户端。 下载方式二： 官网下载：http://www.wulian.cc/service.shtml 温馨提示：初次使用时，请先安装APP客户端，并仔细阅读产品说明书；请时 常关注我司资讯，以便及时更新。...
- Page 10 安装、联网 ①底壳电池仓内装入1节CR2电池。...
- Page 11 ②加网 连续快击【多功能按键】4次，单次快击时间不超过1秒，申请加入ZigBee网络； 搜索网络中，【系统指示灯】呈绿色闪烁；成功加入ZigBee网络后，【系统指 示灯】呈绿色长亮2秒后熄灭。 多功能按键 系统指示灯...
- Page 12 ③退网 长按【多功能按键】10秒，【系统指示灯】呈绿色闪烁4次后熄灭，恢复出厂设 置，同时退出ZigBee网络。 多功能按键 系统指示灯...
- Page 13 ④将下壳的定位圈和上壳的定位点对准，顺时针旋转至定位点与定位横线对齐；...
- Page 14 注： ●设置前，请确认无线网关（需另外购买）正常工作，本产品处于网关有效通 信距离内；如需远程控制，请将网关接入广域网。 ●当本产品需要加入到其他网关时，请先退出当前网关，再进行联网设置。 ● 恢复出厂设置默认为不加入ZigBee网络。...
- Page 15 如何使用 当本产品探测到有渗水漏水情况时，立刻自动发出报警信号到移动智能终端。 同时，【系统指示灯】呈红色闪烁，本产品撤离导电液体后将自动消警。 【系统指示灯】...
- Page 16 当电池电压过低时，移动智能终端将收到无线欠压报警信息，请用户及时更换 电池，以免影响正常使用。 ！ 智能终端...
- Page 17 注意事项 ●本产品需放置在固定的平面，以免影响探测效果。 ●避免将本产品全部浸入到水及其他导电液体中，以免内部元器件受潮而影响 产品使用效果。 ●本产品避免高空摔落或猛烈撞击，以免影响产品使用寿命。 ●本产品表面沾有灰尘时，用细布擦干即可，不得使用带腐蚀的清洁液及其它 化学溶剂进行清洁。 ●本产品需定期进行例行试验，发现故障并及时排除，以免有盗情不报警。 ●请勿擅自拆卸或改装本产品及其配件。 ●若本产品发生故障，非专业人员不得打开本产品，应送到当地维修点进行维 修，或直接与我司客服联系。 请更换正确型号的电池，以免有爆炸危险!请按照操作指示处理废旧电池！...
- Page 18 订购信息 产品名称 产品型号 材质颜色 货号 SmartRoom水浸监测器 SR-ZSSMBPW-FD-01 PC+ABS，白色 SRPN1312301...
- Page 20 服务热线：400-928-9288 官网：www.wulian.cc 邮编：210039 南京市雨花台区凤集大道15号创业创新城-北柚11栋...
- Page 21 ISO9001：2008 Certified SmartRoom Smart Water Leakage Sensor User Manual ©2015 Nanjing IOT Sensor Technology Co., Ltd. Publication No.：2015-0512.V01...
- Page 23 ●Please read this manual carefully and keep it properly before using. ●SmartRoom Smart Water Leakage Sensor (hereinafter referred to as “this product”) is smart home security product produced by Nanjing IOT Sensor Technology Co., Ltd. (hereinafter referred to as “Wulian”).
-
Page 24: Function Illustration
Function Illustration Water Probe Upper Shell Lower Shell Front Back... - Page 25 Multi-functional Key System Indicator Battery Compartment Upper Shell Lower Shell...
- Page 26 Features ● It could moniter water leakage effectively. ●Remote control through any smart mobile terminals. ●The high-sensitive water probe could monitor water leakage and send alarm notifications immediately. ● It could interwork with relative smart devices (i.e. Smart AutomaticManipulator).
-
Page 27: Product Parameter
Product Parameter Structure Parameters 68.97mm Net Weight（g） PC+ABS Materials White Color Mobile Mounting Type Flame Retardant Rating UL94 V-2... - Page 28 General Parameters DC 3V Power Parameter CR2*1 Power Supply ≤2μA Standby Current ≥1mm Water Level IEEE 802.15.4 ZigBee/SmartRoom Communication Protocol PCB Antenna Antenna Type -10℃~+45℃ Operating Temperature ≤95%RH（Noncondensing） Operating Humidity...
-
Page 29: Software Download
Software Download Option A: Download the latest smart APP by scanning QR code on the package box of this product. Option B: iOS user can download the APP by searching "Wulian Smart home" in "APP Store". Android user can download the APP by searching "Wulian Smart home" in "Google Play". Warm Promt: Please download Smart Home APP and read user manual at first use. - Page 30 Installation & Networking ①Put a CR2 battery in battery compartment.
- Page 31 ②Add to network Click [Multi-functional Key] 4 times quickly (each click less than 1s) to request to add to the network. In searching network, [System Indicator] flashes green. Upon connection to ZigBee network, [System Indicator] goes out after staying green for 2s. Multi-functional Key System Indicator...
- Page 32 ③Exit the network Press on [Multi-functional Key] for 10s to restore to factory settings and exit ZigBee network, [System Indicator] goes out after flashing 4 times. System Indicator Multi-functional Key...
- Page 33 ④Direct the locating ring of the lower shell to the locating point of the upper shell. Then rotate clockwise until the locating point aligns with the locating line.
- Page 34 Note: ●First make sure ZigBee network of the wireless gateway (additional purchase) is working well. Meanwhile, make sure this product is connected to power and is placed within the effective communication distance of the gateway. If remote control is needed, connect the gate to WAN.
- Page 35 User Guide When this product detects water leakage, it will send alarm notifications immediately to mobile smart terminals. Meanwhile, System Indicator flashes red. This product out of conductive liquid after police will automatically disappear. System Indicator...
- Page 36 When the battery voltage level is too low, mobile smart terminals will receive undervoltage alarm notifications to remind users to change batteries in case of not affect the normal use. ！ Smart terminal...
- Page 37 Cautions ●Make sure this product is placed on fixed flat surface, in case of poor effect on detection. ●Do not place this product wholly into water or other similar liquid, in case of poor effect in use by being exposed to moisture. ●Do not drop this product high in the air or smash it in case of affecting the service life ●If there is dust on the surface, clean it with a piece of soft cloth.
-
Page 38: Order Information
Order Information Name SR Smart Water Leakage Sensor Model SR-ZSSMBPW-FD-01 Materials & Color PC+ABS,White Item No. SRPN1312301... - Page 39 Statement: Hereby, Nanjing IOT Sensor Technology Co., Ltd. declares that this device is in compliance with theessential requirements and other relevant provisions of Directive 1999/5/EC. Disposal and Recycling Information You can help protect the environment! Please remember to respect the local regulations:hand in the non-working...
- Page 40 Building 11, No.15, Fengji Road, Yuhuatai District, Nanjing Postcode: 210039 Service Hotline: 400-889-2891 www.wulian.cc/english...
