LG 40WP95C Owner's Manual

Hide thumbs Also See for 40WP95C:

Advertisement

Quick Links

Owner's Manual
LED LCD MONITOR
(LED Monitor*)
* LG LED Monitor applies LCD screen with LED backlights.
Please read this manual carefully before operating your set and retain it for future reference.
40WP95C
40BP95C
www.lg.com
Copyright 2021 LG Electronics Inc. All Rights Reserved.

Advertisement

loading

Related Manuals for LG 40WP95C

Summary of Contents for LG 40WP95C

  • Page 1 Owner’s Manual LED LCD MONITOR (LED Monitor*) * LG LED Monitor applies LCD screen with LED backlights. Please read this manual carefully before operating your set and retain it for future reference. 40WP95C 40BP95C www.lg.com Copyright 2021 LG Electronics Inc. All Rights Reserved.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS LICENSE ............3 OPEN SOURCE SOFTWARE NOTICE INFORMATION ..........4 ASSEMBLING AND PREPARING .....4 USING THE MONITOR ........11 USER SETTINGS ...........15 TROUBLESHOOTING ........23 PRODUCT SPECIFICATION ......25...

  • Page 3: License

    LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. The terms HDMI, HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.

  • Page 4: Open Source Software Notice

    Illustrations in this document represent typical procedures, so they may look different from the actual product. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.
  • Page 5 • The power cord provided may differ depending upon the region. Supported Software You can download and install the latest version from the LGE website (www.lg.com). Joystick Button • OnScreen Control/ Dual Controller/ LG Calibration Studio...
  • Page 6 Moving and Lifting the Monitor How to Use the Joystick Button You can easily control the functions of the monitor by pressing the joystick button or moving it left/right/up/ When moving or lifting the monitor, follow these instructions to prevent the monitor from being scratched or down with your finger.
  • Page 7 Installing on a Table CAUTION • • Lift the monitor and place it on the table in an upright position. Place the monitor at least 100 mm Avoid touching the monitor screen as much as possible. (3.9 inches) away from the wall to ensure sufficient ventilation. - This may result in damage to the screen or some of the pixels used to create images.
  • Page 8 Adjusting the Angle CAUTION • Unplug the power cord before moving or installing the monitor. There is risk of electric shock. Place the monitor mounted on the stand base in an upright position. • Make sure to use the power cord that is provided in the product package and connect it to a grounded power Adjust the angle of the screen.
  • Page 9 Using the Kensington Lock Installing on the Wall For more information on installation and usage, refer to the Kensington lock owner’ s manual or visit the website This monitor meets the specifications for the wall mount plate or other compatible devices. at http://www.kensington.com.
  • Page 10 Installing the monitor on the ceiling or on a slanted wall may result in the monitor falling off, which could lead to injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel. Wall Mount (mm/ inches) 100 x 100 (3.9 x 3.9)

  • Page 11: Using The Monitor

    Press the joystick button, go to [Settings] > [Input], and then select the input option. CAUTION • If you use generic cables not certified by LG, the screen may not display or there may be image noises. • Do not press the screen for a prolonged time. This may cause image distortion.
  • Page 12 Connecting to a PC DisplayPort Connection Transmits digital video and audio signals from your PC to the monitor. • This monitor supports the feature. NOTE : A feature that allows you to add a device to your computer without having to reconfigure anything or install any manual drivers.
  • Page 13 Connecting AV Devices Connecting Peripherals HDMI Connection USB Device connection HDMI transmits digital video and audio signals from your AV device to the monitor. The USB port on the product functions as a USB hub. CAUTION NOTE • • Using a DVI to HDMI / DP (DisplayPort) to HDMI cable may cause compatibility issues. It is recommended you install all Windows Updates to keep your Windows up-to-date before connecting to the product for use.
  • Page 14 Case 1: Thunderbolt 3 / 4 ( ) Input Case 2: HDMI/DP (DisplayPort) Input Peripheral devices connected to the USB IN port can be controlled from the PC. Peripheral devices connected to the USB IN port can be controlled from the PC. If you change the input on the menu while a device is connected via the Thunderbolt 3 / 4 ( ) port, then the device connected via the USB port may not work properly.

  • Page 15: User Settings

    USER SETTINGS Headphones Connection Connect peripherals to the monitor via the headphones port. NOTE NOTE • Peripheral devices are sold separately. • Your monitor’ s OSD (On Screen Display) may differ slightly from that shown in this manual. • Depending on the audio settings of the PC and external device, headphones and speaker functions may be •...
  • Page 16 Main Menu Features Menu Settings To view the OSD menu, press the joystick button at the bottom of the monitor and then enter the [Settings]. Move the joystick up/down and left/right to set the options. To return to the upper menu or set other menu items, move the joystick to or pressing ( ) it.
  • Page 17 [Quick Settings] [Input] [Settings] > [Quick Settings] [Settings] > [Input] • [Brightness]: Adjusts the brightness of the screen. • [Input List]: Selects the input mode. • • [Auto Brightness]: Optimizes the brightness automatically for surrounding illuminance. [Auto Input Switch]: When [Auto Input Switch] is set to [On], display will automatically switch to new input when connected.
  • Page 18 [Calibration 1]: Adjusts to the last calibrated screen. : Displays 1 input only. • [Calibration 2]: Adjusts to the previously calibrated screen. Installation of LG Calibration Studio will enable : Displays main screen and sub screen half and half. this menu.
  • Page 19 [Settings] > [Picture] > [Picture Adjust] NOTE • [Brightness]: Adjusts the brightness of the screen. • The [Picture Mode] that can be set depends on the Input signal. • [Auto Brightness]: Optimizes the brightness automatically for surrounding illuminance. • If the [Picture Mode] is changed in the DP (DisplayPort) input, the screen may flicker or the resolution of your •...
  • Page 20 • [Black Level]: Sets the offset level (for HDMI only). [Settings] > [Picture] > [Game Adjust] - Offset: as a reference for a video signal, this is the darkest color the monitor can display. • [Response Time]: Sets a response time for displayed pictures based on the movement of the picture on the screen.
  • Page 21 [Settings] > [Picture] > [Color Adjust] CAUTION • [Gamma] • [Adaptive-Sync] / [FreeSync] - [Mode 1], [Mode 2], [Mode 3]: The higher the gamma value, the darker the image becomes. Likewise, the - In HDMI input, the menu name is displayed as certified AMD FreeSync Tier name instead of Adaptive-Sync. lower the gamma value, the lighter the image becomes.
  • Page 22 [General] • [DisplayPort Version]: Set DisplayPort Version to the same version as the connected external device. ([1.4] and [1.2]) [Settings] > [General] To use the HDR function, set to [1.4]. • [Language]: Sets the menu screen to the desired language. •...

  • Page 23: Troubleshooting

    TROUBLESHOOTING NOTE • [SMART ENERGY SAVING] - The value of energy saving data may differ depending on panel and panel suppliers. - If you select the option of [SMART ENERGY SAVING] is [High] or [Low], monitor luminance become higher Nothing is displayed on the screen. or lower depend on source.
  • Page 24 • Have you installed the display driver? - To extend the lifetime of the monitor, use a screensaver. - Be sure to install the display driver from our web site: https://www.lg.com. • Are there spots on the screen? - Make sure to check if the graphics card supports function.

  • Page 25: Product Specification

    PRODUCT SPECIFICATION 4K/5K resolution is unavailable. • Did you check the cable connection? - Check if the cable is properly connected. Specifications are subject to change without notice. - It is recommended to use the accessories supplied with the product. The symbol means alternating current, and the symbol means direct current.
  • Page 26 Dimensions: Monitor Size (Width x Height x Depth) • With Stand - 947.2 x 614.7 x 283.0 (mm) - 37.2 x 24.2 x 11.1 (inches) • Without Stand - 947.2 x 419.2 x 114.8 (mm) - 37.2 x 16.5 x 4.5 (inches) Weight (Without Packaging) •...
  • Page 27 Support Mode (Preset Mode, DisplayPort / USB-C) Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1920 x 1080 66.587 59.934 3440 x 1440 1280 x 2160 133.160 59.928 PBP (5:9)
  • Page 28 (Preset Mode, Thunderbolt) Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1920 x 1080 66.587 59.934 3440 x 1440 1280 x 2160 133.160 59.928 PBP (5:9) 2560 x 2160 133.272...
  • Page 29 (Preset Mode, HDMI) Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) Polarity (H/V) Remarks 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1920 x 1080 66.587 59.934 3440 x 1440 73.681 49.987 HDMI1.4 Preferred timing, [HDMI ULTRA HD Deep Color]: [Off] 3440 x 1440 HDMI2.0 Preferred timing, [HDMI ULTRA HD Deep Color]: [On] 1280 x 2160...
  • Page 30 HDMI Timing (Video) Resolution Horizontal Frequency (kHz) Vertical Frequency (Hz) 640 x 480p 31.5 1280 x 720p 1920 x 1080p 67.5 3840 x 2160p 5120 x 2160p...
  • Page 31 Beep Guide Menu Location Menu Location Input (PBP Off) - PBP Input (PBP On) - PBP - Off - HDMI 2 2 4 1 2 Menu Location Input (PBP Off) - PBP - Off 2 4 1 Input (PBP On) - PBP - Off - DisplayPort 2 4 1 3 Quick Settings Input (PBP Off) - PBP - PBP(1:1)
  • Page 32 Menu Location Menu Location Menu Location Picture - Picture Adjust - SUPER RESOLUTION+ - Low 3 2 5 3 Picture - Color Adjust - Color Temp - Manual 3 4 2 5 Picture - Color Adjust - Six Color - Yellow Hue 3 4 6 11 Picture - Picture Adjust - SUPER RESOLUTION+ - Off 3 2 5 4...
  • Page 33 Menu Location General - SMART ENERGY SAVING - Off 4 2 3 General - Deep Sleep Mode 4 3 Toggle General - Power LED 4 4 Toggle General - Automatic Standby General - Automatic Standby - 8H 4 5 1 General - Automatic Standby - 6H 4 5 2 General - Automatic Standby - 4H...
  • Page 34 The model and serial number of the product are located on the back and on one side of the product. Trade Name Record them below in case you ever need service. Responsible Party LG Electronics USA, Inc. Address 111 Sylvan Avenue, North Building, Model Englewood Cliffs, NJ 07632 Serial No.
